Cable Specifications - Cisco 1040 Sensor Quick Start Manual

Physical and Operating Environment Specifications
Specification
Operating temperature
Operating relative humidity
Height
Width
Depth
Weight
Power
Cables

Cable Specifications

• RJ-45 jack for the LAN 10/100BaseT connection (10/100-1)
• RJ-45 jack for the second LAN 10/100BaseT compliant connection (10/100-2)
External AC/DC Power Supply Specification: You must use a separately certified
Caution
AC-to-DC Power Supply. This Power Supply must be rated: 5vDC 2.5A certified and
marked: Limited Power Source (or L.P.S.).
Network Port Pinouts
Pin Number Function
1 DSR/RI—Data set ready/ring indicator
2 DCD—Data carrier detect
3 DTR—Data terminal ready
4 SGND—Signal Ground
5 RD—Receive Data
6 TD—Transmit Data
12
Value or Range
0° to 40°C (32° to 104°F)
10% to 90% (non-condensing)
3.8 cm (1.5 in.)
24.1 cm (9.5 in.)
20.3 cm (8 in.)
.5kg (1.0 lb.)
2.5A, 5vDC
Two (2) Category 5 cables
