HP Compaq nx6110 Specifications page 24

QuickSpecs
Technical Specifications
Output Power (for CKK)
Output Power (for
OFDM; power varies by
data rate)
Power Consumption
Power Management
Receiver Sensitivity
Antenna type
Range
Form Factor
Weight
Dimensions
Operating Voltage
Temperature
Humidity
Altitude
Configuration Utility
Intel PRO/Wireless Wireless LAN Standards IEEE 802.11b
2200BG 802.11b/g
WLAN
Interoperability
2
17.5 dBm +/- 1.5 dB
13.5 dBm +/- 1.5 dB
2
Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode: 248 mW (nominal)
Sleep mode: 20 mW (max)
ACPI compliant power management
802.11 compliant power saving mode
3
802.11a - 54 Mbps: -70 dBm; 802.11g - 54 Mbps: -72 dBm, 1 Mbps: -
94 dBm
High efficiency dual band antenna with polarization diversity, mounted
in the display enclosure
802.11 a – Typical
(@6 Mbps)
802.11 b – Typical
(@1 Mbps)
802.11 g – Typical
(@1 Mbps)
MiniPCI Type IIIA
0.035 lb (16 g)
0.19 x 2.00 x 2.35 in (4.8 x 50.95 x 59.75 mm)
3.3v
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
4
Choice of Configuration Utility:
•
•
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK
modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4. WLAN supplier's client utility is required for Cisco Compatible Extensions support.
WLAN may also be compatible with certain third-party software supplicants.
IEEE 802.11g
Wi-Fi certified
Cisco Compatible Exensions Program compliant
(details at http://www.hp.com/go/notebooks/wlan)
DA – 12135 North America — Version 16 — October 4, 2005
HP Compaq nx6110 Notebook PC
1000 feet – Outdoor Open Area
300 feet – Indoor, Office environment
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
32° to 122° F (0° to 50° C)
-14° to 158° F (-10° to 70° C)
10% to 90% (non-condensing)
5% to 95% (non-condensing)
0 to 15,000 ft (4,572 m)
0 to 40,000 ft (12,192 m)
Microsoft Windows XP Wireless Network Connection
Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
Page 24
