FriendlyNET 7000 Series
Gigabit Ethernet Switches
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FriendlyNET 7000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Asante FriendlyNET 7000 Series

  • Page 1 FriendlyNET 7000 Series Gigabit Ethernet Switches User’s Manual...
  • Page 2: Copyright Notice

    Copyright Notice Trademarks Asanté Technologies and FriendlyNET are trademarks of Asanté Technologies, Inc. Ethernet is a registered trademark of the Xerox Corporation. All brand names and products are trademarks or registered trade- marks of their respective holders. FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3: Table Of Contents

    About This Manual ...iii Chapter Contents ... iv Document Conventions ... iv Introduction ... 1-1 Introducing the FriendlyNET 7000 Series ... 1-1 Model Numbering Convention ... 1-2 Configuration Options ... 1-2 Features ... 1-3 Performance Features ... 1-4 Switching Technology ... 1-4 Switch Acts as a Bridge Between Network Segments ...
  • Page 4 Cabling Requirements ... 2-8 Connecting Network Devices ... 2-9 Connecting a Computer to the Switch ... 2-9 Connecting a Hub or a Switch to the Asanté Switch ... 2-10 Connecting a Hub with No Uplink Port to the Switch ... 2-10 Cascading Multiple FS7000 Switches ...
  • Page 5: About This Manual

    This manual describes the complete line of FriendlyNET 7000 Series Gigabit Switches. The manual often focuses on two models: FS7108 — eight-port 10/100Mbps Fast Ethernet switch plus one-port Gigabit module FS7016 — sixteen-port 10/100Mbps Fast Ethernet switch with two expansion slots The FS7108 model is fixed in a single configuration.
  • Page 6: Chapter Contents

    7000 Series Gigabit Switches, their features and switching technology Chapter 2, “Installation,” describes the components and explains how to install, mount, and apply power to FriendlyNET 7000 Series Gigabit Switches Chapter 3, “LED Indicators,” describes how to interpret the LEDs on FriendlyNET 7000 Series Gigabit Switches Appendix A, “Troubleshooting,”...
  • Page 7: Introduction

    Introducing the FriendlyNET 7000 Series Thank you for purchasing an Asanté FriendlyNET 7000 Series Gigabit Switch. FriendlyNET 7000 products are unmanaged 10/100 Fast Ethernet switches which provide built-in or optional Gigabit Ethernet connectivity. These switches are designed to address increasing network bandwidth needs and to accommodate future network expansion.
  • Page 8: Model Numbering Convention

    Introduction A Media Independent Interface (MII) slot is built in to the back panel of all 7000 Series Switches. An Asanté 100 FX MII module can easily be plugged in to allow for 100Base-FX connections. Model Numbering Convention Model numbers for the Asanté FriendlyNET family of switches adhere to the following convention: The first digit identifies the series number...
  • Page 9: Features

    16-port 10/100M switch + 2 Gigabit modules Features The FriendlyNET 7000 Series Gigabit Switch has the following features: Compact size — designed for small to large workgroups in space- limited areas; installs on desktop or in a standard 19-inch equipment...
  • Page 10: Performance Features

    (10Mbps or 100Mbps) workgroups, or as a segmentation device for larger congested networks Performance Features FriendlyNET 7000 Series Switches have the following performance features: Data forwarding rate at 100% of wire-speed, or 148,800pps at 100Mbps, 14,880pps at 10Mbps for 64-byte packets Data filtering at 100% of wire-speed...
  • Page 11: Fast Ethernet And Gigabit Ethernet Technology

    This prevents a device from blocking the network by transmitting continuous data streams or extra-long packets. The FriendlyNET 7000 Series Switch supports store-and-forward switching. If the speeds are different, such as for a 10Mbps workstation connected to a 100Mbps server, the switch will buffer and read the entire packet, perform a data validity check, then forward the packet at the new speed.
  • Page 12 Introduction Page 1-6...
  • Page 13: Installation

    This chapter describes the components and explains how to install, mount, and apply power to your FriendlyNET 7000 Series Gigabit Switch. It contains the following sections: Package Contents Components Expansion Modules 100 FX MII Module Mounting Configurations Cabling Requirements Connecting Network Devices...
  • Page 14: Components

    Installation Components This section describes the front- and back-panel layouts of the FS7108 and FS7016 Switches. The only control on the front panel is the uplink push-button switch. The only control on the rear panel is the power switch. The LED indicators are described in detail in Chapter 3.
  • Page 15: Fs7016 Base Unit

    Figure 2-4 FriendlyNET 7016 back panel Expansion Modules This section describes the two optional expansion modules that can easily be added to FriendlyNET 7000 Series Switches, and gives instructions for their installation. Gigabit SX XP Module Each Asanté Gigabit SX expansion module adds a 1,000Mbps port, for connection to a high-speed server or the corporate backbone.
  • Page 16: 10/100 8-Port Xp Module

    Installation To install the Gigabit SX XP Module: Power down the unit. Remove the metal cover from the front of an empty expan- sion slot (located on the Switch’s front panel) using a small Phillips screwdriver. Align the bottom of the Gigabit module with the rails on the inside of the expansion slot.
  • Page 17: 100 Fx Mii Module

    Option Slot B, the ports on the module will correspond to LED indicators B1–B8. 100 FX MII Module All FriendlyNET 7000 Series Gigabit Switches include one Media Independent Interface (MII) slot on the rear panel of the unit which allows for connection to 100Base-FX media.
  • Page 18: Mounting Configurations

    Connect the installed MII module to your network, follow- ing the instructions below. Mounting Configurations This section describes how to mount the FriendlyNET 7000 Series Gigabit Switch on a desktop or install it in an equipment rack. Page 2-6 MII Module...
  • Page 19: Desktop Mounting

    The Switch is ready for network connections. Rack Mounting All 7000 Series Switches come with a rack-mounting kit and can be mounted in a standard 19-inch equipment rack. This rack can be placed in a wiring closet with other equipment.
  • Page 20: Cabling Requirements

    Installation Mount the Switch in the equipment rack by screwing the mounting brackets to the equipment rack. See Figure 2-11. Friendl yNET 7000 Series A1 A2 A3 A4 A5 A6 A7 Power Figure 2-11 Mounting the FS7000 in an equipment rack The rack mounting is complete.
  • Page 21: Connecting Network Devices

    Connecting Network Devices This section describes how to connect computers, hubs and switches to the FS7000 Switch, and how to connect multiple FS7000 Switches together. Before you connect network devices to the Switch, review the following guidelines: Make sure the network cable length is less than 100 meters (Category 5 and up) Note: Category 3 is acceptable for 10Base-T Use a straight-through twisted pair cable or a crossover cable when...
  • Page 22: Connecting A Hub Or A Switch To The Asanté Switch

    Installation Connecting a Hub or a Switch to the Asanté Switch Use a two-pair Category 5 UTP straight-through cable with RJ-45 connectors Connect the hub’s uplink port to any of the Switch’s ports. See Figure 2-13. FriendlyNET 7 1 08 Gigabit Switch FS7108 Power Hub’s uplink port...
  • Page 23: Cascading Multiple Fs7000 Switches

    Cascading Multiple FS7000 Switches Multiple FriendlyNET 7000 Series Switches can be connected together (called cascading). See Figure 2-15. Friend lyNET 7000 Series A1 A2 A3 A4 A5 A6 A7 B1 B2 B3 B4 B5 B6 B7 Power 10 11 Friend lyNET 7000 Series...
  • Page 24 Installation Page 2-12...
  • Page 25: Led Indicators

    This chapter explains how to interpret the front-panel LED indicators on FriendlyNET 7000 Series Gigabit Switches. There are no LEDs on the rear panel. The LEDs are used to facilitate monitoring and troubleshooting. With the exception of the Power LED and MII Power LED, all front-panel LEDs are used to monitor the status of each port.
  • Page 26: Power On Led Indicators

    Switch. Table 3-1 describes the possible status indications of the MII Power LED. Table 3-1 State Page 3-2 FriendlyNET 7000 Series Gigabit Switch A1 A2 A3 A4 A5 A6 A7 A8 B1 B2 B3 B4 B5 B6 B7 B8 10 11 12 13 14 15 16...
  • Page 27: Led Indicators For Port Connections

    LED Indicators for Port Connections All FS7000 Series Switches include 100/10Mbps, Full/Half Duplex and Link/ Data LED indicators for each 10/100 port on the Switch. On the FS7108, the ports and LEDs are numbered 1–8. On FS7x16 Switches, the ports and LEDs are numbered 1–16, A1–A8, and B1–B8.
  • Page 28: Link/Data Led

    LED Indicators Link/Data LED The green Link/Data LED indicates whether a device is detected on the other end of the port, and whether activity is occurring. Table 3-4 describes the possible status indications of the Link/Data LEDs. Table 3-4 State Blinking LED Indicators on Gigabit SX Module Each Gigabit module (when installed) includes its own LED indicators for...
  • Page 29: Full Duplex/Collision Led

    Full Duplex/Collision LED The Gigabit module’s green or amber Full Duplex/Collision LED indicates port operation in full- or half-duplex mode, and whether collisions are occurring on the port. Table 3-3 describes the possible status indications of the Gigabit Full Duplex/Collision LED. Table 3-6 Gigabit Full Duplex/Collision LED Status Indicators State...
  • Page 30 LED Indicators Page 3-6...
  • Page 31: Troubleshooting

    Table A-1 describes how to troubleshoot problems with your network and/or the Switch by monitoring the Switch’s LEDs. Problem Power LED is off Make sure the power cord is connected to the power outlet and is properly inserted into the power connector on the switch. Determine if the power outlet is functional by plugging another device into the receptacle.
  • Page 32 Page A-2...
  • Page 33: Specifications

    FS7000 Series Specifications Standards IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3z 1000Base-X IEEE 802.3x flow control (in full-duplex mode) Protocol CSMA/CD Data Transfer Ethernet/Fast Ethernet Rate 10Mbps (half-duplex)/100Mbps (half-duplex) 20Mbps (full-duplex)/200Mbps (full-duplex) Topology Star Network Cables 10Base-T: 4-pair UTP Category 3 or 5 (100m maximum) 100Base-TX: 4-pair UTP Category 5 (100m maximum) 1000Base-SX: dual 62.5/125 micron graded-index multimode fiber-optic...
  • Page 34 FS7000 Series Physical and Environmental Specifications AC Inputs 100–240 volts AC, 50/60 Hz (internal universal power supply) Power 15–30 watts (depends on model/configuration) Consumption Operating 32 to 104 F (0 to 40 C) Temperature Storage -4 to 158 F (-20 to 70 C) Temperature Humidity 10% to 90% non-condensing...
  • Page 35 Gigabit SX XP Module Specifications Standards IEEE 802.3z 1000Base-X IEEE 802.3x flow control Data Transfer Gigabit Ethernet Rate 1000Mbps Network Cables Dual 62.5/125 micron graded-index multimode fiber-optic Number of Ports One (Tx and Rx) Connectors LEDs Power Link/Data Full Duplex/Collision Gigabit SX XP Module Physical and Environmental Specifications Dimensions 5.7 in wide x 6.9 in deep x 1.0 in high (145 x 175 x 25 mm)
  • Page 36 Page B-4...
  • Page 37: Technical Support

    Contacting Technical Support To contact Asanté Technical Support: Telephone Fax-Back E-mail World Wide Web Site Technical Support Hours 6:00 a.m. to 5:00 p.m. Pacific Standard Time USA, Monday - Friday. Technical Support (800) 622-7464 (801) 566-3787 (800) 741-8607 support@asante.com http://www.asante.com Page C-1...
  • Page 38 Page C-2...
  • Page 39 ASANTÉ TECHNOLOGIES, INC., 821 FOX LANE, SAN JOSE, CA 95131 PHONE: 800.622.7464 • FAX: 801.566.3787 • e-mail address: sales@asante.com • World Wide Web site: http://www.asante.com ©1999 Asanté Technologies Inc. Asanté is a trademark of Asanté Technologies, Inc. All brand names and products are trademarks or registered trademarks of their respective holders. February 1999 Part Number 06-00504-00...
