  • Page 1 QUANTUM Q6 Edge VA...
  • Page 2 On the product, this icon is represented as a black symbol with a red circle and red slash. NTENDED The intended use of the Pride Mobility Products device is to provide mobility to persons limited to a seated position that have the capability of operating a powered wheelchair. Quick Reference Information...

  • Page 3: Table Of Contents

    C O N T E N T S INTRODUCTION ...........................4 SAFETY ..............................5 III. YOUR POWER CHAIR ........................7 IV. ASSEMBLY ............................12 COMFORT ADJUSTMENTS ......................16 VI. BATTERIES AND CHARGING ......................23 VII. CARE AND MAINTENANCE ......................27 Q6 Edge VA www.pridemobility.com...

  • Page 4: Introduction

    I . I N T R O D U C T I O N SAFETY WELCOME to Quantum Rehab, a division of Pride Mobility Products (Pride). The power chair you have pur- chased combines state-of-the-art components with safety, comfort, and styling in mind. We are confident that these design features will provide you with the conveniences you expect during your daily activities.
  • Page 5 I I . S A F E T Y PRODUCT SAFETY SYMBOLS The symbols below are used on the power chair to identify warnings, mandatory actions, and prohibited actions. It is very important for you to read and understand them completely. NOTE: There are more warnings identified and explained in the Consumer Safety Guide that is included with your power chair.

  • Page 6: Ii. Safety

    I I . S A F E T Y GENERAL GUIDELINES MANDATORY! Do not operate your new power chair for the first time without completely reading and understanding this owner’s manual. Your power chair is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an extensive variety of products to best fit the individual needs of the power chair user.
  • Page 7 I I I . Y O U R P O W E R C H A I R THE Q6 EDGE VA POWER CHAIR Your power chair has two main assemblies: the seat assembly and the power base assembly. See figure 1. Typically, the seat assembly includes the armrests, seatback, and seat base.

  • Page 8: Iii. Your Power Chair

    I I I . Y O U R P O W E R C H A I R TRAPEZE BARS REAR SHROUD FRONT COVER MANUAL FREEWHEEL LEVER SUSPENSION SPRING Figure 2. The Q6 Edge VA Power Base PROHIBITED! The spring tension on your power chair was factory set to meet the needs of the demographic majority of users.
  • Page 9 I I I . Y O U R P O W E R C H A I R Main Circuit Breaker (located on the rear main frame): The main circuit breaker is a safety feature built into your power chair. When the batteries and the motors are heavily strained (e.g., from excessive loads), the main circuit breaker trips to prevent damage to the motors and the electronics.
  • Page 10 I I I . Y O U R P O W E R C H A I R Manual Freewheel Levers For your convenience, your power chair is equipped with a manual freewheel lever mounted on each motor. The levers allow you to disengage the drive motors and maneuver the chair manually. WARNING! The power chair could roll unintentionally when the drive motors are disengaged on an incline! Property damage, severe injury or death can occur.
  • Page 11 I I I . Y O U R P O W E R C H A I R MANUAL FREEWHEEL LEVER MANUAL FREEWHEEL LEVER Figure 5A. Drive Mode (Left Drive Motor Engaged) Figure 5B. Drive Mode (Right Drive Motor Engaged) Q6 Edge VA www.pridemobility.com...

  • Page 12: Initial Assembly

    I V . A S S E M B L Y INITIAL ASSEMBLY Your power chair may require some assembly either before initial use or after transportation. It may also require disassembly to make some comfort adjustments. Figure 6 details those parts of the power chair that are designed to be disassembled and assembled by an end user or by a qualified caregiver before using the product or making comfort adjustments.

  • Page 13: I V . A S S E M B L Y

    I V . A S S E M B L Y Seat Installation SEAT LATCH SAFETY It may be necessary to install the seat either prior to initial operation or after transporting your power chair. For unoccupied transit power chairs, contour seats are attached to the power base with the Universal Mount- ing System (UMS).
  • Page 14 I V . A S S E M B L Y MANDATORY! Prevent controller harness damage! Avoid routing the controller harness on the outside of the armrest pad. Route the harness under the armrest or toward the inside of the armrest pad. Use correct tie- down points for controller harness to prevent harness...
  • Page 15 I V . A S S E M B L Y Power Elevating Seat Option SEAT PLATE INTERFACE Your power chair may be equipped with a power ele- BRACKET vating seat option. While the seat itself may be any one of the styles offered for this model, the way the seat base attaches to the power base is different.

  • Page 16: Comfort Adjustments

    Your Quantum Rehab Provider has evaluated your power chair and made any necessary adjustments to suit your specific requirements. Do not change your seating configuration without first contacting Pride Mobility Products or your Quantum Rehab Provider.

  • Page 17: V. Comfort Adjustments

    V . C O M F O R T A D J U S T M E N T S 7. Remove the hardware that attaches the trapeze bars to the seat interface weldments. See figure 13. 8. Move the trapeze bars up or down to the desired height.

  • Page 18: Armrest Width Adjustment

    V . C O M F O R T A D J U S T M E N T S Seatback Angle Adjustment If your power chair is equipped with an adjustable seat- back, you can adjust it to four (4) different angles: 90°, JAM NUT 102°, 105°, or 107°.

  • Page 19: Controller Position

    V . C O M F O R T A D J U S T M E N T S Controller Position You can move the controller in toward or out away from the armrest, or change the position of the control- ler for either left-hand or right-hand use.
  • Page 20 V . C O M F O R T A D J U S T M E N T S Foot Platform Height Adjustment The foot platform height is easily adjusted to several different heights. To raise or lower the foot platform: 1.
  • Page 21 V . C O M F O R T A D J U S T M E N T S Power Elevating Seat (Optional) If your power chair is equipped with a power elevating seat, you can change the seat height either through the controller or through a toggle switch mounted to one of the armrests.

  • Page 22: Positioning Belt

    V . C O M F O R T A D J U S T M E N T S Positioning Belt Your power chair may be equipped with a positioning belt that can be adjusted for operator comfort. See fig- ure 19.

  • Page 23: Batteries And Charging

    V I . B A T T E R I E S A N D C H A R G I N G BATTERIES AND CHARGING The Q6 Edge VA uses two long-lasting, 12-volt, deep-cycle batteries. These batteries are sealed and maintenance free.

  • Page 24: Vi. Batteries And Charging

    V I . B A T T E R I E S A N D C H A R G I N G To charge the batteries using the off-board charger: 1. Position your power chair next to a standard electrical outlet.
  • Page 25 V I . B A T T E R I E S A N D C H A R G I N G Daily Use If you use your power chair on a daily basis, charge the batteries as soon as you are finished using your power chair.
  • Page 26 V I . B A T T E R I E S A N D C H A R G I N G How can I ensure maximum battery life? A fully charged deep-cycle battery will provide reliable performance and extended battery life. Keep your power chair’s batteries fully charged whenever possible.

  • Page 27: Care And Maintenance

    V I I . C A R E A N D M A I N T E N A N C E CARE AND MAINTENANCE Your Q6 Edge VA is a sophisticated power chair. Like any motorized vehicle, it requires routine maintenance checks.

  • Page 28: Vii. Care And Maintenance

    V I I . C A R E A N D M A I N T E N A N C E The body shroud has been sprayed with a clear sealant coating. You can apply a light coat of car wax to help it retain its high-gloss appearance.

  • Page 29: Cleaning And Disinfection

    V I I . C A R E A N D M A I N T E N A N C E Storage Your power chair should be stored in a dry place, free from temperature extremes. When storing, disconnect the batteries from the power chair.

  • Page 30: Battery Replacement

    V I I . C A R E A N D M A I N T E N A N C E TIRE TUBE SCREWS WHEEL FRONT RIM HALF REAR RIM HALF LUG NUTS Figure 21. Q6 Edge VA Drive Wheel Figure 22.
  • Page 31 V I I . C A R E A N D M A I N T E N A N C E To replace the batteries: 1. Turn off the power to the controller. 2. Make sure that the power chair is in drive mode. See III. “Your Power Chair.” 3.

  • Page 32: Corrective Maintenance

    V I I . C A R E A N D M A I N T E N A N C E When to See Your Quantum Rehab Provider for Service The following symptoms could indicate a serious problem with your power chair. If necessary, contact your Quantum Rehab Provider.
  • Page 33 N O T E S Q6 Edge VA www.pridemobility.com...
  • Page 34 N O T E S www.pridemobility.com Q6 Edge VA...
  • Page 36 Q6 Edge VA Product Serial #...
