HP StorageWorks AiO600 Quickspecs page 6

QuickSpecs
Highlights
AiO600 Processor
Hardware
Specifications
Memory
Operating System
Network Controller
Storage Controller
Internal Storage
(varies by model)
Optical Drive
Expansion Slots
Power Supply
Cooling Fans
Remote Management
Form Factor
Warranty
SIM Support
DA - 12786
HP StorageWorks 600 All-in-One Storage System
Dual Core Intel Xeon 2.67 GHz/1333 MHz FSB with 4MB (1 x
4MB) L2 Cache; NOTE: The AiO600 supports up to 2 processors
1 GB of PC2-5300 Fully Buffered DIMMs; 2 x 512MB (AiO600 has
Eight PC2-5300 FB-DIMM (DDR2 667) sockets)
Up to 4GB supported
Windows Storage Server 2003, Release 2 Standard Edition
Embedded NC373i Multifunction Gigabit Network Adapter with
TCP/IP Offload Engine
Additional Dual port 10/100/1000T Adapter (NC360T)
NOTE: The NC360T replaces the NC7170 NIC which previously
shipped with the AiO600. These network adapters are functionally
equivalent in all respects and both adapters will continue to be fully
supported by HP. Support for units in the field, including replacement
parts, will be provided to both the NC7170 or NC360T.
Smart Array E200i Controller with 128MB BBWC included (RAID
0,1,10,5)
1.5TB SATA Model: 6 x 250GB front load, hot plug, 7200 RPM
SATA HDDs
3.0TB SATA Model: 6 x 500GB front load, hot plug, 7200 RPM
SATA HDDs
876GB SAS Model: 6 x 146GB front load, hot plug, 15,000 RPM
Serial Attached SCSI (SAS) HDDs
1.8TB SAS Model: 6 x 300GB front load, hot plug, 15,000 RPM
Serial Attached SCSI (SAS) HDDs
HP DVD+R/RW 16X Half Height
(3) x4 PCI-Express (x8 connectors)
NC360T Network Card)
(1) 64 bit, 133MHz 3.3V PCI-X
(2) 64 bit, 100MHz 3.3V PCI-X
Dual Hot-Plug redundant power supplies
Two system fans plus two redundant system fans
Remote system management User Interface (UI), Remote Desktop or
Telnet
Integrated Lights Out 2 (iLO2) with Advanced License Pack
5 U Tower or Rack with optional rack conversion
The AiO600 has a standard 3-3-3 warranty (3 years parts exchange,
three years labor, and three years on-site, next business day response)
which can be upgraded to same day support through HP Care Packs.
The AiO600 supports Insight Manager through SNMP. For more
information on HP Insight Manager please visit:
http://h18013.www1.hp.com/products/servers/
management/hpsim/index.html
Worldwide QuickSpecs — Version 3 — 9.12.2007
(AiO600)
(NOTE: One slot occupied by
Page 6
