- Page 1 User’s Guide KP 6 Keypad Remote Keypad Remote Controls 68-694-01 Rev. A Printed in the USA 07 02...
-
Page 2: Installation And Operation
REMOTE SW6 VGA Ars SW6 VGA Ars OUTPUT OUTPUT Install the KP 6 Keypad Remote Control on this type of switcher as 50-60Hz follows: SW6 VGA Ars Switcher Rewire the connector on the KP 6 Keypad Remote Control. Power down the switcher. -
Page 3: Specifications
Remote Control Figure 3 — KP 6 application (with 5-pole captive screw connector) Operation To select an input using the KP 6 Keypad Remote Control, press the number key for the desired input. Specifications Power ..........None required Temperature/humidity ....Storage -40° to +158° (-40° to +70°C)/ 10% to 90%, non-condensing Operating ........
