- Page 1 ® PT1500MX / PT1550MX PT1555MU / PT1505MU Touch Screen LCD Monitors USER’S GUIDE www.planar.com...
- Page 2 Important Recycle Instructions: Lamp(s) inside this product contains mercury. This product may contain other electronic waste that can be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal Laws. For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG.
-
Page 3: Table Of Contents
Table of Contents Usage Notice Precautions..................2 Introduction About Planar’s PT1500MX/PT1550MX/PT1555MU/PT1505MU..3 Touch Screen for PT1500MX/PT1550MX/PT1555MU/PT1505MU……………………….4 Package Overview ................5 Installation Product Overview................6 VESA Mount for your Monitor…………………………………………….8 Start Your Installation……………………………………………………...9 Connecting the Display………………………………..…………………10 User Controls Front Panel Controls ................12 How to Use the OSD Menus ............13 On-Screen Display Menus ...............14... -
Page 4: Usage Notice
Usage Notice - To prevent the risk of fire or shock hazards, do not Warning expose this product to rain or moisture. - Please do not open or disassemble the product as Warning this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 5: Introduction
Introduction About PT1500MX / PT1550MX / PT1505MU / PT1555MU The PT1500MX / PT1550MX / PT1555MU / PT1505MU is a 15” flat panel screen with an active matrix, thin-film transistor (TFT) liquid crystal display (LCD). Features include: Direct Analog signal input... -
Page 6: Touch Screen For
VISTA, XP, 2000, ME, 98, CE, XP Embedded, Linux, ® Apple Mac OS Touch Screen for PT1505MU / PT1555MU Surface Acoustic Wave (SAW) touch screen for finger and stylus input Surface: Anti-glare treatment Interface: USB controller Durability: 30 million touches at a single point Hardness of surface: Mohs’... -
Page 7: Package Overview
Package Overview LCD Display Power Cord VGA Signal Cable USB Cable (A to A) Audio-in Cable RS-232 Cable (PT1550MX/PT1555MU) (PT1500MX/PT1550MX) USB Cable (A to B) Touch Screen Driver User’s Guide Installation CD-ROM Landing Strip DC Power Supply (sold separately) -
Page 8: Installation
Installation Product Overview Front View PT1500MX / PT1550MX Bottom View (Without Stand) -
Page 9: Kensington Security Slot
PT1505MU / PT1555MU Bottom View (Without Stand) Kensington Security Slot The monitor can be secured to your desk or any other fixed object with Kensington lock security products. The Kensington lock is not included. -
Page 10: Vesa Mount For Your Monitor
VESA Mount your monitor This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface Standard which defines a physical mounting interface for flat panel monitors, and corresponding standards for flat panel monitor mounting devices, such as wall and table arms. The VESA mounting interface is located on the back of your monitor. -
Page 11: Start Your Installation
Start Your Installation Remove the Back Cover Please follow these instructions to remove the cover on the back panel of the LCD so that you can hookup the cables to associated connector. Figure A. 1. To remove the back cover, follow the arrows in Figure A and pull out with your fingers and the cover should be removed from the stand. -
Page 12: Connecting The Display
7. Once the touch screen is configured, the monitor is ready for use. Instructions to attach the magnetic stripe reader to the PC (PT1550MX and PT1555MU models) 1. Attach the USB Type A to A cable to the magnetic stripe reader. - Page 13 To ensure the LCD display works well with your computer, please configure the display mode of your graphics card to make it less than or equal to 1024 x768 resolution and make sure the timing of the display mode is compatible with the LCD display.
-
Page 14: User Controls
User Controls Front Panel Controls Control Function No / Icon MENU Menu button Display the OSD menus Select – To select the adjustment items from OSD menus. SELECT/AUTO Select/Auto Auto – To activate the “Auto Adjustment” function to obtain an optimum image. 1. -
Page 15: How To Use The Osd Menus
How to Use the OSD Menus Press the "MENU" button to pop up the “on-screen menu” and to select among the four Main Menus. 2. Choose the adjustment items by pressing the “Select/Auto” button. 3. Adjust the value of the adjustment items by pressing the “ ”or “ “ button. 1. -
Page 16: On-Screen Display Menus
On-Screen Display Menus Main OSD Menu: MAIN MENU SUB MENU Function Description Auto-Adjustment Choose this function to obtain an optimum No/Yes image. Contrast Adjust the contrast of the display image. 0-100 Brightness Adjusts the brightness of the image. 0-100 Horizontal Position Changes the horizontal position of the image. -
Page 17: Appendix
Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. Check that all the I/O and power connectors are correctly and well connected as described in the “Installation”... -
Page 18: Warning Signal
There may be three sources for this problem. Please check the cable connections or contact Planar for more information. No Signal This message means that the LCD Display has been powered on but it cannot receive any signal from the computer graphics card. -
Page 19: Product Dimensions
Product Dimensions... -
Page 20: Compatibility Modes
Compatibility Modes Mode Resolution H-Frequency (KHz) V-Frequency (Hz) 720x350 31.47 720x400 31.47 640x480 31.47 VESA 640x480 37.86 VESA 640X480 37.5 VESA 800x600 35.16 VESA 800x600 37.88 VESA 800x600 46.88 VESA 800x600 48.08 VESA 1024x768 48.36 1024x768 52.45 VESA 1024x768 56.48 VESA 1024x768 60.02... -
Page 21: Touch Screen Driver Installation
Touch Screen Driver Installation Driver Installation Process: 1. Before you start to install the touch driver, please be sure the USB or the RS-232 Serial cable is connected from the PC or the LCD display. 2. Uninstall any touch screen driver that may be on your system. 3. - Page 22 2. Power on the computer. 3. Load the touch screen driver CD. 4. Follow the step-by-step instructions as shown on pop-up windows. PT1505MU / PT1555MU Driver Install: The touch driver is located on the enclosed CD-ROM for these OS: Windows® VISTA, XP, 2000, 98.
-
Page 23: Product Registration And Technical Support
Product Registration and Technical Support Register Your Planar Products Today Thank you for choosing Planar. To assure you receive all the benefits of your Planar product and services, register your Planar product today. Visit our website to register your product at http://www.planar.com/support/product_registration.html. - Page 24 Tel: 1-866-PLANAR1 (866-752-6271) or +1 503-748-5799 outside the United States. Hours: 24 hours a day, 7 days a week © 2008 Planar Systems, Inc. 1/08 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners.
