FEATURES
Rotating Camera
Touch Screen
AC Adaptor Jack
Headphone Jack
Power Button
USB Port
Brightness Buttons
Help Button
Microphone
Volume Buttons
Camera Button
Home Button
InnoTab Cartridge Port
®
InnoTab 2 Stylus &
®
Stylus Holder
Backup Battery Slot & Cover The backup battery provides power for
ACTION
Rotate the camera to take pictures of yourself
and your friends.
Touch the screen with your finger or the
InnoTab 2 stylus to play.
®
Use this to connect an AC/DC adaptor (sold
separately).
Use this to connect headphones (sold
separately).
Note: Maximum output voltage
Press this button to turn InnoTab
Plug the included USB cable into this USB
port to connect the tablet to your computer.
Press these buttons to adjust the screen
brightness.
Press this button to replay voice instructions,
or ask for a hint.
Speak into this microphone to record your
voice or play microphone games.
Press these buttons to adjust the sound
volume.
Press this button to enter the Camera app; or
if you are already in the Camera app, press
this button to take a picture.
Press this button to return to the InnoTab
2 desktop menu at any time.
Insert an InnoTab
into this slot to play.
Use your finger or this stylus to play. Always
place the InnoTab
stylus holder after use.
the clock. For backup battery replacement
instructions, please see the Care &
Maintenance section on page 22.
®
cartridge (sold separately)
®
2 stylus back into the
®
150mV.
2 on or off.
®
