easily. The system manager can change the key range with a
command, for example, in an overnight operation, or you can
plan to do this during scheduled maintenance.
A partition can also have multiple standby servers.
A node can be configured as a primary server for one key range
Standby Server
and as a standby server for another key range. This helps
Configurations
to distribute the work of the standby servers. Figure 1–19
illustrates this use of standbys with distributed partitioning.
As shown in Figure 1–19, the Server application on backend A
is the primary server for accounts 1 to 19,999 and the Server
application on backend B is the standby for these same accounts,
shown as a dashed line. The Server application on backend B
is the primary for accounts 20,000 to 39,999 and the Server
application on backend A can be the standby for these same
accounts (not shown in the figure). For clarity, account numbers
are shown only for the primary servers and one standby server.
Figure 1–19 Standby with Partitioning
RTR supports anonymous clients; that is, clients can be set up in
Anonymous clients
a configuration using wildcarded node names.
RTR can also be used with firewall tunneling software, which
Tunnel
supports secure internet communication for an RTR connection,
either client-to-router, or router-to-backend.
1-19,999
TR
1-19,999
20,000-39,999
RTR Server Types
BE
Server
1-19,999
application
A
1-19,999
BE
20,000-39,999
Server
application
B
20,000-39,999
Introduction 1–25
Accounts:
1-19,999
Accounts:
