Sharp QT-CD161 Service Manual page 33

NO. PARTS CODE
231 PRDAR0001SJZZ
232 LHLDA1001SJZZ
233 CMECB0001SJ01
233- 1 9GD192104309
233- 2 9GD192107039
233- 3 9GD192109389
233- 4 9GD62070114
233- 5 9GD62091010
233- 6(M601) 9GD192112343W
233- 7(SW601) 9GD6401011499
234 TSPC-0079SJZZ
234 TSPC-0080SJZZ
235 CGERH0001SJ01
236 LHLDZ1016SJZZ
237 MSPRC0003SJFE
240 MSPRD0002SJFD
601 XUBSD30P12000
602 XUBSD30P20000
603 XUBSD30P10000
604 XUBSD25P10000
605 XWHSD28-08120
606 XUPSD25P08000
607 XUBSD30P08000
608 XHBSD20P03000
609 XEBSF30P10000
ACCESSORIES
QACCU0001SJ00
!
TINSE0023SJZZ
TINSE0025SJZZ
TINSZ0037SJZZ
TINSZ0038SJZZ
TLABN0053SJZZ
TLABN0054SJZZ
TLABR1041SJZZ
TLABR1043SJZZ
TLABZ0026SJZZ
TLABZ0027SJZZ
RRMCG0015SJSA J
HTR0211-720010
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~7 DCEK-0004SJ03
PWB-A1~6 DCEK-0004SJ06
PWB-B QPWBF3895AFZZ
OTHER SERVICE PART
UDSKA0004AFZZ
PRICE
DESCRIPTION
RANK
J AD Heat Sink
J AC Holder,Bar Antenna
J AY Tape Mechanism Ass'y
J AR Pinch Roller Arm Ass'y
J AE Belt,RF
J AE Belt,Main
J AL Head,Playback/Record
J AM Head,Erase
J AX Motor With Pulley [Tape]
J AE Switch,Leaf Type [Tape Main]
J AF Label,Specifications [For U.S.A.]
J Label,Specifications
[Except for U.S.A.]
J AF Gear,Damper
J AE Holder,LCD
J AF Spring,Back Up
J AC Spring,CD Lid
J AA Screw,ø3×12mm
J AA Screw,ø3×20mm
J AA Screw,ø3×10mm
J AB Screw,ø2.5×10mm
J AB Washer,ø2.8×ø12×0.8mm
J AB Screw,ø2.5×8mm
J AA Screw,ø3×8mm
J AA Screw,ø2×3mm
J AA Screw,ø3×10mm
J AR AC Power Supply Cord
J AH Operation Manual
[For U.S.A./Central America]
[QT-CD161]
J AP Operation Manual
[For U.S.A./Central America]
[QT-CD141]
J Operation Manual [Except for
U.S.A/Central America]
[QT-CD161]
J Operation Manual [Except for
U.S.A./Central America]
[QT-CD141]
J AE Label,Serial No. [QT-CD161]
J Label,Serial No. [QT-CD141]
J AD Label,Bar Code [QT-CD141]
J AE Label,Bar Code [QT-CD161]
J AE Label,Feature [QT-CD161]
J AG Label,Feature [QT-CD141]
AX Remote Control
[QT-CD161 Only]
J Battery Lid,Remote Control
[QT-CD161 Only]
J –– Main/Headphones/Terminal/
Battery/Battery/Switch/Spacer
(Combined Ass'y)[QT-CD161]
J –– Main/Terminal/Battery/Battery/
Switch/Spacer
(Combined Ass'y)[QT-CD141]
J AC CD Motor (PWB Only)
J AZ CD Pickup Lens Cleaner
NO. PARTS CODE
– 4 –
QTCD161/141
PRICE
DESCRIPTION
RANK
