Nobles Concorde 608349 Operation And Parts Manual

Automatic carpet extractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model No.:
608349
608935 – Pac
609256 – Can. Pac
NOBLES
12875 RANSOM STREET
HOLLAND MI 49424 U.S.A.
CUSTOMER SERVICE: 1-800-365-6625
FAX: 1–800–678–4240
OUTSIDE U.S. : 1–616–786–2330
Home
Concorde
Find... Go To..
t
HP Plus
Automatic Carpet Extractor
Operator and Parts Manual
Rev. 00 (01-00)
608416

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Concorde 608349 and is the answer not in the manual?

Questions and answers

Related Manuals for Nobles Concorde 608349

Summary of Contents for Nobles Concorde 608349

  • Page 1 608935 – Pac 609256 – Can. Pac NOBLES 12875 RANSOM STREET HOLLAND MI 49424 U.S.A. CUSTOMER SERVICE: 1-800-365-6625 FAX: 1–800–678–4240 OUTSIDE U.S. : 1–616–786–2330 Home Automatic Carpet Extractor Operator and Parts Manual Find... Go To.. HP Plus 608416 Rev. 00 (01-00)

  • Page 2: Table Of Contents

    ........Concordet HP Plus (01–00)

  • Page 3: Safety Precautions

    Use care when reversing machine. – Report machine damage or faulty operation immediately. – Follow mixing and handling instructions on chemical containers. Concordet HP Plus (01–00) Home 4. Before leaving or servicing machine: – Stop on level surface. – Turn off machine.

  • Page 4: Machine Components

    Charge Cleaning Meter Brush Restorative Pressure Cleaning Meter Transport Read Manual Fast Speed Before Operating Transport Slow Speed Find... Go To.. CIRCUIT BREAKER PANEL Main Power Circuit Breaker Brush Motor Circuit Breaker Drive Motor Circuit Breaker Concordet HP Plus (01–00)

  • Page 5: Machine Installation

    1 – Spray Bar (installed on machine) 1 – Battery Charger (Included with Concordet HP Plus Pac 608935) Packaged Separately 3 – 12V Batteries (Included with Concordet HP Plus Pac 608935; not included with Pac 609256) Packaged Separately ATTENTION: Battery installation must be accomplished after removing machine from shipping crate.

  • Page 6: Machine Setup

    SPRAY BAR AND SPRAY TIP MAINTENANCE). TRANSPORTING MACHINE Operating machine without using cleaning functions. 1. Raise brush lift lever and engage lock block. 2. Activate main power switch. 3. Press drive switch towards transport mode symbol (Figure 5). Find... Go To.. Concordet HP Plus (01–00)

  • Page 7: Cleaning With Machine

    ATTENTION: For first time users, operate at a slower speed until maneuvering becomes easy. 6. To transport machine in reverse, simply pull reverse drive trigger (Figure 8). Concordet HP Plus (01–00) Home 7. To stop machine, release control grips and turn off machine.

  • Page 8: While Operating Machine

    2. Overlap each pass by about 51 mm (2 in). 3. Keep machine within 152–203 mm (6–8 in) of baseboard. 4. When turning, it may be necessary to turn pump switch off and raise brush lift lever. Find... Go To.. FIG. 13 FIG. 14 Concordet HP Plus (01–00)

  • Page 9: Maintenance

    Circuit breaker buttons are located at rear of machine as shown (Figure 15). FIG. 15 Concordet HP Plus (01–00) Home ADJUSTING BRUSH HEIGHT 1. Turn all switches off.

  • Page 10: Accessory Tool Setup And Operation (Options)

    (Figure 21). NOTE: If using a bucket to drain machine, use a separate bucket for filling solution tank. This will prevent possible solution line clogs. Find... Go To.. FIG. 20 Concordet HP Plus (07–99)

  • Page 11: Draining Solution Tank

    FIG. 22 2. Hold hose over floor sink or remove tank dome and direct hose into tank. 3. Activate main power and pump switch. Concordet HP Plus (01–00) Home BATTERY CHARGING The following charging instructions are intended for chargers supplied with machine. Use a battery charger with the following specifications to prevent battery damage.

  • Page 12: Machine Maintenance

    3. Remove vacuum hoses from vacuum pickup heads. 4. Remove drain hose from holder and push hose halfway through U–bracket to allow hose slack . 5. Carefully hinge tank over (Figure 27). Find... Go To.. FIG. 27 Concordet HP Plus (07–99)

  • Page 13: Hour Meter

    FOR SAFETY: Before leaving or servicing machine, stop on level surface, turn off machine and pull out main circuit breaker button. 8. Remove and clean solution tank fill port strainer. Concordet HP Plus (01–00) Home WEEKLY MAINTENANCE (Every 20 Hours of Use) 1.

  • Page 14: Battery Maintenance

    2. Remove belt guard, two screws (Figure 31). (4) Motor Mount Bolts 3. Remove any debris in pulley assembly. 4. Inspect belt for wear and for proper tension. Find... Go To.. Tension Bolt FIG. 30 FIG. 31 Concordet HP Plus (01–00)

  • Page 15: Plumbing System Maintenance

    2. Unscrew and remove inline strainer filter (clear bowl). Filter is located underneath at rear of machine (Figure 32). Concordet HP Plus (01–00) Home 3. Remove screens from bowl and clean. 4. When replacing filter, be certain clear bowl is threaded securely.

  • Page 16: Spray Bar And Spray Tip Maintenance

    3. Remove recovery tank dome to promote air circulation. ATTENTION: If storing machine in freezing temperatures, be certain to drain machine of all water. Damage due to freezing temperatures is not covered by warranty. Find... Go To.. Concordet HP Plus (01–00)

  • Page 17: Trouble Shooting

    Brush motor does not operate. Brush circuit breaker is tripped. Loose wiring. Faulty motor. Loose or broken belt. Carbon brushes worn. Faulty solenoid. Concordet HP Plus (01–00) Home SOLUTION Push in main circuit breaker button. Contact Service Center. Contact Service Center.
  • Page 18 Contact Service Center. Contact Service Center. Contact Service Center. Connect plug correctly. See Battery Maintenance Section. Let charge until fully charged. Replace charger. Charge batteries. Replace battery. See BATTERY MAINTENANCE. Replace battery charger. Find... Go To.. Concordet HP Plus (01–00)

  • Page 19: Specifications

    DRIVE MOTOR BRUSH MOTOR VACUUM MOTOR SOLUTION PUMP SEALED WATER LIFT DECIBEL RATING AT OPERATOR’S EAR, INDOORS ON CARPET Concordet HP Plus (01–00) Home CONCORDEt HP PLUS 1370 mm (54 in) 710 mm (28 in) 1190 mm (47 in) 306Kg (675 lbs) 3–12V Deep Cycle Lead Acid, 215Amp hours...

  • Page 20: Parts List

    PARTS LIST Home UPPER HOUSING GROUP Find... Go To.. Concordet HP Plus (09–98)

  • Page 21: Parts List Upper Housing Group

    PARTS LIST UPPER HOUSING GROUP DECALS LIST Concordet HP Plus (01–00) Home Find... Go To..

  • Page 22: Main Chassis Group

    PARTS LIST Home MAIN CHASSIS GROUP Find... Go To.. Concordet HP Plus (03–96)
  • Page 23 PARTS LIST MAIN CHASSIS GROUP Concordet HP Plus (01–00) Home Find... Go To..

  • Page 24: Control Console Group

    PARTS LIST Home CONTROL CONSOLE GROUP Find... Go To.. Concordet HP Plus (01–00)
  • Page 25 PARTS LIST CONTROL CONSOLE GROUP 602919 Concordet HP Plus (01–00) Home Find... Go To..

  • Page 26: Drive Group

    PARTS LIST Home DRIVE GROUP 28 29 Find... Go To.. Concordet HP Plus (03–96)
  • Page 27 PARTS LIST DRIVE GROUP Concordet HP Plus (09–98) Home Find... Go To..

  • Page 28: Plumbing System Group

    PARTS LIST Home PLUMBING SYSTEM GROUP TO SPRAY Find... Go To.. Concordet HP Plus (03–96)
  • Page 29 PARTS LIST PLUMBING SYSTEM GROUP Concordet HP Plus (09–98) Home Find... Go To..

  • Page 30: Brush Head Group

    PARTS LIST Home BRUSH HEAD GROUP Find... Go To.. 23 24 25 Concordet HP Plus (03–96)
  • Page 31 PARTS LIST BRUSH HEAD GROUP Concordet HP Plus (03–96) Home Find... Go To..

  • Page 32: Pump Breakdown

    PARTS LIST PUMP BREAKDOWN PUMP BREAKDOWN Concordet HP Plus (08–96) Home Find... Go To..

  • Page 33: Spray Bar Group

    Concordet HP Plus (02–97) Home SPRAY BAR GROUP SPRAY BAR GROUP Find... Go To.. PARTS LIST...

  • Page 34: Electrical Diagrams

    50 K LOCKABLE REVERSE INTERIM SPEED 50 K SETTING DASH MOUNT FORWARD TRAVEL SPEED ADJUSTMENT 50 K 50 K ROLL SWITCH 4.7K BRUSH HEAD SWITCH 10 A CIRCUIT BREAKER 60 A MAIN BREAKER CHARGER PLUG SWITCH Concordet HP Plus (01–00)

  • Page 35: Ladder Diagram

    FORWARD SPEED ADJUSTMENT –70– INTERIM MODE INTERIM –68– 50 K RESTOR MODE RESTOR –66– 50 K –16– Concordet HP Plus (01–00) Home LADDER DIAGRAM – MAIN SWITCH –9– –23– ORG –30– –39– –6– MASTER SOLENOID –53– –36– –15– BLK –30–...

  • Page 36: Options

    Find... Go To.. CAP, VALVE NIPPLE, HEX 1/4 ELBOW, ST 1/4 45 BODY, SPRAY 1/4F SCREEN, SPRAY NOZZLE TIP, SPRAY #8002 CAP, SPRAY BODY HOSE, VACUUM 25 W/ CUFFS CUFF, HOSE 1–1/2” CONNECTOR, VACUUM HOSE 1–1/2” Concordet HP Plus (03–96)

  • Page 37: Floor Tool

    Assembly Included in Assembly Find... Go To.. OPTIONS 13 14 ELBOW, 1/4–45 NIPPLE, CLOSE 1/4 COUPLER, QUICK SER. 60 HOSE, 1/4 HP W/ SWEDGE NIPPLE, HEX 1/4” WASHER ASM., SPRAY BAR CROSS NIPPLE ELBOW, 90 1/4FX1/4F SPRAY BODY SCREEN, SPRAY BODY...
