- Page 1 724-746-5500 or blackbox.com. About Black Box Black Box Network Services is your source for more than 118,000 networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 20 seconds or less.
-
Page 2: Black Box
Customer call 724-746-5500) • FREE technical support 24 hours a day, 7 days a Support week: Call 724-746-5500 or fax 724-746-0746 • Mailing address: Information Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com... -
Page 3: Federal Communications Commission
FCC and NOM Statements FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment... -
Page 4: Instrucciones De Seguridad
DVI Extender Normas Oficiales Mexicanas (NOM) Electrical Safety Statement INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. - Page 5 NOM Statement 12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada. 13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
-
Page 6: Trademarks Used In This Manual
DVI Extender TRADEMARKS USED IN THIS MANUAL BLACK BOX and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners. 724-746-5500 | blackbox.com... -
Page 7: Table Of Contents
2.5 Features .................... 10 3. Installation and Operation ................. 11 3.1 Installing the Transmitter and Receiver ..........11 3.2 Operation ..................11 4. Troubleshooting ..................12 4.1 Calling Black Box ................12 4.2 Shipping and Packaging ..............12 724-746-5500 | blackbox.com Page 5... -
Page 8: Chapter 1. Specifications
DVI Extender 1. Specifications Compatible Cable: 50-/125-µm multimode fiber, OM3 preferred; Link distance using 50-/125-µm multimode fiber is up to 1280 ft. (400 m); Link distance using 62.5-/125-µm fiber is reduced to 576 ft. (180 m) Emulation Mode: Supports extended EDIDs up to 256 bytes Housing: Metal, black powder-coated Link Distance: Up to 1280 ft. -
Page 9: Overview
2. Overview 2.1 Introduction The ACS2004A is a single fiber optic DVI extender set that consists of a transmit- ter and a receiver. It overcomes the limits of traditional copper-based extenders and even other fiber optic extenders. It extends DVI signals up to 1920 x 1200 pixels using optical signals transmitted without signal degradation, without compression, and without delays. -
Page 10: Left Side Panel
DVI Extender 2.2 Left Side Panel Figures 2-1 and 2-2 show the left side panels of the ACS2004A transmitter and receiver. Figures 2-3 and 2-4 show the right side panels. Figure 2-1. ACS2004A transmitter left side panel. Figure 2-2.ACS2004A receiver left side panel. -
Page 11: Right Side Panel
Chapter 2: Overview 2.3 Right Side Panel Figure 2-3. ACS2004A transmitter right side panel. Figure 2-4. ACS2004A receiver right side panel. Table 2-2. Right side panel components. Number Component Description Barrel connector Power SC connector Link both units together 724-746-5500 | blackbox.com... -
Page 12: What's Included
DVI Extender 2.4 What’s Included Your package should include the following items. If anything is missing or damaged, contact Black Box Technical Support at 724-746-5500. • (1) TX unit • (1) RX unit • (2) power supplies • This user’s manual 2.5 Features... -
Page 13: Installation And Operation
Chapter 3: Installation and Operation 3. Installation and Operation 3.1 Installing the Transmitter and Receiver 1. Connect the transmitter’s DVI-D connector to a DVI 1.0-compliant video source, such as a computer, media player, TV tuner, etc.. 2. Connect the receiver’s DVI-D connector to an LCD or plasma display. 3. -
Page 14: Troubleshooting
• Package it carefully. We recommend that you use the original container. • If you are returning the unit, make sure you include everything you received with it. Before you ship for return or repair, contact Black Box to get a Return Authorization (RA) number.
