Specifications, Cont'd
Product weight
MDA 5SVA RCA,
MDA 3AV RCA ............... 2.2 lbs (1.0 kg)
MDA 5AV RCA ............... 2.3 lbs (1.0 kg)
Shipping weight .......................... 5 lbs (2.3 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
FCC Class A Notice
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference, in which case the user will be required to correct the interference
at his own expense.
Note: This unit was tested with shielded cables on the peripheral devices. Shielded
cables must be used with the unit to ensure compliance.
Extron Electronics, USA
Extron Electronics, Europe
1230 South Lewis Street
Beeldschermweg 6C
Anaheim, CA 92805
3821 AH Amersfoort
USA
The Netherlands
714.491.1500
+31.33.453.4040
www.extron.com
Fax 714.491.1517
Fax +31.33.453.4050
© 2002 Extron Electronics. All rights reserved.
Extron Electronics, Asia
Extron Electronics, Japan
135 Joo Seng Road, #04-01
Daisan DMJ Building 6F
PM Industrial Building
3-9-1 Kudan Minami
Singapore 368363
Chiyoda-ku, Tokyo 102-0074 Japan
+65.6383.4400
+81.3.3511.7655
Fax +65.6383.4664
Fax +81.3.3511.7656
User's Guide
MDA 5SVA RCA / 5AV RCA / 3AV RCA
Video and Audio Mini Distribution Amplifiers
68-615-01 Rev. B
Printed in the USA
08 02
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Extron electronics MDA 5SVA RCA
Summary of Contents for Extron electronics MDA 5SVA RCA
- Page 1 Note: This unit was tested with shielded cables on the peripheral devices. Shielded MDA 5SVA RCA / 5AV RCA / 3AV RCA cables must be used with the unit to ensure compliance. Video and Audio Mini Distribution Amplifiers 68-615-01 Rev.
-
Page 2: Rack Installation
(diagonal) corners to secure the MDA to loop-through for a local monitor. the shelf. • MDA 5SVA RCA — S-video DA with one S-video and stereo Install the blank panel (included with the rack shelf) or audio input and five S-video and stereo audio outputs. -
Page 3: Specifications
75 Ohm 0.2A LOOP INPUT OUTPUTS MDA 5SVA RCA ..... Y: 1.0V p-p (including sync), C: 0.3V p-p MDA 3AV RCA, MDA 5AV RCA 1.0V p-p (including sync) Figure 2 — MDA 3 and MDA 5 Series front and rear panels Minimum/maximum level MDA 5SVA RCA ..... - Page 4 Nominal level ....... Compatible with +4dBu (1.23V), Nominal level 0dBu (0.775V), -10dBV (316mV), and MDA 5SVA RCA ..... Y: 1.0V p-p (including sync), C: 0.3V p-p -20dBV (100mV) MDA 3AV RCA, MDA 5AV RCA Maximum level (Hi-Z) ....>+24dBu, unbalanced at 1%THD+N 1.0V p-p (including sync)
