Asante 1012 Installation Manual

Ethernet hub
Hide thumbs Also See for 1012:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
A s a n t é H u b
1 0 1 2
I n s t a l l a t i o n
G u i d e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1012 and is the answer not in the manual?

Questions and answers

Related Manuals for Asante 1012

Summary of Contents for Asante 1012

  • Page 1 A s a n t é H u b 1 0 1 2 I n s t a l l a t i o n G u i d e...
  • Page 2 Printed in the United States of America. T r a d e m a r k s Asanté Technologies, MacCon+, AsantéHub 1012, AsantéView, and 10T MAU are trademarks of Asanté Technologies, Inc. Apple, AppleTalk, EtherTalk, TokenTalk, AppleShare, and Macintosh are registered trademarks of Apple Computer, Inc.

  • Page 3: Table Of Contents

    Product Overview xi Features xii AsantéView xiii Chapter 1. 1-1 Quick View Front Panel - Quick View of Your Network AsantéHub 1012 front panel Reset Button Interpreting LEDs Rear Panel - Convenience in Connections Use of the 3-In-1 Uplink Hub ID...
  • Page 4 What Next? 1-26 Step 7. Making Network Connections 1-26 Network Connections to Thin Ethernet 1-27 Step 8. Connections for AsantéView Management System (AMS) Link With Multiple Hubs (Out-of-Band Network Management) 1-31 What You Need 1-31 How to Do It 1-32 The Next Step 1-34 Chapter 2.
  • Page 5 Can You Use Existing Wiring? 3-12 Site Requirements for Wiring 3-12 Site Requirements for Hubs 3-12 Constructing RJ-45 Extension Cables 3-13 Chapter 4. Interpreting the LEDs Start-up Display Normal Operational Display General Guidelines Wiring Problems and Solutions Workstation Problems and Solutions Hub Problems and Solutions Traffic Patterns Network Troubleshooting Software...
  • Page 6 Figures Figure 1-1. Front Panel Figure 1-2. Front Panel Features Figure 1-3. Rear Panel Figure 1-4. AsantéHub Rear Panel (left) - TELCO and Network Connections 1-6 Figure 1-5. AsantéHub Rear Panel (right) - TELCO and Network Connections 1-7 Figure 1-6. The Installation Process 1-13 Figure 1-7.
  • Page 7 Crossover RJ-45 Cable Tables Table 1-1. Interpreting Hub-Level Status Indicators 1-4 Table 1-2. Interpreting Port-Level Status Indicators Table 1-3. AsantéHub 1012 Factory Default Settings 1-9 Table 2-1. LED Status Indications Table 2-2. AsantéHub Connectors Table 2-3. AsantéHub Switches and Switch Settings Table 3-1.

  • Page 8: About This Manual

    About This Manual This manual describes the AsantéHub 1012 intelligent Ethernet hub and shows you how to create a 10BaseT local area network (LAN) using the hub. Use the following list to look up specific subjects. Overview of your AsantéHub See Chapter 1, "Quick Start."...

  • Page 9: Other Manuals In This Product Family

    Other Manuals in This Product Family If you purchased the Simple Network Management Protocol (SNMP) option, you need to perform some software configuration before you can communicate with the hub over a TCP/IP network; see the manual, AsantéView Users' Guide for Windows, In-Band.

  • Page 10: Technical Support

    Asanté Technologies, Inc. 821 Fox Lane San Jose, CA 95131 (800) 432-7511 FAX: (408) 734-4864 AppleLink address: ASANTE.TECH Internet Mail Address: tech@asante.asante.com Please have the following information when you contact us: • Model # • PROM revision level SNMP Option Users...
  • Page 11 Information about the technical POC, as follows: Name: Title: Mailing Address: Phone Number: Net Mailbox: NIC Handle (if any): Mnemonic name for the network (to 12 characters): Network geographic location and responsible organization establishing the network: Network type: Research/Defense/Government-non- Defense/Commercial If you encounter any problems, call Asanté...

  • Page 12: Product Overview

    Product Overview The AsantéHub 1012™ is a compact, powerful LAN hub that lets you create high-speed Ethernet networks over ordinary, unshielded twisted-pair (UTP) telephone wire. AsantéView network management software lets you manage the AsantéHub 1012 network remotely, with graphical software that is intuitively easy to use.

  • Page 13: Features

    Features AsantéHub 1012 offers outstanding technical features in a compact, modern design: • Twelve 10BaseT Ports — Up to twelve network devices can be connected to a single AsantéHub (thirteen, in a standalone configuration). • Auto-Sensing Network Ports — Auto-sensing network ports with AUI, BNC and RJ-45 connectors support thick, thin or 10BaseT wiring.

  • Page 14: Asantéview

    • Detailed Front Panel Indicators — The LED indicators of the AsantéHub indicate: Functionality of CPU and SNMP option AsantéView message status Out-of-band and in-band link functionality Port partition status (automatic or operator- commanded) for link and device ports Port link status and receive activity for link and device ports Presence of the following network errors: late collisions, misaligned packets/CRC errors,...
  • Page 15 • Monitors network performance and displays comprehensive statistics in three easy-to-read formats: tables, line graphs, and bar charts • Automatically responds to threshold violations by generating traps, partitioning ports, and/or paging for assistance • Protects network security with bi-level password structure •...

  • Page 16: Quick View

    3-In-1 Uplink, the Reset function, and Hub ID Front Panel - Quick View of Your Network The status LEDs and the twelve modular 10BaseT ports of the AsantéHub 1012 are located on the front panel (Figure 1-1). UTILIZATION 10BASE-T PORTS...

  • Page 17: Asantéhub 1012 Front Panel

    Chapter 1 AsantéHub 1012 front panel Figure 1-2 illustrates the Reset button and the status LEDs on the front panel. BLINKING = CPU functions are normal. PARTITION SNMP/Uplink/ Ports 1-12 PWR (power) Individual LEDs indicate partitioning (automatic or operator-commanded) of ON = power on.

  • Page 18: Reset Button

    Quick Start Reset Button The reset button is located at the far left of the front panel. It resets all CPU functions, including communication and network management. It does not interfere with traffic through the hub. Interpreting LEDs The LEDs on the front panel can be thought of as two separate groups: •...

  • Page 19: Table 1-1. Interpreting Hub-Level Status Indicators

    Chapter 1 Table 1-1. Interpreting Hub-Level Status Indicators Power/CPU Status LED KEY Power Off, CPU Off Power On, CPU Normal FLASHING Power On, CPU Failure Utilization % Utilization LED Interpretation +0-1% +1-3% +3-5% +5-10% +10-20% +20-30% LED KEY +30-50% +50-65% FLASHING +65%...

  • Page 20: Table 1-2. Interpreting Port-Level Status Indicators

    Quick Start Warnings Warning LED Interpretation Late Collision Misaligned/CRC Error LED KEY Runt/fragmented Packets FLASHING Short event/Missing SFD Wanings may apply to any port on the hub. Use AsanteView (Port Control for this hub) to isolate. More than one warning type may be present. Table 1-2.

  • Page 21: Rear Panel - Convenience In Connections

    Chapter 1 Rear Panel - Convenience in Connections The rear panel of the AsantéHub is shown in Figure 1-3, below. It provides TELCO device connections, 3-in-1 Uplink (network) connections, two LED status indicators for the uplink, an RS-232 port for PC or terminal connection, and the dedicated AMS link connectors, as well as the fan and power hardware.
  • Page 22 Quick Start Partition and Traffic LEDs - Through/End switch - Duplicate the functions of the Terminates the AMS Link Partition Uplink and used in out-of-band network Link/Receive Uplink LEDs on management. Set up for the front panel (see previous pass-through hubs; down to section).

  • Page 23: Use Of The 3-In-1 Uplink

    Chapter 1 Use of the 3-In-1 Uplink The 3-In-1 Uplink includes the rear panel RJ-45 IN/OUT, BNC, and AUI ports at the rear of the hub. The default setting for primary link selection is auto- selection (see “Factory Defaults,” in this chapter.) On auto-select, the hub uses the AUI, 10BaseT, and BNC ports, in that order, if more than one uplink connection exists.

  • Page 24: Table 1-3. Asantéhub 1012 Factory Default Settings

    Quick Start Table 1-3. AsantéHub 1012 Factory Default Settings Default To Modify All ports have Link Integrity testing If you are using AsantéHub with a pre- enabled. Jumper JP8 is set OUT to 10BaseT device, disable Link Integrity. enable Link Integrity testing on the 3- (You will not be able to obtain link in-1 Uplink.
  • Page 25 Chapter 1 Table 1-3, cont. AsantéHub 1012 Factory Default Settings Serial Port 0 (AMS Link): 9600 bps, Cannot be modified. 8 data bits, 1 stop bit, no parity Serial Port 1 (RS-232 port): 9600 bps, For a PC, reconfigure in terminal menu 8 data bits, 1 stop bit, no parity.

  • Page 26: Figure 1-14. Single-Hub Network With Asantéview

    Chapter 1 Step 6. Connecting the Network Management Station (Out of Band) Now, connect the network management station that runs AsantéView. The network management station is connected to a hub at the end of the AMS Link. If you are installing a standlone hub, this step creates a departmental network with network management, as illustrated below.
  • Page 27 Quick Start If you are installing a multiple-hub network, you will go on to connect the AMS link and network connections. In this case, also note that the network management station must be connected to the hub at the end of the network path.

  • Page 28: Figure 1-16. Dip Switch Legend

    Chapter 1 Switch Settings Key DOWN Not relevant to this connection Figure 1-16. DIP Switch Legend Note: Because the AsantéHub's rear panel switches are very small and close together, whenever switch settings are shown, the position of both switches is identified (or a greyed out box is shown to represent the fact that a given switch setting is not important for what is being discussed in this section).

  • Page 29: Figure 1-17. Out-Of-Band Ams (Asantéview Management System ) Link Connections To Pc And Hub

    Spare Fuse in Fuse Holder DOW N=TERM INAL TRAFFIC UPLINK To PC Comm Port RS232 RS232 ASANTE DB9 to DB9 SERIAL CABLE DIP Switches 2A/250V Slow Blow Fuse Replace Only With Fuse of Same Rating RS485 THROUGH RS232 IN or OUT...

  • Page 30: What Next

    Chapter 1 DIP Switches 2A/250V Slow Blow Fuse Replace Only With Fuse of Same Rating RS485 THROUGH RS232 IN or OUT RJ21 10 BASE-T PORTS AMS LINK PARTITION UP=PC 3-IN-1 Spare Fuse in Fuse Holder TRAFFIC DOW N=TERM INAL UPLINK DIN-8 RJ45 To MAC...

  • Page 31: Network Connections To Thin Ethernet

    Quick Start This section describes network connections via the BNC port, to a thin Ethernet backbone, as illustrated below. For other network configurations, see Chapter 2, “Hardware Description.” Figure 1-19. Backbone network with AsantéView Network Connections to Thin Ethernet The most common network connection is the thin Ethernet backbone network.

  • Page 32: Figure 1-20. Network Connections - Thin Ethernet Backbone

    Chapter 1 2 A/ 2 5 0 V S low Blow Fus e Re pla c e O nly Wit h Fus e of S a me Ra t ing RS485 THROUG RS232 IN or OUT RJ21 10 BASE-T PORTS AMS LINK PARTITION 3-IN-1 UPLINK...

  • Page 33: Figure 1-21. Connecting A Hub To An Existing Ethernet Backbone

    Quick Start Hub #3 Hub #1 Hub #2 2. Attach terminated cable to Hub #2. Terminator 1. Remove Terminator. 3. Attach T-connector to Hub #3. Figure 1-21. Connecting a Hub to an Existing Ethernet Backbone The AsantéHub should already be powered on and working normally.
  • Page 34 Chapter 1 BNC port and ensure that the weight of the cable will not twist the T-connector into contact with the AUI cable connector. When you connect the hub to the backbone, traffic over the hub should begin immediately (if the network is in use). You will see activity on the Link/Receive Uplink LED (this should be on, indicating the connection through the backbone).

  • Page 35: Step 8. Connections For Asantéview Management System (Ams) Link With Multiple Hubs (Out-Of-Band Network Management)

    Quick Start Step 8. Connections for AsantéView Management System (AMS) Link With Multiple Hubs (Out-of-Band Network Management) If you have more than one hub in your network, use this section to install the AMS link. This dedicated link interconnects hubs for out-of-band network management in AsantéView.

  • Page 36: Figure 1-23. Wiring For Network Management Out-Of-Band (Nms On Rs-232 Port)

    Chapter 1 Connect a straight-through RJ-45 extension cable from a rear panel AMS Link port on the first hub to a rear panel AMS Link port on the second hub. See the figure below. Terminate the hub at each end of the daisy-chain by flipping rear panel Through/End DIP switch down (closed), unless you used the other AMS Link port to connect to the network management station.

  • Page 37: Figure 1-24. Wiring For Network Management Out-Of-Band (Nms On Ams Link Port)

    Quick Start 2 A/ 2 5 0 V S low Blow Fus e THROUGH Re pla c e O nly Wit h Fus e of S a me Ra t ing RS485 RS232 AMS LINK IN or BNC RJ21 10 BASE - T PORTS PARTITION UP=PC 3 - IN - UPLINK...

  • Page 38: The Next Step

    Chapter 1 The Next Step Congratulations! — this completes your hardware installation. Now you can: • Go to Chapter 2 to view details of the front and rear panel features and learn more about AsantéHub hardware. • Go to Chapter 3 to learn more about network installation. •...

  • Page 39: Interpreting Leds

    Chapter 2. Hardware Description The AsantéHub™ is an easy to use and powerful LAN hub that lets you create high-speed Ethernet networks over ordinary, unshielded twisted-pair telephone wire. AsantéView network management software, when included, lets you manage the LAN from an easy-to-read graphical display. With the SNMP option, you can manage AsantéHub networks from a centralized SNMP-based management console.

  • Page 40: Figure 2-1. Asantéhub Front Panel Leds During Normal Operation

    1 3 5 10 20 30 50 65+ 2 3 4 6 7 8 9 10 11 12 S N M P U P LIN K ASANTE * * * * * * * * SNMP MSG RESET Late Collision...

  • Page 41: Table 2-1. Led Status Indications

    Hardware Description Table 2-1. LED Status Indications State Meaning PWR (power) Green Power to this unit is on. Power to this unit is off. Green, blinking CPU is functioning normally. ~1x/sec. Reset process, power off, or CPU not working. SNMP Green SNMP daughterboard is installed and SNMP daughterboard is not installed or...
  • Page 42 Chapter 2 Link/Receive: 14 separate LEDs: All LEDs: Power to unit is off. SNMP 2 Green, on No traffic over the SNMP link. Or, Link Integrity test disabled. Green, blinking Traffic over the SNMP link. Or, Link Integrity test disabled. Uplink Green, on No traffic over the uplink.

  • Page 43: Connectors And Their Usage

    9 10 11 12 30 50 65+ SNMPUPLINK ASANTE Asante Hub 1012 RESET LINK/RECEIVE COLLISION 2 A/ 2 5 0 V S low Blow Fus e Re pla c e O nly Wit h Fus e of S a me Ra t ing...

  • Page 44: Table 2-2. Asantéhub Connectors

    Chapter 2 Table 2-2. AsantéHub Connectors Connector Description Front panel 10BaseT Twelve modular RJ-45 jacks for connections connectors to network devices. Also support connections between hubs for optional in- band SNMP-based network management. Support straight-through RJ-45 cables, as defined in Appendix B. Thirteenth device port Rear panel RJ-45 IN, BNC and AUI ports can be used as device ports only in a...

  • Page 45: Switches

    Hardware Description RS-232 (DB-9) connector Supports terminal, PC or MAC, or modem for dial-up network management. Use straight-through RS-232 cable for terminal or PC; use crossover (null modem) cable for modem connection. DB-9 to DB-25 converter will be required for connection to DB-25 comm ports.

  • Page 46: Cabling Configurations

    Chapter 2 Cabling Configurations This section describes cabling configurations for the most common AsantéHub applications. • Hubs can be interconnected via the RJ-45, BNC, or AUI ports (the 3-In-1 Uplink) on the rear panel. Redundant physical links can also be installed. See the following four sections. •...

  • Page 47: Figure 2-3. Interconnecting Hubs Via Rj-45 Ports

    Hardware Description • Connect the next extension cable being between the rear panel RJ-45 OUT port of hub #2, and a front panel port on hub • Continue for additional hubs. The second method can be used only if the network chain is ending (the daisy chain does not need to be continued).

  • Page 48: Interconnecting Hubs Via The Bnc Port

    Chapter 2 Interconnecting Hubs via the BNC Port The BNC port is typically used to interconnect hubs on a thin Ethernet backbone. The backbone cable must be properly terminated, and the network configuration must not exceed maximum distance length or device count guidelines as given in the 802.3 10Base2 specifications.

  • Page 49: Interconnecting Hubs Via The Aui Port

    Hardware Description Interconnecting Hubs via the AUI Port The AUI port is typically used to interconnect hubs using a thick Ethernet backbone, as illustrated in the figure below. It can also be used to interconnect hubs using a variety of media, such as fiber optic, unshielded twisted-pair, or broadband, depending on the external transceiver you connect to the port.

  • Page 50: Figure 2-6. Interconnecting Hubs On Thick Ethernet Backbone

    Chapter 2 2 A/ 2 5 0 V S low Blow Fus e Re pla c e O nly Wit h Fus e of S a me Ra t ing RS485 THROUG RS232 RJ21 10 BASE-T PORTS IN or OUT AMS LINK PARTITION 3-IN-1 UPLINK...

  • Page 51: Cabling For Redundant Links

    Hardware Description Cabling for Redundant Links Redundant links may be easily installed. For example, twisted-pair wiring might be used as a backup to a thin Ethernet backbone, as illustrated below. CAUTION: When using Thin and Thick Ethernet cabling, make sure that the T-connector on the BNC port does not touch the AUI connector.

  • Page 52: Cabling A Local Terminal/Emulator To The Hub

    Chapter 2 Cabling a Local Terminal/Emulator to the Hub To connect a local terminal (or PC running Windows’ terminal emulation) to the hub, use the rear panel RS-232 connector. • Set the PC/Terminal switch to Terminal. • The setting of the Through/End switch for AMS Link termination is irrelevant to the terminal connection (though not to the AMS Link connection, if any).

  • Page 53: Figure 2-9. Nms (Pc Oob) Connections To A Stand-Alone Hub

    Hardware Description • If you use the RS-232 port, the Through/End switch setting is irrelevant to the network management station (though not to the AMS Link). The PC/Terminal switch must be set to PC. The network management station can be placed anywhere in the network.

  • Page 54: Hub (Out-Of-Band)

    PARTITION UTILIZATION 10BASE-T PORTS 50 65+ SNMP UPLINK ASANTE RESET AsantéHub 1012 LINK/RECEIVE COLLISION RJ45 RJ45 To PC Figure 2-11. Network Management Station Connections to Hub (In-Band) 2-16...

  • Page 55: Cabling The Ams Link (Out-Of-Band Network Management Link)

    Hardware Description Cabling the AMS Link (Out-of-Band Network Management Link) To interconnect hubs for out-of-band network management, use the AMS (AsantéView Management System) Link ports at the right rear of the hub. If only one of the jacks is used on a hub, the Through/End switch on the rear panel must be set to "End"...

  • Page 56: Overview

    This chapter discusses 10BaseT, introduces terms used in discussing network configurations, summarizes configuration guidelines for the 10Base media types supported by the AsantéHub 1012, and discusses wiring standards and site requirements for a 10BaseT network. About 10BaseT 10BaseT is a communications standard for twisted-pair Ethernet, defined by the Institute of Electrical and Electronic Engineers (IEEE).

  • Page 57: How 10Baset Uses Existing Telephone Wiring

    Chapter 3 How 10BaseT Uses Existing Telephone Wiring Buildings are usually wired for telephones in a star topology: wires run from one or more central locations, called wiring closets, to wall jacks in each office. A small building may have only one wiring closet; large buildings often have multiple wiring closets which are interconnected.

  • Page 58: Determine Application Needs

    Network Planning For small installations, the network manager’s duties may only require a few hours a week. For larger installations, the network manager’s position may be a full-time job. Determine Application Needs Think about how people on the network plan to use it. Will they be printing, exchanging mail, or transferring files steadily, or occasionally throughout the day? Will some users regularly access a multi-user database, transfer large graphics or CAD files, or launch applications from a server?

  • Page 59: Create A Network Map

    Chapter 3 To evaluate sites, see "Site Requirements for Hubs" and "Site Requirements for Wiring." To evaluate existing wiring, see "Standards for Network Wiring" and "Tracing Existing Wire Routes." Create a Network Map Consider creating a network map as a visual record of your network configuration.
  • Page 60 Network Planning A simple network log may contain the following information for each device on the network: • Name • Description • Device number • Hub port number A more detailed log may contain: • Serial number of each device •...

  • Page 61: Common Network Configurations

    Chapter 3 Common Network Configurations Single-Hub Star Network The simplest AsantéHub network consists of a single hub with attached devices (nodes). This configuration yields thirteen device ports, using the rear panel RJ- 45 IN port in addition to the twelve front-panel device ports. Only twisted-pair wiring is used.

  • Page 62: Backbone Network

    Network Planning • Reliability compared to the backbone network; if there is an accidental break in the wire, only service on the affected branch will be interrupted . Figure 3-3. Tree Network Backbone Network A backbone network suspends hubs from a linear length of cable, either thin or thick Ethernet cable.

  • Page 63: Figure 3-4. Thin Ethernet Backbone Network

    Chapter 3 • Simple topology, because all of the hubs are connected in a single line (the linear, or bus, configuration) • Better noise immunity because coaxial cable (either thick or thin) is shielded, vs. unshielded twisted-pair • Physical strength; coaxial cable is stronger than unshielded twisted-pair.

  • Page 64: 10Baset Network Specifications

    Network Planning Figure 3-5. Thick Ethernet Backbone Network 10BaseT Network Specifications This section provides an overview of the IEEE 802.3 specifications for 10BaseT network configurations using thick, thin, and twisted-pair wiring. Thick, thin, and twisted-pair network requirements are based on the IEEE 802.3 (Ethernet) specification for local area networks.

  • Page 65: Table 3-1. Ieee 802.3 Network Specifications

    Chapter 3 Table 3-1. IEEE 802.3 Network Specifications Thick Thin Twisted-Pair (10Base2) (10Base5) (10BaseT) Media Thick coaxial cable Thin coaxial cable Unshielded twisted- pair External and external devices transceiver required Topology Star, Tree Max. 500 meters 185 meters 100 meters Segment (1625 feet) (605 feet)

  • Page 66: Standards For Network Wiring

    Network Planning • If the AsantéHub is connected to an 802.3 backbone, and you have other workstations on your network backbone, remember to consider these workstations in your maximum data transmission path. • When interconnecting tree networks over a backbone (which uses the AUI or BNC ports) and staying within the maximum length and node count limits of the port type you use, it is possible to use all fourteen ports of the AsantéHub at the same...

  • Page 67: Can You Use Existing Wiring

    Chapter 3 Can You Use Existing Wiring? You may be able to use existing wiring with your installation. All twisted-pair wire used between hub and hub, or hub and device, should conform to the IEEE Standard 802.3 Draft 10, Section 14.4, Media Specification. In general, this is ordinary, unshielded twisted-pair wiring.

  • Page 68: Constructing Rj-45 Extension Cables

    Network Planning • The location should not be near sources of electrical interference, such as motors or heavy-current switches. Constructing RJ-45 Extension Cables To make extension cables, first measure the necessary lengths, remembering not to exceed a length of 100 meters. Then have the cables constructed according to the pinouts in Appendix C, ”Pinouts and Cable Specifications.”...

  • Page 69: Interpreting The Leds

    Chapter 4. Troubleshooting The AsantéHub 1012 does not require any routine maintenance. There are no user serviceable parts in the AsantéHub. If you cannot identify and correct a fault using the testing procedures described below, contact Technical Support. See “Technical Support” in this manual.

  • Page 70: Table 4-1. Asantéhub Leds - Normal Status

    Chapter 4 Table 4-1. AsantéHub LEDs - Normal Status L E D Normal Meaning Condition P W R Green, ON Green: Power is ON. C P U Green, BLINKING BLINKING: CPU is present and operating normally. S N M P Green ON Green: SNMP daughter board is installed.

  • Page 71: General Guidelines

    Troubleshooting General Guidelines Factors affecting network performance include wiring problems, software or hardware problems on the device or network interface card, inclusion of pre-10BaseT devices on a 10BaseT network, and incorrect hub configuration. Wiring Problems and Solutions • Degraded network performance. Check to see whether stranded wire has been used.

  • Page 72: Workstation Problems And Solutions

    Chapter 4 • Unable to establish link. Make sure that physical connections are in place, tightly attached, properly terminated, and connecting the appropriate devices. See Chapter 1, "Quick Start " for wiring for star and thin backbone networks. See Chapter 3: "Network Planning,"...

  • Page 73: Hub Problems And Solutions

    Troubleshooting Hub Problems and Solutions Note: Hub hardware failure is not likely, if it has passed its self-test at startup or reset • After changing hub configuration, part of Restore hub to the initial factory settings (see the network does not work. “Default Settings”...

  • Page 74: Network Troubleshooting Software

    Chapter 4 Network Troubleshooting Software Below is a list of network troubleshooting applications that Asanté has found useful. This list is for informational purposes only, as a service to our customers, and does not constitute an endorsement by Asanté Technologies, Inc. The list contains the product name, the manufacturer, the platform that the application runs on, and the application type (network analyzer or protocol analyzer).
  • Page 75 Link Integrity test for the port connected to that device. First check with the vendor to make sure disabling the Link Integrity will make the card compatible with the AsantéHub 1012. Then follow these steps: Determine which port number the workstation is wired to on the AsantéHub.
  • Page 76 Appendix A A -2...
  • Page 77 Appendix B. Technical Specifications This appendix describes the technical features of the AsantéHub 1012. Standards Supported: IEEE 802.3 Ethernet specifications for thick (10Base5), thin (10Base2), and unshielded twisted-pair (10BaseT) media. Data Rate: 10 Mbps Maximum Cable Distances: 10BaseT (UTP) 100m (328 ft.) 10Base2 (thin) 185m (605 ft.)
  • Page 78 Appendix B Option Slot: Accepts SNMP module or future internetworking devices Mounting: Desktop, Rack (with bracket), or Wall (with bracket) Physical Dimensions: 10”L (25.4 cm) x 2.2” H (5.9 cm) x 16”W (40.6 cm) Weight: Approx. 6 lbs. (2.73 kg) °...

  • Page 79: Appendix C

    Appendix C. Pinouts and Cable Specifications RJ-45 to RJ-21 Pinouts (Amphenol to Modular Jack) The Amphenol modular 50-pin connector establishes connections to the 8-pin modular jack through the network (hub) and distribution (house) punch-down blocks as illustrated below. Wire jacket colors may vary. RJ-45 66 Type RJ-21 Connector...

  • Page 80: Rj-45 Modular Jack To Wall Jack Pinouts

    Appendix C 25242322212019181716151413121110 9 8 7 6 5 4 3 2 1 50494847464544434241403938373635343332313029282726 50-pin cable connector Hub punch-down block House punch-down block 1 2 3 6 8-pin modular jack Figure C-2. Single Device Link - Amphenol Connector to 8-Pin Modular Jack RJ-45 Modular Jack to Wall Jack Pinouts These pin numbers are for an Asanté...

  • Page 81: Rj-45 To Rj-45 Extension Cables

    Pinouts & Cable Specifications RJ-45 to RJ-45 Extension Cables RJ-45 extension cables consist of two IS0 8877 8-pin modular jacks (RJ-45) on a ≤ 100 meter length of 24-gauge, solid conductor, unshielded twisted-pair wiring. These pinouts describe the straight-through RJ-45 extension cable used in all the RJ-45 ports on the hub.

  • Page 82: Rj-45 To Rj-45 Crossover Cable

    Appendix C RJ-45 to RJ-45 Crossover Cable This cable may be used to connect two 10BaseT compatible devices (e.g., hubs) or to connect hubs using two front-panel ports. Figure C-6. Crossover RJ-45 Cable Note: This manual assumes that straight-through cabling is used for all applications, except where specifically noted.

  • Page 83: Db-9 Pinouts

    Pinouts & Cable Specifications DB-9 Pinouts D B - 9 Name Direction Pin # DCD- Output (from AsantéHub 1012) Output (from AsantéHub 1012) Input (to AsantéHub 1012) DTR- Input (to AsantéHub 1012) -------- Output (from AsantéHub 1012) Input (to AsantéHub 1012)

  • Page 84: Glossary

    The family name for all of Asanté Technology, Inc.'s networking products. A registered trademark of Asanté Technology, Inc. auto-sensing AsantéHub 1012 capability to sense physical links present on the 3-in-1 ports (hub uplinks). backbone The major interconnecting bus in a network. Provides interconnection among subnetworks.
  • Page 85 G l o s s a r y b/s or bps Bits per second. b u s A network topology that uses a single, linear run of cable to connect all the devices in the network. Each device in the network is typically connected to the main ("backbone") cable by means of a drop cable.
  • Page 86 G l o s s a r y E t h e r n e t A network communications system developed and standardized by DEC, Intel, and Xerox, using baseband transmission, CSMA/CD access, logical bus topology, and coaxial cable. It defines a physical medium (the cable) and the recommended method of packet signaling (placing data on that cable type).
  • Page 87 G l o s s a r y IP address Internet Protocol address. Internet Protocol is a network layer protocol developed with the Transmission Control Protocol. The address is the unique identifier of a device connected to such a network using the TCP/IP protocol. interrupt request An interruption in microprocessor activity provided in order (IREQ or IRQ)

  • Page 88: Star Network

    Electronic isolation of an Ethernet device from network communications. partition uplink A front panel LED on the AsantéHub 1012; it reflects the partition status of the uplink to the hub. physical layer Layer 1, the lowest layer in the OSI model; it provides the transparent transmission of bit streams, including relaying through different media.

  • Page 89: Tree Network

    This type of Ethernet cable is 5mm in diameter and can cable connect network stations over a distance of 300 meters. Also known as 10Base2 cable. Through/End Rear panel DIP switch on AsantéHub 1012; terminates switch AMS Link (dedicated out-of-band network management) connection. topology The physical layout of devices and links in a network.

  • Page 90: Index

    Index 10BaseT B-1 SNMP write community 1-10 10BaseT, what is it? SYS contact Configuration 3-in-1 Uplink, guidelines SYS contact 1-10 5-4-3 rule 3-10 Default settings AMS link.i.Configuration AMS link port configuration 1-10 RS-232 port Configuration RS-232 port configuration 1-10 Default settings, AsantéHub Dimensions AC power source, for installation 1-14...
  • Page 91 I n d e x Installation AC power 1-14 AMS link connections 1-12 device connections 1-12 electrical interference 1-14 MAC address host connections 1-12, 18 Modem dial string, default setting 1-10 host connections to hub 1-20, 21 hub location 1-14 humidity requirements 1-14 network connections (BNC) 1-12, 26...
  • Page 92 I n d e x Rear panel Rear panel features Rear panel, network connections Redundant link selection, setting priorities 1-9 Reset button RJ-45 rear panel ports, guidelines Serial port 1 (RS-232), default settings 1-10 SFD (Start Frame Delimiter) Site requirements 1-14 Site Requirements 3-12 SNMP read community, default setting 1-10...
