- Page 1 Front & rear Parking assist system PTS800V8 Blue LCD display and precise detection up to 0.01m Manual BRM061...
-
Page 2: Table Of Contents
Contents Important notice User's Manual Installation Manual Parking assist systems help to provide assistance when driving forward or reversing. Driving skills, Important notice ---------------------------------------- Brief installation diagram ---------------------------- such as slowing down, use of mirrors etc. are always essential. Disclaimer ----------------------------------------------- Packing list ---------------------------------------------- 1. -
Page 3: About The Product
Blue LCD display with precise detection up Voice alert to 0.01m/0.1ft Distance PTS800V8 is a front and rear parking assist system Self-test function Damaged sensor indication with blue LCD display. All the detachable sensors Voice / beep alert selectable are water-resistance and can be easily changed. -
Page 4: Voice And Volume Adjustment
Voice and volume adjustment Self-test function Turning ON/OFF voice alert 1. Once the ignition is turned on, the system will test the 4 front sensors E,F,G and H automatically. 1) All sensors are working. 2) Damaged sensors are detected. Beep three times Be...Be...Be... -
Page 5: Learning Function For Cars With Tow-Bar Or Spare
Learning function for cars with tow-bar or spare wheel How does the system work Driving forward (6 sensor) 1" Flash Ignition on, shift the gear from "N" to "R" and shift back in 1 second and repeat for 10 times. At the 10th time stay at "R" The display will flash 3 times then beep position for 6 seconds to achieve the learning function. - Page 6 Driving forward (8 sensor) Reversing +12V +12V +12V 0.81m/2.7ft 0.40m/1.3ft Stop(<0.30m/1.0ft) 1.21m/4.0ft 0.60m/2.0ft Stop(<0.30m/1.0ft) No beep Be--- Be---Be---...
-
Page 7: Attention
Attention Sensor maintenance Zigzag reversing False detection may occur in the following situations: Do not wash the sensor with squirt gun or swab them forcibly. Please wash car with low-pressure water. water. Please melt the ice with warm water when the sensors are covered by ice. - Page 8 Brief installation diagram Installation Manual Display...
- Page 9 Packing list Sensor installation Pls adjust the sensor angle according to sensor height and bumper angle, avoid detecting to ground. H > 40cm/1.3ft H < 60cm/2.0ft The actual sensor may vary from the image shown above Installation tools 0.9m /3.0ft 35cm/1.1ft <L1<...
- Page 10 H > 45cm/1.5ft H < 65cm/2.1ft < 45cm/1.5ft < 45cm/1.5ft < 45cm/1.5ft 2.5m /0.8ft Check the size of the hole saw packed in the product to be matching the diameter of the sensors before drilling any holes. 1.5m /0.5ft = 1/8L H <...
- Page 12 Display installation Power Reversing light + Check the size of the hole saw packed in the product to be matching the diameter of the sensors before drilling any holes.
- Page 13 Wire connection Function test after installation Display Function test is possible by E F G H A B C D holding a wooden board (0.3x 1m/1.0x3.2ft) standing at the front/ rear of the car, and drive the car forward and backward t o t e s t e a c h f u n c t i o n respectively as shown in this Pink...
- Page 14 Troubleshooting After installation, the display doesn’t work The display always shows 0.4/15.7ft~0. a) Are all wires connected properly? 6m/23.6ft. b) Is the ignition turned on? a) Are sensors mounted too low or detecting the c) Is the reverse gear selected or is the footbrake ground? pressed? b) Check whether the sensor is installed up-side-...
