Specifications - Extron electronics KP 6 Keypad Remote User Manual

Figure 3 — KP 6 application (with 5-pole captive
screw connector)
Operation
To select an input using the KP 6 Keypad Remote Control, press the
number key for the desired input.

Specifications

Power ............................................. None required
Temperature/humidity .............. Storage -40° to +158° (-40° to +70°C)/ 10%
Operating ...................................... +32° to +122° (0° to +50°C)/ 10% to 90%,
Enclosure type .............................. Plastic
Approvals ..................................... CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
