HP Compaq nx6110 Specifications page 21

QuickSpecs
Technical Specifications
Power Management
Manageability
NIC Device Driver Name Broadcom 440X 10/100 Integrated Controller
Drivers Available
Agere Systems AC'97 Form Factor
Modem
Power Management
Support
Approvals/
Certifications
Data Mode Capabilities
Fax Mode Capabilities
clauses 21-30)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and
100 Mbit/s
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
ACPI 1.1a compliant -- multiple power modes
Situation-sensitive features reduce power consumption
Wake-on-LAN from all Power-Managed States (configurable; Magic
Packet and Microsoft Wake-Up Frame)
PXE 2.0 Remote Boot
Statistics Gathering (RMON, Ethernet-like MIB, Ethernet MIB (802.3x,
clause 30))
Comprehensive diagnostic and configuration software suite
Windows XP
Windows 2000
DOS NDIS2 and ODI
MDC Daughtercard
APM Revision 1.2, ACPI
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21,
FCC Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22,
Australian ACA, CE Mark, Other Countries
56K modem (a-law, mu-law)
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
V.34 (file date: 10/96)
Optional symbol rates:
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J
TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
DA – 12135 North America — Version 16 — October 4, 2005
HP Compaq nx6110 Notebook PC
Page 21
