2
AutoView 3050/3100/3200 Switch Installer/User Guide

Access the AutoView 3050/3100/3200 switch via a standard TCP/IP network

The Avocent AutoView 3050/3100/3200 switches provide agentless remote control and access. No
special software or drivers are required on the attached, or client, computers.
NOTE: The client connects to the AutoView 3050/3100/3200 switch using an Internet browser.

Figure 1.1: Example Switch Configuration (AutoView 3100/3200 shown)

Table 1.1: Descriptions for Figure 1.1

Number Description
1
UTP Connection
2
KVM Connection to the Switch
3
Remote IP Connection
4
AutoView 3100/3200 Switch
4
7
Number
5
6
7
8
3
5
8
Description
Ethernet
Digital User (Computer with Internet browser)
Analog User (OSCAR
Digital User (Computer with Internet browser)
6
®
Graphical User Interface)
