Names Of Parts; Remote Control - Sharp QT-CD161 Service Manual

1. Cassette Compartment
2. CD Compartment
3. (TAPE) Record Button:
4. (TAPE) Play Button:
5. (TAPE) Rewind Button:
6. (TAPE) Fast Forward Button:
7. (TAPE) Stop/Eject Button:
8. (TAPE) Pause Button:
9. Band/Pause:
10. Tuner Memory
11. Volume
12. Power, On/Function Switch
13. Extra Bass Button: X-BASS
14. (CD) Track Down: /Review Button:
15. (CD) Track Up: /Cue Button:
16. (TUNER)Tuning: /(CD) Stop Button:
17. (TUNER) Tuning: /(CD) Play/Repeat Button:
18. FM Telescopic Rod Aerial
19. Headphone Socket (QT-CD161 Only)
20. Battery Compartment
21. AC Power Input Socket
Remote control (QT-CD161 ONLY)
1. (TUNER) Tuning: /(CD) Play/Repeat Button:
2. (CD) Track Down: /Review Button:
3. Band/Pause:
4. (CD) Track Up: /Cue Button:
5. (TUNER)Tuning: /(CD) Stop Button:
Notes concerning use:
Replace the batteries if the operating distance is
reduced or if the operation becomes erratic.
Periodically clean the transmitter LED on the
remote control and the sensor on the main unit
with a soft cloth.
Exposing the sensor on the main unit to strong
light may interfere with operation. Change the
lighting or the direction of the unit.
Keep the remote control away from moisture,
excessive heat, shock, and vibrations.

NAMES OF PARTS

/
REMOTE CONTROL (QT-CD161 ONLY)
3 4
9
10
16
12
13 11
20
2
3
Sensor Remote
– 3 –
QT-CD161/141
5 6 7 8
1
2
14
17
18 19
21
1
4
5
8" - 20'
(0.2 m - 6 m)
0,2 m - 6 m
15
