Sharp QT-CD161 Service Manual page 32

QT-CD161/141
NO. PARTS CODE
R546 VRD-ST2CD153J
R547 VRD-ST2CD332J
R548 VRD-ST2EE470J
R549,550 VRD-ST2CD153J
R552 VRD-ST2CD102J
R801 VRD-ST2CD102J
R802 VRD-ST2CD104J
R803 VRD-ST2CD153J
R804 VRD-ST2CD222J
R805 VRD-ST2CD682J
R806 VRD-ST2CD101J
R807 VRD-ST2CD102J
R808 VRD-ST2CD123J
R809 VRD-ST2CD273J
R810 VRD-ST2CD823J
R811 VRD-ST2CD332J
R812 VRD-ST2CD153J
R813 VRD-ST2CD333J
R814 VRD-ST2CD103J
R815 VRD-ST2CD473J
R816 VRD-ST2CD152J
R817 VRD-ST2CD823J
R819 VRD-ST2CD393J
R820 VRD-ST2CD103J
R821 VRD-ST2CD563J
R822 VRD-ST2CD682J
R823 VRD-ST2CD122J
R824 VRD-ST2CD103J
R825 VRD-ST2CD122J
R826,827 VRD-ST2CD224J
R828~831 VRD-ST2CD102J
R832 VRD-ST2CD563J
R833 VRD-ST2CD562J
R834 VRD-ST2CD102J
R835 VRD-ST2CD471J
R836,837 VRD-ST2CD473J
R838 VRD-ST2CD333J
R839,840 VRD-ST2CD223J
R842 VRD-ST2EE220J
R849 VRD-ST2CD104J
R856 VRD-ST2CD122J
R857 VRD-ST2CD273J
R858 VRD-ST2CD681J
R860 VRD-ST2CD102J
R871 VRD-ST2CD472J
R873,874 VRD-ST2CD101J
R875,876 VRD-ST2CD103J
R880 VRD-ST2CD101J
OTHER CIRCUITRY PARTS
BI801/CNS801 QCNWN0113SJZZ J
BI802/CNS802 QCNWN0114SJZZ J
BI803/CNS803 QCNWN0115SJZZ J
CNP101 QCNCW001DSJZZ J
CNP201 QCNCW001CSJZZ J
CNP602 QCNCW002CSJZZ J
CNS101 ————
CNS201 QCNWN0001SJZZ J
CNS602 QCNWN0132SJZZ J
FW201 QCNWN0133SJZZ J
FW202 QCNWN0140SJZZ J
FW203 QCNWN0144SJZZ J
FW501 QCNWN0134SJZZ J
FW601 QCNWN0089SJZZ J
J39 RCORF0001SJZZ
J100 RCORF0001SJZZ
J201 QJAKM0007AWZZ J
LCD501 RV-LX0005SJZZ
M601 9GD192112343W
M701 RMOTV0408AFM3 J
M702 RMOTV0409AFM1 J
RX501 VHLN61V380A-1
SO601 QSOCA0001SJZZ
!
SP501,502 VSP0010PBT98S
SW102 QSW-S0001SJZZ
SW201 QSW-S0008SJZZ
PRICE
DESCRIPTION
RANK
J AA 15 kohms,1/6W
J AA 3.3 kohms,1/6W
J AA 47 ohms,1/4W [QT-CD161 Only]
J AA 15 kohms,1/6W
J AA 1 kohm,1/6W
J AA 1 kohm,1/6W
J AA 100 kohm,1/6W
J AA 15 kohms,1/6W
J AA 2.2 kohms,1/6W
J AA 6.8 kohms,1/6W
J AA 100 ohm,1/6W
J AA 1 kohm,1/6W
J AA 12 kohms,1/6W
J AA 27 kohms,1/6W
J AA 82 kohms,1/6W
J AA 3.3 kohms,1/6W
J AA 15 kohms,1/6W
J AA 33 kohms,1/6W
J AA 10 kohm,1/6W
J AA 47 kohms,1/6W
J AA 1.5 kohms,1/6W
J AA 82 kohms,1/6W
J AA 39 kohms,1/6W
J AA 10 kohm,1/6W
J AA 56 kohms,1/6W
J AA 6.8 kohms,1/6W
J AA 1.2 kohms,1/6W
J AA 10 kohm,1/6W
J AA 1.2 kohms,1/6W
J AA 220 kohms,1/6W
J AA 1 kohm,1/6W
J AA 56 kohms,1/6W
J AA 5.6 kohms,1/6W
J AA 1 kohm,1/6W
J AA 470 ohms,1/6W
J AA 47 kohms,1/6W
J AA 33 kohms,1/6W
J AA 22 kohms,1/6W
J AA 22 ohms,1/4W
J AA 100 kohm,1/6W
J AA 1.2 kohms,1/6W
J AA 27 kohms,1/6W
J AA 680 ohms,1/6W
J AA 1 kohm,1/6W
J AA 4.7 kohms,1/6W
J AA 100 ohm,1/6W
J AA 10 kohm,1/6W
J AA 100 ohm,1/6W
AF Connector Ass'y,8Pin
AD Connector Ass'y,5Pin
AE Connector Ass'y,6Pin
AC Socket,4Pin
AC Socket,3Pin
AD Socket,3Pin
–– Connector Ass'y,4Pin
(Not Replacement Item)
AD Connector Ass'y,3Pin
AE Connector Ass'y,3Pin
AE Flat Wire,5Pin
AE Flat Wire,3Pin [QT-CD161 Only]
Flat Wire,8Pin
AE Flat Wire,3Pin
AG Flat Wire,2Pin
J AC Core
J AC Core
AF Jack,Headphones
[QT-CD161 Only]
J AU LCD
J AX Motor with Pulley [Tape]
AN Motor with Chassis [Spindle]
AN Motor with Gear [Sled]
J AN Remote Sensor
[QT-CD161 Only]
J AE AC Socket
J AL Speaker,Woofer
J AD Switch,Slide Type
[Record/Playback]
J AG Switch,Slide Type
[Function/Power]
NO. PARTS CODE
SW202 QSW-P0001SJZZ
SW501 QSW-K0001SJZZ
SW502 QSW-K0001SJZZ
SW503 QSW-K0001SJZZ
SW504 QSW-K0001SJZZ
SW505 QSW-K0001SJZZ
SW506 QSW-K0001SJZZ
SW507 QSW-F0001SJZZ
SW601 9GD192112343W
SW702 QSW-F9001AWZZ
W601 QCNWN0101SJZZ J
CD MECHANISM PARTS
301 NGERH0586AFZZ
302 NGERH0587AFZZ
303 MLEVP1054AFZZ
304 NSFTM0291AFFW J
305 PCUSG0613AFZZ
306 RCTRH8179AFZZ
!
701 XBSSD26P06000
702 XHBSD20P05000
703 XBBSD20P03000
704 LX-WZ1070AFZZ
M701 RMOTV0408AFM3 J
M702 RMOTV0409AFM1 J
SW702 QSW-F9001AWZZ
CABINET PARTS
201 GCABA1029SJM1
201 GCABA1032SJM1
202 GCABC1029SJSA
202 GCABC1029SJSB
203 GCABB1029SJSA
203 GCABB1032SJSA
204 HPNLC1032SJSA
204 HPNLC1036SJSA
205 HDECQ0022SJSA
205 HDECQ0022SJSB
206 JKNBK0016SJSA
207 LHLDW1001SJZZ
208 MSPRC0002SJFD
209 JHNDP1001SJSA
209 JHNDP1002SJSB
210 QANTR0003SJZZ
211 MSPRZ0001SJFD
212 GFTAB1001SJSA
212 GFTAB1005SJSB
213 JKNBK0018SJSA
214 LHLDZ1015SJSA
214 LHLDZ1015SJSB
215 JKNBK0017SJSA
215 JKNBK0017SJSB
216 GFTAC1001SJSA
216 GFTAC1001SJSD
217 MSPRD0001SJFD
218 JBTN-0001SJSA
218 JBTN-0007SJSB
219 JBTN-0002SJSA
219 JBTN-0008SJSB
220 JBTN-0003SJSA
220 JBTN-0009SJSB
221 JBTN-0004SJSA
221 JBTN-0010SJSB
222 JBTN-0005SJSA
222 JBTN-0011SJSB
223 JBTN-0006SJSA
223 JBTN-0012SJSB
224 LANGK0001SJFW
225 PGUMS0001SJZZ
226 GFTAT1001SJSA
226 GFTAT1001SJSD
227 CHLDM1001SJ01
227- 1 ————
227- 2 PMAGF0002AWZZ J
228 MSPRP0001SJFW J
230 MSPRC0001SJFN
– 3 –
PRICE
DESCRIPTION
RANK
J AD Switch,Push Type [X-Bass]
J AC Switch,Key Type [Tuner Up]
J AC Switch,Key Type [Tuner Down]
J AC Switch,Key Type [Band]
J AC Switch,Key Type [Memory]
J AC Switch,Key Type [Preset Down]
J AC Switch,Key Type [Preset Up]
J AD Switch,Leaf/Skeleton Type
[CD Lid Open/Close]
J AX Switch,Push Type [Tape Main]
J AE Switch,Push Type [Pickup In]
AC Flat,Wire,2Pin
J AC Gear,Middle
J AC Gear,Drive
J AC Rail,Guide
AD Shaft,Guide
J AC Cushion
J BG Pickup Unit Ass'y
J AA Screw,ø2.6×6mm
J AA Screw,ø2×5mm
J AA Screw,ø2×3mm
J AA Washer,ø4.5×ø1.5×0.25mm
AN Motor with Chassis [Spindle]
AN Motor with Gear [Sled]
J AE Switch,Push Type [Pickup In]
J BC Front Cabinet Ass'y [QT-CD161]
J BA Front Cabinet Ass'y [QT-CD141]
J AV Top Cabinet [QT-CD161]
J AR Top Cabinet [QT-CD141]
J AZ Rear Cabinet [QT-CD161]
J AV Rear Cabinet [QT-CD141]
J AS Panel,Control [QT-CD161]
J AK Panel,Control [QT-CD141]
J AF Decoration Plate [QT-CD161]
J AE Decoration Plate [QT-CD141]
J AE Knob,Volume
J AD Nylon Band
J AC Spring,Battery,+/-
J AE Handle [QT-CD141]
J AM Handle [QT-CD161]
J AL Rod Antenna
J AC Spring,Rod Antenna
J AD Battery Compartment Lid
[QT-CD141]
J AH Battery Compartment Lid
[QT-CD161]
J AC Knob,X-BASS
J AF Button,Unit [QT-CD161]
J AF Button,Unit [QT-CD141]
J AC Knob,Function [QT-CD161]
J AC Knob,Function [QT-CD141]
J AE Cassette Lid [QT-CD141]
J AM Cassette Lid [QT-CD161]
J AC Spring,Cassette Lid
J AC Button,Pause [QT-CD141]
J AC Button,Pause [QT-CD161]
J AC Button,Stop [QT-CD141]
J AC Button,Stop [QT-CD161]
J AC Button,FF [QT-CD141]
J AC Button,FF [QT-CD161]
J AC Button,REW [QT-CD141]
J AC Button,REW [QT-CD161]
J AC Button,Play [QT-CD141]
J AC Button,Play [QT-CD161]
J AC Button,Rec [QT-CD141]
J AC Button,Rec [QT-CD161]
J AC Bracket,Button
J AB Leg,Cushion
J AE CD Lid [QT-CD141]
J AN CD Lid [QT-CD161]
J AG Stabilizer Ass'y
–– Stabilizer
(Not Replacement Item)
AE Magnet
AC Lever,Record
J AC Spring,Battery,-
