Features:
• High Efficiency Class D Topology
• Compact Size for Easy Installation
• Balanced Differential Input Circuitry
• Audiophile NJM2068M Operational Amplifiers
• Ultra High Speed IR Class D Chipset
• 48dB Subsonic and 24dB Low Pass Crossovers
• Robust Unregulated Power Supply
• Surface Mount Component Technology
• Direct Insert Power and Speaker Terminals
• Audio Precision Quality Control Verification
• High Temperature Plexiglass cover
• RBC- Remote subwoofer level control included
• RMD - Remote Monitoring Display Port
• Signal Clipping Indicators
Manual del Amplificador
Manuel del'amplifica teur
Características:
• Alta eficiencia de clase D Topología
• Tamaño compacto para una fácil instalación
• Diferencial balanceada circuitos de entrada
• Audiophile NJM2068M amplificadores operacionales
• IR Chipset Ultra Alta Velocidad
• 48dB Subsonic and 24dB Low Pass Crossovers
• Robusta y no regulada Fuente de Poder
• Tecnología "Surface Mount Component"
• Conexiones directas de terminales de poder y de
parlantes
• Control de verificación de calidad de precisión de audio
• Cubierta de Plexiglás resistente a altas temperaturas
• RBC -Control de nivel de Subwoofer remoto incluido
• RMD - Puerto de display para monitoreo remoto
• Indicadores de señal máxima
Amplifier Manual
Models: Ti2800.1, Ti21300.1
Caractéristiques:
• Topologie de classe D de gamme complète
• Petit format pour faciliter l'installation
• Circuit équilibré Entrée différentielle
• Audiophile NJM2068M Amplificateurs opérationnels
• Haute Vitesse IR de classe D chipset
• Filtres croisés passe-haut et passe-bas
• Alimentation électrique robuste non réglementée
• Technologie de composant monté en surface
• Terminaux d'alimentation et de haut-parleurs à
insertion directe
• Vérification du contrôle de la qualité de la précision audio
• Couvercle de plexiglas résistant aux températures élevées
• RBC- Niveau de contrôle de passe-bas inclus
• RMD - Entrée De L'affichage de Tension a Distance
• Indicateurs de saturation du signal
Phoenix Gold • www.phoenixgold.com
Advertisement
Table of Contents
Related Manuals for Phoenix Gold TI2800.1
Summary of Contents for Phoenix Gold TI2800.1
- Page 1 Amplifier Manual Manual del Amplificador Manuel del’amplifica teur Models: Ti2800.1, Ti21300.1 Features: Características: Caractéristiques: • Alta eficiencia de clase D Topología • High Efficiency Class D Topology • Topologie de classe D de gamme complète • Compact Size for Easy Installation •...
-
Page 2: Specifications
IMPORTANT: A power birth certificate is included for each amplifier. Ti2 amplifiers are conservatively rated and will exceed their RMS power rating shown here. All RMS power ratings and measurements are at 14.4 volts with no more than 1% THD. Phoenix Gold • www.phoenixgold.com... -
Page 3: Crossover Settings
Amplifier Owner’s Manual Crossover Settings All crossover frequency potentiometers have 41 detents or “clicks” so the end user can set the exact cross over frequency desired. SUBSONIC LOWPASS clicks (10~55Hz) (30~200Hz) Phoenix Gold • www.phoenixgold.com... - Page 4 “up front” subwoofer bass and resolve level of the low pass signal. subwoofer cancellation problems in certain installations. Each installation is different, slowly adjust and listen for best results. NOTE: This control is not compatible with the Phoenix Gold LPL44 level control. +12V SPEAKER OUTPUTS This must be connected to the fused positive terminal (+12V) of the car’s...
-
Page 5: Monoblock Power Amplifier
“up front” subwoofer bass and resolve level of the low pass signal. subwoofer cancellation problems in certain installations. Each installation is different, slowly adjust and listen for best results. NOTE: This control is not compatible with the Phoenix Gold LPL44 level control. +12V SPEAKER OUTPUTS This must be connected to the fused positive terminal (+12V) of the car’s... -
Page 6: System Tuning
LP frequency control is not set too low at the same time. is blown, check the power wire and also the amplifier for a short. If the short is in the amplifier itself, see your Phoenix Gold dealer. If no FREQUENT AMPLIFIER SHUTDOwN wITH AUTOMATIC RECOVERY: short is present, replace the fuse. - Page 7 “up front” bass subwoofer y resolver los problemas subwoofer cancelación en determinadas instalaciones. Cada NOTA: Este control no es compatible con el control de nivel Phoenix Gold instalación es diferente, ajuste lentamente y escuchar para obtener mejores LPL44.
- Page 8 “up front” bass subwoofer y resolver los problemas subwoofer cancelación en determinadas instalaciones. Cada NOTA: Este control no es compatible con el control de nivel Phoenix Gold instalación es diferente, ajuste lentamente y escuchar para obtener mejores LPL44.
- Page 9 SORTIES HAUT-PARLEUR +12V Sert à relier l’amplificateur aux haut-parleurs. Ti2800.1 l’impédance minimale Doit être relié à la borne positive protégée par fusible (+12 V) de la batterie est de 1 ohm. de la voiture. Le fusible doit être situé à moins de 18 pouces de la batterie.
- Page 10 Doit être relié à la borne négative de la batterie de la voiture ou boulonné sur un élément propre et non peint du châssis du véhicule. Remarque: Le Ti21300.1 dispose d’un ventilateur à vitesse variable situé sur le panneau d’extrémité pouvoir. Phoenix Gold • www.phoenixgold.com...
-
Page 11: Corrección De Problemas
Si el corto Muy bajo output: Chequear el control de fader del radio o el nivel de es en el amplificador, llévelo a su agente autorizado Phoenix Gold. Si no hay sensibilidad de input del amplificador. Asegurarse que el control de frecuencia corto, solo reemplace el fusible. -
Page 12: International Warranties
LIMITED WARRANTY ON AMPLIFIERS Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer in the United States of America only. Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction, Phoenix Gold will (at its discretion), repair or replace the defective product with new or remanufactured product at no charge.
