The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced,translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission.
Usage Notice Warning - To prevent the risk of fi re or shock hazards, do not expose this product to rain or moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit.
Introduction About PT2275SW / PT2285PW The PT2275SW / PT2285PW is a 22" fl at panel screen with an active matrix, thin-fi lm transistor (TFT) liquid crystal display (LCD). Features include: • Direct Analog signal input • Direct Digital signal input •...
Installation Product Overview • Front View PT2275SW • PT2275SW Bottom View (Without Stand) AUDIO VGA IN • PT2285PW Bottom View (Without Stand) Audio VGA IN PT2285PW DVI IN AC IN RS-232 DVI IN AC IN...
Start Your Installation 1. Lay the LCD fl at on an even surface. 2. Remove the stand back cover by pulling in the direction of the arrow as seen in step 2 diagram. 3. Move the stand into position as seen in step 3 diagram. 4.
Page 10
6. Using a Philips Head screwdriver, insert the screw (CPMSP M3x10) into the cable cover and monitor as seen in the step 6 diagram. 7. Re-attach the stand back cover to the LCD stand by pressing fi rmly until the tabs snap into place as seen in the step 7 diagram.
To setup this display, please refer to the following fi gure and procedures. 1. Be sure all equipment is turned off. 2. Connect the AC power cord to the power connector on the monitor and the other end into an electrical outlet (9.1).
Kensington Security Slot The monitor can be secured to your desk or any other fi xed object with Kensington lock security products. The Kensington lock is not included.
The VESA mounting interface is located on the back of your monitor. To mount the monitor on a UL certifi ed swing arm or other mounting fi xture, follow the instructions included with the mounting fi xture to be used.
User Controls Side Panel Controls Menu off status Menu appear Brightness Mute Enter / Select sub-item function Power On / Off Icon key Name Menu Down Enter Power Menu on status Menu disappear / return to main item Main item select up / Adjust up Main item select down / Adjust down...
6. To Lock the OSD / Power menu buttons, please follow the instructions below. (Please note: the monitor has to be turned ON with a valid signal pre-set) (a.) Press “Menu” key , the OSD menu will pops upon display.
On-Screen Display Menus Main OSD Menu: ITEM CONTENT The monitor luminance level control. Contrast The monitor backlight level control. Brightness Fine-tune the image to full screen automatically. Auto Adjust Moving screen image horizontal position to left or right. Left/Right Moving screen image vertical position to up or down.
Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. ► Check that all the I/O and power connectors are correctly and well connected as described in the “Installation”...
The LCD display is under the power saving mode. In addition, the LCD display will enter power saving mode when experiencing a sudden signal disconnecting problem. The monitor can be activated by pressing any key on the keyboard, triggering the mouse or touching the screen.
Compatibility Modes Mode Resolution IBM VGA IBM VGA Apple MacII VESA VGA VESA VGA VESA VGA VESA VGA VESA VGA VESA VGA Apple Mac VESA XGA VESA XGA VESA XGA VESA SXGA VESA SXGA VESA SXGA VESA SXGA WXGA+ WXGA+ WSXGA+ WSXGA+ 1680X1050 (VGA only)
CD-ROM for these operating systems: Windows 64/32 bits, XP, 2000, ME, 98, NT 4.0, CE, XP Embedded, Linux, Apple The PT2285PW is available with USB connection. The touch driver is located on the enclosed CD-ROM for these operating systems: Windows...
PT2285PW Calibration Instructions: Calibrating the touch screen in Windows 7: 1. Tap the Start button, Control Panel and then Hardware and Sound. 2. Under Tablet PC Settings, tap Calibrate the screen for pen or touch input. 3. On the Display tab, under Display options, tap Calibrate and then Yes to allow the program to make changes.
PT2275SW/PT2285PW Driver Install Instructions: If you are using a PC running Windows NT4.0, follow the instructions below: 1. Power on the PC. 2. Be sure the USB or the RS-232 Serial cable is connected from the PC to the LCD display.
Page 30
3. Remove the original Touch Interface (RS-232 or USB). 4. Connect the computer to the Touch Interface (RS-232 or USB) that you would like to use. 5. Load the Touch Driver CD, then follow the step-by-step instructions as show on monitor. PLEASE NOTE! Don’t plug in both the RS-232 and USB cables!
Product Registration and Technical Support Register Your Planar Products Today Thank you for choosing Planar. To assure you receive all the benefi ts of your Planar product and services, register your Planar product today. Visit our website to register your product at http://www.planar.com/support/product_registration.html.
