Special Conditions

The following chart describes the appearance of the cable modem front panel LED
status indicators during special conditions to show when you have been denied
network access.
Front Panel LED Status Indicators During Special Conditions
Front Panel Indicator
1 POWER
2 DS
3 US
4 ONLINE
5 LAN1-LAN4
6 WIRELESS
7 TEL 1
8 TEL 2
4028315 Rev A
Network Access Denied
Slow Blinking
1 time per second
Slow Blinking
1 time per second
Slow Blinking
1 time per second
Slow Blinking
1 time per second
Slow Blinking
1 time per second
On
Off
Off
