D H
ESCRIPTION OF ARDWARE
This ADSL Gateway Router is a high bit-rate Digital Subscriber Line (DSL)
modem that can connect to an ADSL Internet service provider.
This unit provides the following ports on the rear panel:
One RJ-11 port for connection to your ADSL service provider's incoming
◆
line.
One RJ-45 port for connection to a PC, or to a 10/100BASE-TX Ethernet
◆
Local Area Network switch. This port operates at 10/100 Mbps, half/full
duplex. It supports automatic MDI/MDI-X operation, so you can use
straight-through cables for all network connections. (See
100BASE-TX Pin Assignments" on page
One USB port for connection to a PC (if an RJ-45 Ethernet port is not
◆
available).
The following two figures show the components of the Gateway:

Figure 1: Top Panel

– 20 –
C 1
HAPTER

Description of Hardware

119.)
LED Indicators
| Introduction
"10/
