G586SP
G586SP AIO
Rev . 0+
System Board
User' s Manual
- D29160226 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G586SP and is the answer not in the manual?

Questions and answers

Related Manuals for DFI G586SP

Summary of Contents for DFI G586SP

  • Page 1 G586SP G586SP AIO Rev . 0+ System Board User’ s Manual - D29160226 -...
  • Page 2 The information in this document is subject to change without notice. DFI, Inc. reserves the right to make revisions to this publication and to make changes to any and/or all parts of its content, at any time, without obligation to notify any person or entity of such changes.
  • Page 3 v FCC Statement on Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation.

  • Page 4: Table Of Contents

    v Table of Contents v Introduction ................6 Features and Specifications ............7 Package Checklist ..............9 Installation Overview ..............10 Preparing the Area ..............10 Handling the System Board ............11 Tips in Handling the System Board ......... 11 Hardware Installation ...............
  • Page 5 Award BIOS CMOS Setup Utility ........... 34 Standard CMOS Setup ............. 35 BIOS Features Setup ............... 38 Chipset Features Setup ............39 Power Management Setup............40 PCI Configuration Setup ............41 Load BIOS Defaults ..............42 Load Setup Defaults ..............42 Password Setting ..............

  • Page 6: Introduction

    133MHz or 150MHz frequencies. This ZIF socket allows users to easily upgrade CPUs. The difference between the G586SP and G586SP AIO is that the G586SP AIO comes with a built-in video accelerator for ultimate graphic displays. The VGA controller can display...

  • Page 7: Features And Specifications

    SiS5511: PCI/ISA system and cache memory controller SiS5512: PCI local data buffer SiS5513: PCI system I/O SiS6205 PCI graphics and video accelerator (G586SP AIO) • Winbond W83787F/83877F super I/O controller System Design • Unified Memory Architecture (G586SP AIO): 64-bit main...
  • Page 8 • Supports 360KB, 720KB, 1.2MB, and 1.44MB floppy drives • Two NS 16C550A-compatible enhanced serial ports • One SPP/ECP/EPP parallel port • One analog VGA port (G586SP AIO) Mouse/Keyboard Connectors • One mini-DIN-6 PS/2 or AT keyboard connector • Option: DIP 6-pin PS/2 mouse connector...

  • Page 9: Package Checklist

    • One card-edge bracket with serial port cable • One 16-pin cable for the VGA connector • One set of IDE software drivers • One set of VGA drivers (G586SP AIO only) • Option: PS/2 mouse port cables • Option: Cache module If any of these items is missing or damaged, please contact your dealer or sales representative for assistance.

  • Page 10: Installation Overview

    G586SP/G586SP AIO Installation Overview This chapter summarizes the steps in installing the board into your system unit. It also includes a description of the area in which you must work and directions for memory installation. Before installing the system board, obtain the memory you plan to install.

  • Page 11: Handling The System Board

    G586SP/G586SP AIO Handling the System Board Static electrical discharge can damage computer components without causing any signs of physical damage. You must take extra care in handling the system board to ensure against electrostatic buildup. Tips in Handling the System Board 1.

  • Page 12: Hardware Installation

    G586SP/G586SP AIO Hardware Installation The following summarizes the basic installation instructions. Before installing the system board into your system unit, you should prepare the tools you will need one medium size, flat- blade screwdriver and one medium Phillips screwdriver. 1. Unlock your system unit. Turn off the power and discon- nect all power cords and cables.

  • Page 13: Board Layout

    G586SP/G586SP AIO Board Layout...

  • Page 14: Memory Installation

    G586SP/G586SP AIO Memory Installation The system board supports 2MB to 256MB of memory using 72-pin SIMMs (Single In-line Memory Module) with the following two types of memory and sizes: (1) Single-sided SIMMs: 1MB, 4MB, 16MB, and 64MB; (2) Double-sided SIMMs: 2MB, 8MB, and 32MB.
  • Page 15 G586SP/G586SP AIO Bank 0 Bank 1 Memory Size SIMM1 SIMM2 SIMM3 SIMM4 10MB 1Mx36 1Mx36 256Kx36 256Kx36 12MB 1Mx36 1Mx36 512Kx36 512Kx36 16MB 1Mx36 1Mx36 1Mx36 1Mx36 16MB 2Mx36 2Mx36 — — 18MB 2Mx36 2Mx36 256Kx36 256Kx36 20MB 2Mx36 2Mx36...

  • Page 16: Installing The Modules

    G586SP/G586SP AIO Bank 0 Bank 1 Memory Size 132MB 16Mx36 16Mx36 512Kx36 512Kx36 136MB 16Mx36 16Mx36 1Mx36 1Mx36 144MB 16Mx36 16Mx36 2Mx36 2Mx36 160MB 16Mx36 16Mx36 4Mx36 4Mx36 192MB 16Mx36 16Mx36 8Mx36 8Mx36 256MB 16Mx36 16Mx36 16Mx36 16Mx36 Installing the Modules A SIM module simply snaps into a socket on the system board.

  • Page 17: Jumper Settings

    G586SP/G586SP AIO Jumper Settings Jumpers JP7 & JP8, and JP20 & JP21 CPU External Clock Speed and CPU Internal/External Speed Ratio CPU Speed CPU External Frequency JP20 JP21 Speed Ratio 50MHz 75MHz 1.5x 90MHz* 60MHz 1.5x 66MHz 100MHz 1.5x 120MHz...
  • Page 18 G586SP/G586SP AIO Cacheable Range Cache Size Tag SRAM Data SRAM 8 Tag Bits 7 Tag Bits 1 Dirty Bit 8KBx8x1 256KB 32KBx8x8 64MB 32MB 512KB 64KBx8x8 16/32KBx8x1 128MB 64MB 128KBx8x8 32KBx8x1 256MB 128MB Note: You can change the cacheable range settings by using the “L2 (WB) Tag Bit Length”...
  • Page 19 Jumper JP3 PS/2 Mouse The G586SP/G586SP AIO package includes a card-edge bracket with serial and mouse port. If you set JP3 to On, Enabled, make sure you connect the PS/2 mouse port to Connector J3. The default is set to On, enabled. If you want to disable this function, set JP3 to Off.
  • Page 20 G586SP/G586SP AIO Jumper JP12 Password/CMOS Clear If you set a password in the CMOS “Password Setting” option and forgot your password, you can use the CMOS Clear function to return the CMOS back to default and reset your password. To reset your password, first power off the computer and set pins 2-3 to On.

  • Page 21: Cache Configuration

    G586SP/G586SP AIO Cache Configuration The system board supports 3.3V pipeline burst or asynchro- nous cache SRAM installed in the 160-pin cache module slot. The board can be configured to the following cache sizes: 256KB, 512KB, or 1MB. Installing the Cache Module 1.
  • Page 22 G586SP/G586SP AIO 2. Once the cache module has been installed, make sure the “External Cache” option in the BIOS Features Setup menu of the Award PnP BIOS CMOS Setup Utility is set to “Enabled”. Note: With the cache module installed in the cache module slot, the...

  • Page 23: Cpu Installation

    G586SP/G586SP AIO CPU Installation The system board is equipped with a 321-pin Zero Insertion Force (ZIF) socket (see page 8 for socket location). This socket is designed for easy removal of an old CPU and easy insertion of an upgrade CPU. If you need to apply excessive force to insert the CPU, you are not installing the CPU correctly.

  • Page 24: Installation Procedure

    G586SP/G586SP AIO Installation Procedure To install a CPU, do the following. 1. Make sure the handle on the side of the ZIF socket is up. To raise the handle, push it down, slightly pull it out to the side, then raise it as far as it will go. The top plate will slide back.
  • Page 25 G586SP/G586SP AIO 3. Position the CPU above the ZIF socket. Make sure pin 1 of the CPU is aligned with pin 1 of the socket. Lower the chip until the pins are inserted properly in their corresponding holes. Remember that very little force is needed to install the CPU.

  • Page 26: Clearance Requirements

    G586SP/G586SP AIO Clearance Requirements The 3.3V Pentium OverDrive Processor comes with a heat sink mounted on top. To maintain proper airflow once the upgrade is installed on the system board, the processor and heatsink require certain space clearances. The clearance above 3.3V Pentium OverDrive Processor's fan/heatsink must be at least 0.4 inches.

  • Page 27: Built-In Ports

    G586SP/G586SP AIO Built-in Ports The system board is equipped with two serial ports, one SPP parallel printer port, one FDD connector, two IDE hard disk shrouded headers, and/or one optional PS/2 mouse connector. Serial Ports The built-in serial ports are RS-232C asynchronous commu-...

  • Page 28: Ps/2 Mouse Port

    G586SP/G586SP AIO PS/2 Mouse Port (optional): J3 The PS/2 mouse port is a 6-pin connector on the system board. Attach the 6-pin mouse port cable to Connector J3 and make sure the brown wire on the PS/2 mouse connector aligns with pin 1 of Connector J3.

  • Page 29: Connecting The Floppy And Hard Disk Cable: J11, J12, J13

    G586SP/G586SP AIO Connecting the Floppy and Hard Disk Cable: J11, J12, J13 Pin 1 Stripe J12: Primary IDE Connector J13: Secondary IDE Connector Floppy Drive Connector: J11 The Floppy and Hard Disk Connector on the System Board Connecting the Floppy Disk...

  • Page 30: Connecting The Ide Hard Disk Interface

    G586SP/G586SP AIO Connecting the IDE Hard Disk Interface To prevent improper IDE cable installation, each PCI IDE shrouded header has a keying mechanism. The 40-pin connector on the IDE cable can be placed into the header only if pin 1 of the connector is aligned with pin 1 of the header.

  • Page 31: Adding A Second Ide Hard Drive

    G586SP/G586SP AIO Adding a Second IDE Hard Drive When using two IDE drives, one must be set as the master and the other as the slave. Follow the instructions provided by the drive manufacturer for setting the jumpers, drive type, and/or switches on the drives.

  • Page 32: Installing Expansion Cards

    G586SP/G586SP AIO Installing Expansion Cards The system board is equipped with four PCI and three ISA slots. All four PCI slots are bus masters. One PCI slot and one ISA slot are shared. You can only install one card in one or the other of the shared slots at a time;...

  • Page 33: Troubleshooting Checklist

    G586SP/G586SP AIO v Troubleshooting Checklist If you experience difficulty with the system board, refer to the checklist below. If you still cannot isolate the problem, please contact your dealer. 1. Check the jumper settings to ensure that the jumpers are properly set.

  • Page 34: Award Bios Cmos Setup Utility

    G586SP/G586SP AIO v Award BIOS CMOS Setup Utility After you power up your system, the BIOS message appears on your screen and the memory count begins. After the memory test, the following message will appear on the screen: Press DEL to enter setup If the message disappears before you respond, restart your system or press the “Reset”...

  • Page 35: Standard Cmos Setup

    G586SP/G586SP AIO Press <Ctrl> <Alt> <Esc> simultaneously or <Del> to enter the Setup utility. A screen similar to the one below will appear. ROM PCI/ISA BIO S (2A 5IDD49) CMOS S ETUP UTILITY AWARD SO FTWARE, INC. S TAND ARD CMO S SETU P...
  • Page 36 G586SP/G586SP AIO Date and Time This selection sets the time and date for the system. Press <F3> for the calendar. These items cannot be altered; they are detected and displayed automatically. Hard Drive Type This allows you to enter the appropriate specifications for the type of hard disk drive(s) installed in your system.
  • Page 37 G586SP/G586SP AIO None Select <None> and press <Enter> if a hard drive is not installed. Drive A and Drive B These options are used to select the type of floppy disk drives installed in your system. If neither drive is present, select “None”.

  • Page 38: Bios Features Setup

    G586SP/G586SP AIO Memory The lower right hand corner shows the base memory size, extended memory size, and the other memory size of your system. You cannot alter these items; your computer auto- matically detects and displays them. The Other Memory size refers to the memory located in the 640K to 1024K address space.

  • Page 39: Chipset Features Setup

    G586SP/G586SP AIO The Virus Warning option may be set to “Enabled” or “Disabled”. When enabled, the BIOS issues a warning when any program or virus sends a Disk Format command or attempts to write to the boot sector of the hard disk drive. If...

  • Page 40: Power Management Setup

    G586SP/G586SP AIO Use the arrow keys to move the highlight bar to the option you wish to change or modify. Use the <Page Up>, <Page Down>, <+> or <-> keys to make the corresponding changes. If the changes you made are incorrect or you change your mind, press <F6>...

  • Page 41: Pci Configuration Setup

    G586SP/G586SP AIO PCI Configuration Setup Use the arrow keys to highlight “PCI Configuration Setup” and press <Enter>; a screen similar to the one below will appear. RO M PCI/IS A BIOS (2A5IDD 49) PCI & ON BOARD I/O SETU P AWARD S OFTWARE, INC.

  • Page 42: Load Bios Defaults

    G586SP/G586SP AIO Load BIOS Defaults The “Load BIOS Defaults” option loads the troubleshooting default values permanently stored in the ROM chips. These settings are non-optimal and turn off all high performance features. You should use these values only if you have hardware problems.

  • Page 43: Ide Hdd Auto Detection

    G586SP/G586SP AIO Type in the password. You are limited to eight characters. Type in a password that is eight characters long or shorter. When done, the message below will appear: Confirm Password: You are asked to verify the password. Type in exactly the same password.
  • Page 44 G586SP/G586SP AIO Enter your choice, and press <Enter> to accept the param- eters or press <Esc> to abort. The parameters of the hard disk will be displayed in the Standard CMOS Setup. Hard Drive Mode The board supports three HDD modes: Normal, LBA and Large.
  • Page 45 Large Mode The Large mode is the extended HDD access mode sup- ported by the G586SP AIO system board. Some IDE HDDs have more than 1024 cylinders without LBA support (in some cases, you may not want the LBA mode). The system board provides another alternative to support these kinds of HDD.

  • Page 46: Hdd Low Level Format

    G586SP/G586SP AIO Note: To support LBA or Large mode, address translation software is included in the Award BIOS HDD Service Routine (INT13h). If you are running an operating system that bypasses the BIOS Int13 Service Routine, LBA and Large Mode may fail.

  • Page 47: Save & Exit Setup

    G586SP/G586SP AIO Save & Exit Setup When all the changes have been made, highlight “Save & Exit Setup” and press <Enter>. The message below will appear: Save to CMOS and Exit (Y/N)? N Type “Y” and press <Enter>. The following message will...

  • Page 48: System Error Report

    G586SP/G586SP AIO System Error Report When the BIOS encounters an error that requires the user to correct something, either a beep code will sound or a mes- sage will be displayed in a box in the middle of the screen...
  • Page 49 G586SP/G586SP AIO different setting than indicated in Setup. Determine which setting is correct, and then either turn off the system and change the jumper, or enter Setup and change the VIDEO selection. DISPLAY TYPE HAS CHANGED SINCE LAST BOOT Since last powering off the system, the display adapter has been changed.
  • Page 50 G586SP/G586SP AIO OFFENDING ADDRESS NOT FOUND This message is used in conjunction with the I/O CHANNEL CHECK and RAM PARITY ERROR messages when the segment that has caused the problem cannot be isolated. KEYBOARD ERROR OR NO KEYBOARD PRESENT Cannot initialize the keyboard. Make sure the keyboard is attached correctly and no keys are being pressed during the boot.
  • Page 51 G586SP/G586SP AIO RAM PARITY ERROR - CHECKING FOR SEGMENT Indicates a parity error in Random Access Memory. SYSTEM HALTED, (CTRL-ALT-DEL) TO REBOOT... Indicates the present boot attempt has been aborted and the system must be rebooted. Press and hold down the CTRL...

  • Page 52: Appendix A: Award Bios Hard Disk Table

    G586SP/G586SP AIO v Appendix A: Award BIOS Hard Disk Table Type Example Size Cylinders Heads Sectors Write Land (MB) Precomp Zone Model TEAC SD510, MMI 112, 5412 Seagate ST225, ST4026 None Seagate ST125, Tandon TM262 None Tandon TM 703 None...
  • Page 53 G586SP/G586SP AIO Type Size Cylinders Heads Sectors Write Land Example Model (MB) Precomp Zone Maxtor 1085, 1024 None 1023 Micropolis 1325 Maxtor 1105 None 1023 1120, 4780 Maxtor 1170 None 1023 None CDC 9415 1024 1024 None 1023 1024 None...

  • Page 54: Appendix B: Memory & I/O Maps

    G586SP/G586SP AIO v Appendix B: Memory & I/O Maps Memory Map Address Name Function 0000000 to 640KB System System Board Memory 009FFFF Board RAM 00A0000 to 128KB Video Reserved for Graphics 00BFFFF Display Memory Display Memory 00C0000 to 160KB I/O...
  • Page 55 G586SP/G586SP AIO I/O Address Map I/O Address Function 000-01F DMA Controller 1, 8237A-5 020-03F Interrupt Controller 1, 8259A, Master 040-05F Timer, 8254-2 060-06F 8742 (Keyboard Controller) 070-07F Real-time Clock, NMI (Non-maskable Interrupt) Mask 080-09F DMA Page Memory, 74LS612 0A0-08F Interrupt Controller 2, 8259A...

  • Page 56: Appendix C: Pci I/O Pin Assignments

    G586SP/G586SP AIO v Appendix C: PCI I/O Pin Assignments Solder Side Component Side -12V TRST# - 01 - - 02 - +12V Ground - 03 - - 04 - - 05 - INTA# - 06 - INTB# - 07 -...

  • Page 57: Appendix D: Isa I/O Pin Assignments

    G586SP/G586SP AIO v Appendix D: ISA I/O Pin Assignments - 01 - -I/O Chck - 02 - Reset Drv - 03 - +5V DC - 04 - IRQ9 - 05 - -5V DC - 06 - DRQ2 - 07 -...

  • Page 58: Appendix E: System Overview

    G586SP/G586SP AIO Appendix E: System Overview DMA Channels DMA Controller 1 DMA Controller 2 Ch0-Reserved for User Ch4-Cascade for CTRL 1 Ch1-Reserved for User Ch5-Reserved for User Ch2-Diskette Ch6-Reserved for User Ch3-Reserved for User Ch7-Reserved for User Note: DMA controller 1 supports 8-bit data transfer.
  • Page 59 G586SP/G586SP AIO Page Memory Address Page Memory I/O Port Address 0081H DMA Channel 2 0082H DMA Channel 3 0083H DMA Channel 1 0087H DMA Channel 0 0089H DMA Channel 6 008AH DMA Channel 7 008BH DMA Channel 5 System Interrupts...
  • Page 60 G586SP/G586SP AIO Note: The 16 levels of system interrupts have the following prior- ity: IRQ0>IRQ1>IRQ8>IRQ9>IRQ10>IRQ11> IRQ12>IRQ13>IRQ14>IRQ15>IRQ3>IRQ4>IRQ5> IRQ6>IRQ7. System Timers Channel 0 System Timer (IRQ0) Channel 1 Refresh Request Generator (15us Rate Generator Period Signal) Channel 2 Tone Generation for Speaker...

  • Page 61: Appendix F: Connector Pin Assignments

    G586SP/G586SP AIO v Appendix F: Connector Pin Assignments Connector J2 PS/2 Keyboard Connector Function Keyboard Data Reserved Ground Keyboard Clock Reserved Connector J2 AT Keyboard Connector Function Keyboard Clock Keyboard Clock Not Connected Ground Connector J3 PS/2 Mouse Connector Function...
  • Page 62 G586SP/G586SP AIO J4 and J5 Primary (COM1) AND Secondary (COM2) Serial Ports Function DCD (Data Carrier Detect) RX (Receive Data) TX (Transmit Data) DTR (Data Terminal Ready) Ground (Signal Ground) DSR (Data Set Ready) RTS (Request to Send) CTS (Clear to Send)
  • Page 63 G586SP/G586SP AIO Connector J7 (G586SP AIO) Analog Connector Function Green Blue Monitor ID bit 2 (Not Used) Ground Red Return (ground) Green Return (ground) Blue Return (ground) Sync Return (ground) Not used DDCDA T Horizontal Sync Vertical Sync DDCCCK Not used...
  • Page 64 G586SP/G586SP AIO Connector J8 Parallel Printer Port Function -Strobe Data 0 Data 1 Data 2 Data 3 Data 4 Data 5 Data 6 Data 7 -Ack Busy Paper Empty Select -Autofd -Error -Init -Slctin Ground Ground Ground Ground Ground Ground...
  • Page 65 G586SP/G586SP AIO Connector J9 Power Connector Function Power Good +12V -12V Ground Ground Ground Ground...
  • Page 66 G586SP/G586SP AIO Connector J10 (G586SP AIO) Feature Connector Function PD 2 PD 3 PD 4 PD 5 PD 6 PD 7 Enpclk EBlank EHSync EVSync Ground Ground Ground Ground EnVideo EnSync EnPclk Not used Ground Ground Ground Ground Not used...
  • Page 67 G586SP/G586SP AIO Connector J11 Floppy Disk Drive Connector Function Ground DENSEL Ground Reserved Ground Drate0 Ground Index Ground MTR0 Ground Ground Ground MTR1 Drate1 Ground Step Ground Write Data Ground Write Gate Ground Track 0 MSEN Wr Protect Ground Read Data...
  • Page 68 G586SP/G586SP AIO Connector J12 and J13 Primary/Secondary IDE Hard Disk Drive Connectors Function -Reset Ground Ground Reserved Reserved Ground -IOW Ground -IOR Ground Reserved BALE Reserved Ground IOCS16...
  • Page 69 G586SP/G586SP AIO Function Reserved HCS0 HCS1 Ground Connector J14 External Battery Function 3.6V Lithium Battery...
  • Page 70 G586SP/G586SP AIO Connector J17 IDE LED Function Signal LED Power Connector J18 Suspend Switch Function Signal Connector J19 Green LED Function Signal LED Power Connector J20 Turbo LED Function Signal LED Power...
  • Page 71 G586SP/G586SP AIO Connector J21 Turbo Button Function Signal Connector J22 Reset Switch Function Ground Reset Connector J23 Speaker Function Signal Reserved Ground Connector J24 Power LED/Keylock Function LED Signal Reserved Ground Leylock Signal Ground...

  • Page 72: Appendix G: Vga Mpeg Support Mode List

    G586SP/G586SP AIO v Appendix G: VGA Video Playback Support Mode G586SP AIO: Shared Memory Configuration (1) R e s o l u t i o n C o l o r s F r a m e V G A...
  • Page 73 G586SP/G586SP AIO G586SP AIO: Shared Memory Configuration (2) R e s o l u t i o n C o l o r s F r a m e V G A N o r m a l F u l l...

This manual is also suitable for:
