4. Operation
The LEDs on the Extender Units show the real-time status indicating the linking and
communication between the Console Unit and Computer Unit. Users can identify the present
status through the LED indicator on the top. See Figures 2-3 and 2-6 and Tables 2-1 and 2-2.
The quality of the output signal will depend largely upon the quality of video source, cable,
and display device used. Low-quality cables degrade the output signal causing elevated noise
levels. Use the proper cable and make sure the display device can handle the resolution and
refresh rate selected.
5. Application Diagram
IR receiver IR transceiver
ACS261A-SM ACS261A-SM
Console Computer
Unit Unit
Single-mode
Computer
fiber optic cable
Console
Figure 5-1. Typical installation.
© Copyright 2012. Black Box Corporation. All rights reserved. Black Box ® and the Double Diamond
logo are registered trademarks of BB Technologies, Inc. Any third-party trademarks appearing in
this manual are acknowledged to be the property of their respective owners.
ACS261A-SM, version 1
FREE! Live, 24/7 T ech Support is just 30 seconds away.
724-746-5500 | blackbox.com
Chapter 2: Overview
Figure 2-6. Computer unit top panel.
Table 2-2. Computer Unit components.
Number Component Description
1 Audio connector Connects to speaker
2 Audio connector Connects to microphone
3 IR control jack Plug in the external sensor here
4 Barrel connector Links to power
5 Link OK LED Flashing yellow: Link OK
6 (2) SC connectors Connect to fiber
7 DVI connector Links to computer video port
8 (1) USB Type B connector Connects to computer keyboard and mouse
9 (1) 6-pin mini DIN connector Connects to computer PS/2 keyboard and mouse
10 Reset button Resets unit
Green: Power on
11 Link OK/Power LED
Blue: Link OK
724-746-5500 | blackbox.com
ACS261A-SM
BLACK BOX
®
Chapter 3: Installation
3. Installation
• Power off all devices that will be connected to this system.
11 • Make sure that all devices you will connect are properly grounded.
• Place units away from fluorescent lights, air conditioners, and machines that are likely to
generate electrical noise.
• Determine where the Console Unit and the Computer Unit will be located.
• Use SC to SC duplex single-mode fiber optic cable (8–10 µm) for the interconnection between
Console Unit and Computer Unit.
• Make sure that the fiber cable length is long enough for the connection between the Console
Unit and the Computer Unit to prevent having to splice fiber.
• Never attempt to disassemble or reassemble the enclosure for any purpose. This may cause
personal injury and/or property damage.
Considerations for Duplex Optical Fiber Installation
1. Users may need to order appropriate cable lengths conforming to the application environment;
however, the maximum cable length should not exceed 3200 ft. (1000 meters). Otherwise, the
video resolution signal may degrade.
2. Do not exceed the cable bend radius. Fiber optic cable can break when kinked or bent too
tightly, especially during pulling.
3. Do not twist the cable. Twisting the cable can stress the fibers. Tension on the cable and
pulling ropes can cause twisting.
CAUTION: Do not look into the ends of any fiber optic cables. You might be exposed to harmful
invisible laser radiation.
4. Follow the cable manufacturer's recommendations. Fiber optic cable is often custom designed
for the installation, and the manufacturer may have specific instructions on its installation.
Installing the Extender
Users can connect the video source and keyboard and mouse ports to the Computer Unit;
connect the keyboard, mouse, and monitor to the Console Unit; and use an SC to SC duplex
fiber optic cable for the SC-SC fiber port connection between the Console Unit and the
Computer Unit. After all device connections are completed, connect the provided power cord
into an appropriate power source and plug the opposite end into the power connector on the
Unit to power up.
Page 5
724-746-5500 | blackbox.com
ACS261A-SM
DVI-D USB Fiber Extender Single-Mode with Audio
Using fiber optic cable, place a computer up to
BLACK BOX
3280 feet (1000 m) away from a console.
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.
Customer
call 724-746-5500) • FREE technical support 24 hours a day, 7 days
Support
Information a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address:
Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Page 6
Web site: www.blackbox.com • E-mail: info@blackbox.com
ACS261A-SM
®
