Options - Icom IC-F3021T/S Instruction Manual

D BATTERY PACK
Battery pack Voltage
BP-230N 7.4 V
BP-232N 7.4 V
Battery case for AAA
BP-240
(LR03) × 6 alkaline
* 1 When the power save function is turned ON, and the operat-
ing periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
* 2 Operating period depends on the alkaline cells used.
D CHARGERS
• B C-119N
desktop charger
+ BC-145
ac adapter
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 3 hours when BP-232N is attached.
• B C-121N + AD-106
-
multi charger
+ BC-157
ac adapter
For rapid charging of up to 6 battery packs (six AD-106'
s are required) simultaneously. An AC adapter should be
purchased separately. Charging time: approx. 3 hours when
BP-232N is attached.
• B C-160 + BC-145
desktop charger
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 3 hours when BP-232N is attached.
Capacity Battery life* 1
980 mAh 7.35 hrs.
2000 mAh 15.5 hrs.
—* 2
+ AD-106
charger adapter
(6 pcs.)
charger adapter
ac adapter

OPTIONS

D BELT CLIPS
• MB-93
swivel belt clip
• MB-94
belt clip
Exclusive alligator-type belt clip. The same as supplied with
the transceiver.
• MB-96N/96F
leather belt hanger
D OPTIONAL UNITS
• UT-108R
dtmf decoder unit
Provides pager and code squelch capabilities.
• UT-109R /UT-110R*
voice scrambler units
Non-rolling type (UT-109R)/Rolling type (UT-110R)* voice
scrambler unit provides higher communication security.
*You can use the UT-110R as Non-rolling type.
• UT-124R
man down unit
Provides measure of safety when working in a hazardous
environment, etc.
• UT-117R
SmarTrunk 3G™ logic board
Provides SmarTrunk 3G™ capability.
D DC CABLES
• CP-17L
cigarette lighter cable
Allows charging of the battery pack through a 12 V ciga-
rette lighter socket. (For BC-119N)
• OPC-515L/OPC-656
dc power cables
Allows charging of the battery pack using a 13.8 V power
source instead of the AC adapter.
OPC-515L: For BC-119N
OPC-656 : For BC-121N
