  • Page 1 PT3270Q Touch LED LCD Monitor USER'S GUIDE www.planar.com...

  • Page 2: Table Of Contents

    Rear View of the Product ....................Quick Installation ........................8 Basic Operation ........................OSD Menu ........................Supporting Timing Modes ....................Technical Information ......................18 Wall Mount Instructions ..................... 19 Care and Maintenance Wall ....................20 Troubleshooting ........................ 20 Planar Support ........................21...

  • Page 3: Operation Instructions

    LED LCD Monitor can't be handled as normal trash in Europe when it is out of usage. Please refer to the recycle information on Planar's website to handle it. For more information on how to recycle your product, please visit http://www.planar.com/about/green/...
  • Page 4 COMMUNIQUE D'AVERTISSEMENT DE LA FCC CONCERNANT LES INTERFERENCE DE FREQUENCE RADIO: (SEULEMENT POUR MODELES CERTIFIE PAR LA FCC) Ce moniteur a été testé et à été trouvé conforme aux limites pour un appareil numérique de Class B, suivant la partie 15 des règlements de la FCC. Ces limites ont été développées pour offrir une protection satisfaisante contre les interférences nuisibles dans une installation résidentielle.

  • Page 5: Unpacking Instructions

    Unpacking Instructions  Remove the Touch LED LCD Monitor out of the package and take off EPE Foam. Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user's manual to maximize the life of your unit. DO : ...

  • Page 6: Consignes De Sécurité

    Consignes de sécurité Respectez tous les avertissements, les précautions et conseils d'entretien recommandés dans ce manuel de l'utilisateur pour maximiser la durée de vie de votre appareil. A faire:  É teindre le produit avant de le nettoyer.  La surface de l'écran tactile peut être nettoyée avec un chiffon doux et propre imprégné d'un nettoyant doux du commerce pour vitres ou d'un mélange à...

  • Page 7: Package Overview

    Package Overview TOUCH LED LCD MONITOR DP Cable TYPE-C to TYPE-C Cable HDMI Cable Power Cord USB-A to TYPE-C Cable User's Guide...

  • Page 8: Front View Of The Product

    Front View of the Product...

  • Page 9: Rear View Of The Product

    Rear View of the Product Power Input (AC input) HDMI Input DP Input USB-C Input (Output 5V1A) USB3.2 Gen 1 *2 (Output DC 5V1A) Audio Output (EARPHONE) LED Indicator Power On / Off Input select / Enter Brightness / Down Blue Light Reducer / Up Menu / Exit...

  • Page 10: Quick Installation

    Quick Installation Connect either USB-C to USB-C, DP, or HDMI Video Source from the monitor to the computer. If connecting USB-C only , see Fig 1. If connecting DP or HDMI inputs, please also connect the USB-A to TYPE-C Cable, see Fig 2. Connect the power cord to a properly grounded AC outlet, then to the monitor.

  • Page 11: Basic Operation

    Basic Operation Before using the TOUCH LED LCD MONITOR:  Connect external equipment properly.  Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the Touch LED LCD Monitor on/off: Press button on the back. The power LED indicator light will be blue when the Touch LED LCD Monitor is on.
  • Page 12 Repeat this step to unlock. PT3270Q Calibration/Reset Instructions： ® The PT3270Q is available with USB connection. It is Microsoft 7, 8, 10, 11 HID (Human Interface Device) compatible if you use the USB touch screen interface. No additional software driver is required .Calibration is a simple process and can be invoked by running Tablet PC Settings from control Panel and clicking the Calibrate button.

  • Page 13: Osd Menu

    OSD Menu BRIGHTNESS  BRIGHTNESS: Adjust backlight levels Adjust between 0-100.  CONTRAST: Adjust contrast levels Adjust between 0-100.  PICTURE MODE : Select from preset modes Standard, Movie, Game, Text.  DCR: Turn Dynamic Contrast Ratio on or off ON/OFF.
  • Page 14 IMAGE  ASPECT: Select aspect ratio FULL SCREEN, 4:3, 5:4, 16:10.  GAMMA: OFF, 1.8, 2.0, 2.2, 2.4.  SHARPNESS: Adjust between 0-100.  BLACK LEVEL: Adjust between 0-100.
  • Page 15 COLOR TEMP COLOR TEMP : Choose color temperature User, Warm, Normal, Cool Under USER, the following colors can be adjusted  R : Red 0-100  G : Green 0-100  B : Blue 0-100  LOW BLUE RAY Browsing, Low light, Video, Reading...
  • Page 16 OSD SETTING LANGUAGE : Choose language English, French, German, Italian, Spanish, Finnish, Japanese, Simplified Chinese, Traditional Chinese OSD H. POS : Adjust horizontal position of OSD 0~100 OSD V. POS : Adjust vertical position of OSD 0~100 OSD TIMER : Adjust OSD time out 0~60 TRANSPARENCY: Adjust OSD transparency 0~100...
  • Page 17 RESET  RESET : Reset to factory default...
  • Page 18 MISC SIGNAL SOURCE : Select Input source HDMI, DP, USB-C MUTE : ON/OFF VOLUME : Adjusts volume of earphone 0-100 TOUCH MODE : NORMAL, WATER PROOF, GLASS COVER, GLOVES, OFF NORMAL: Normal mode, support 10-point touch WATER PROOF: Water mist mode, supports single touch GLASS COVER: 6mm glass cover mode, support 10-point touch GLOVES: Glove mode, support 2-point touch when using 2mm thick labor gloves or medical gloves...

  • Page 19: Supporting Timing Modes

    Supporting Timing Modes STANDARD RESOLUTION 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA 800 x 600 @ 75Hz 832 x 624 @ 75Hz VESA 1024 x 768 @ 60Hz VESA...

  • Page 20: Technical Information

    Technical Information Panel 31.5" TFT (with LED backlight) Power Management Normal On: 26 Watts (typical), 55 Watts (maximum) Standby Mode: < 0.5Watt Off: < 0.3 Watt Displayable Resolution 2560x1440@60Hz max Pixel Dimension 0.2727(H)x0.2727(V)mm Display Color 1.07B Active Display Area 698.122mm x 392.688mm Temperature Operating: 5°...

  • Page 21: Wall Mount Instructions

    Wall-Mount Installation Instructions Attaching The Optional Wall Mount Arm (not supplied) Follow these steps to finish installing the wall mounting arm: 1. Place the wall mounting arm onto the back of the Touch LED LCD Monitor. Line up the holes of the arm with the holes in the back of the monitor.

  • Page 22: Care And Maintenance Wall

    Care and Maintenance Care  Avoid exposing your LED LCD monitor directly to sunlight or other heat source. Place your Touch LED LCD monitor away from the sun to reduce glare.  Put your Touch LED LCD monitor in a well ventilated area. ...

  • Page 23: Planar Support

    Planar Support Cables and Accessories To find cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com. Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touchscreen drivers, warranty information and access to Planar's Technical Library for online trouble shooting.
  • Page 24 Hours: 24 hours a day, 7 days a week © 09/2022 Planar Systems, lnc. Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is...
