Advantech AIMB-740-6CB1 User Manual

Advantech AIMB-740-6CB1 User Manual

Socket 478 intel pentium 4/celeron-d industrial atx motherboard with 6 serial ports
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AIMB-740-6CB1
Socket 478
Intel® Pentium® 4/
Celeron-D
Industrial ATX Motherboard
with 6 Serial Ports
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Advantech AIMB-740-6CB1

Summary of Contents for Advantech AIMB-740-6CB1

  • Page 1 AIMB-740-6CB1 Socket 478 Intel® Pentium® 4/ Celeron-D Industrial ATX Motherboard with 6 Serial Ports User’s Manual...

  • Page 2: Copyright Notice

    Copyright Notice This document is copyrighted, 2006, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improve- ments to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmit- ted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3 1.0.1 A Message to the Customer Advantech customer services Each and every Advantech product is built to the most exacting specifica- tions to ensure reliable performance in the harsh and demanding condi- tions typical of industrial environments. Whether your new Advantech...
  • Page 4 Table 1.1: AIMB-740-6CB1 Model AIMB-740VE-6CB1 CPU: Single socket 478 Intel® Pentium® 4/ Celeron-D/ Mobile Pentium® 4-M Chipset 845GV DDR SDRAM ECC support Memory DDR200/266/333 AGP 4X slot VGA: Chipset integrated VGA LAN 1: 10/100Base-T, Intel 82562 LAN 2: 10/100Base-TIntel 82551 LAN 1: 10/100/1000Base-T Intel 82541 AIMB-740-6CB1 User’s Manual...
  • Page 5 Table 1.2: AIMB-740-6CB1 DDR memory compatibility table Brand Size Speed Type ECC Part # Memory Apacer 256MB DDR266 77.10603.112 INFINEON HYB25D25680BT-7 (32×8) Kingston 512MB DDR266 KVR266X64C2 KINGSTON 5/512 D328DL-60 (32×8) Apacer 512MB DDR333 77.10728.56G MOSEL V58C2256804SAT5B 256MB DDR333 SAMSUNG K4H560838F- TCB3(32×8)

  • Page 6: Product Warranty

    Advantech assumes no liability under the terms of this warranty as a consequence of such events. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 7 740-6CB1 mechanically and electrically before shipment. It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the AIMB-740-6CB1, check it for signs of shipping dam- age. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.
  • Page 8 AIMB-740-6CB1 User’s Manual viii...

  • Page 9: Table Of Contents

    Table 1.1: Jumpers ............5 Table 1.2: Connectors ..........6 Board Layout: Jumper and Connector Locations....8 Figure 1.1: AIMB-740-6CB1 Jumpers and Connectors 8 Figure 1.2: I/O Connectors ..........8 AIMB-740-6CB1 Block Diagram........9 Figure 1.3: AIMB-740-6CB1 Block Diagram....9 Safety Precautions ............
  • Page 10 2.12 Front Panel connector (CN16, 17, 18, 19, 21&29) ..24 Table 2.1: PS/2 or ATX power supply LED status ..25 2.13 H/W Monitor Alarm (CN22)........... 26 2.14 USB and LAN ports (CN31 and CN32)......27 2.15 CF socket (CN44, optional) ..........28 2.16 Line-out, Mic-in connector (CN55) ........
  • Page 11 4 Chipset Software Installation Utility ....56 Before you begin ............. 56 Introduction ..............56 Windows XP Driver Setup..........57 Chapter 5 VGA Setup (for AIMB-740-6CB1) ....62 Introduction ..............62 Dynamic Video Memory Technology......62 Windows XP Driver Setup..........63 Chapter 6 LAN Configuration ........70...
  • Page 12 Table B.23: Front audio conn (FP AUDIO; CN59)..122 B.25 8-pin Alarm Board connector (CN62) ......122 Table B.24: 8-pin Alarm Board connector (CN62) ..122 B.26 Case Open connector (CN64; only AIMB-740-6CB1). 123 Table B.25: Case Open connector (CN64) ....123 AIMB-740-B/741-B User’s Manual...
  • Page 13 B.27 Front Panel LAN LED connector (CN65) ....123 Table B.26: Front Panel LAN LED con. (CN65) ..123 B.28 System I/O Ports............124 Table B.27: System I/O ports........124 B.29 DMA Channel Assignments.......... 125 Table B.28: DMA channel assignments ..... 125 B.30 Interrupt Assignments ...........
  • Page 14 AIMB-740-B/741-B User’s Manual...
  • Page 15 General Information...

  • Page 16: Chapter 1 Hardware Configuration

    It meets the requirements of a variety of applications where a commercial motherboard cannot fit. The AIMB-740-6CB1 utilizes Intel 845GV and supports Socket 478 Pen- tium® 4/Celeron-D/Mobile Pentium® 4-M (FSB 400/533MHz) up to 3.06 GHz. In addition to a high-speed processor, it supports up to 2GB DDR memory and has 2 DIMM sockets on board.

  • Page 17: Features

    1.3 Specifications 1.3.1 System • CPU: AIMB-740-6CB1 supports CPU: Socket 478 for Pentium® 4/ Celeron-D/Mobile Pentium 4-M, FSB 400/533 MHz. up to 3.06 GHz, FSB 400/533 MHz. • L2 Cache: 256/512/1024 KB fullspeed L2 cache.

  • Page 18: Vga Interface

    PS/2 mouse. • USB port: Supports up to six USB 2.0 and transmission rate up to 480Mbps. (Six USB ports are available in AIMB-740-6CB1) 1.3.4 VGA interface • Interface: •...

  • Page 19: Jumpers And Connectors

    • Board weight: 0.7 kg (1.68 lb) 1.4 Jumpers and Connectors Connectors on the AIMB-740-6CB1 motherboard link it to external devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your applica- tion.

  • Page 20: Table 1.2: Connectors

    Table 1.2: Connectors Label Function Primary IDE connector Secondary IDE connector Floppy drive connector Parallel port USB port 4, 5 VGA connector (only for AIMB-740- 6CB1) Serial port: COM1 CN10 Serial port connector: COM2 CN10 Serial port connector: COM2 (RS 232/ 422/485) CN23 Serial port connector: COM3 (RS 232)
  • Page 21 Table 1.2: Connectors CN31 USB port 0, 1 & LAN1 CN32 USB port 2, 3 & LAN2 CN37 System FAN connector 2 CN44 CF socket (Optional) CN55 Line Out, Mic IN connector CN56 CD IN (Audio input from CD-ROM) CN57 AUX IN connector CN58 MDM IN connector...

  • Page 22: Board Layout: Jumper And Connector Locations

    1.5 Board Layout: Jumper and Connector Locations Figure 1.1: AIMB-740-6CB1 Jumpers and Connectors Figure 1.2: I/O Connectors AIMB-740-B/741-B User’s Manual...

  • Page 23: Aimb-740-6Cb1 Block Diagram

    Intel 82845GV VGA Port DDR 200/266/333 2 ATA 100 DMA 33/66/100 ports F-LAN1 : Intel 82562EZ Intel 82801DB 6 USB Ports USB 2.0/1.1 ICH4 Audio Codec LPC Bus Super IO Fintek Winbond BIOS COM3~COM6 F81216D W83627HF Figure 1.3: AIMB-740-6CB1 Block Diagram...

  • Page 24: Safety Precautions

    1.7 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.

  • Page 25: Jumper Settings

    1.8.2 CMOS clear (J1) The AIMB-740-6CB1 motherboard contains a jumper that can erase CMOS data and reset the system BIOS information. Normally this jumper should be set with pins 1-2 closed. If you want to reset the CMOS data, set J1 to 2-3 closed for just a few seconds, and then move the jumper back to 1-2 closed.

  • Page 26: Table 1.4: Watchdog Timer Output (J2)

    1.8.3 Watchdog timer output (J2) The AIMB-740-6CB1 contains a watchdog timer that will reset the CPU or send a signal to IRQ11 in the event the CPU stops processing. This fea- ture means the AIMB-740-6CB1 will recover from a software failure or an EMI problem.
  • Page 27 1.8.5 J15: Serial port pin out selection signal (RI)/power (5V or 12V) (User’s can use jumper settings to change pin outs of the RI pins of COM1~COM6.) 1.8.6 SW1 CPU Type Selection...

  • Page 28: System Memory

    1.9 System Memory The top-left edge of the AIMB-740-6CB1 contains two sockets for 184- pin dual in-line memory modules (DIMMs). Both two sockets use 2.5 V double-data-rate synchronous DRAMs (DDR SDRAM). DIMMs are available in capacities of 64, 128, 256, 512 MB, or 1 GB. The sockets can be filled in any combination with DIMMs of any size, giving your AIMB- 740-6CB1 single board computer between 64 MB and 2 GB of memory.

  • Page 29: Cache Memory

    CPU, the cache size is 256/128KB. In the Mobile Pentium 4(R)-M CPU, the cache size is 512KB. 1.12 Processor Installation The AIMB-740-6CB1 is designed for Intel Pentium® 4//Celeron-D/ Mobile Pentium® 4-M/Celeron® (socket 478). Note: Slim Heatsink & Fan is available from Advan- tech.

  • Page 30: Pci Bus Routing Table

    1.13 PCI Bus Routing Table Table 1.7: PCIBus Routing Table: PCI Slot ID SEL PCI Interrupt PCI1 AD31 INT B, C, D, A PCI2 AD30 INT C, D, A, B PCI3 AD29 INT D, A, B, C PCI4 AD28 INT A, B, C, D PCI5 AD27 INT B, C, D, A...
  • Page 31 Connecting Peripherals Chapter 2...

  • Page 32: Chapter 2 Connecting Peripherals

    2.2 Primary and Secondary IDE connectors (CN1/2) You can attach up to four IDE (Integrated Drive Electronics) drives to the AIMB-740-6CB1’s built-in controller. The primary (CN1) and secondary (CN2) connectors can each accommodate two drives. Wire number 1 on the cable is red or blue and the other wires are gray.

  • Page 33: Floppy Drive Connector (Cn3)

    2.3 Floppy Drive connector (CN3) You can attach up to two floppy disk drives to the AIMB-740-6CB1's onboard controller. You can use 3.5" (720 KB, 1.44 MB) drives. The motherboard comes with a 34-pin daisy-chain drive connector cable.

  • Page 34: Parallel Port (Cn4)

    26-pin flat-cable connector, CN4. 2.5 USB Ports (CN6) The AIMB-740-6CB1's provides up to six ports of USB (Universal Serial Bus) interface, which gives complete Plug & Play and hot swap- ping for up to 127 external devices.The USB interface complies with USB Specification Rev.

  • Page 35: Vga Connector (Cn7)

    2.7 Serial Ports (COM1: CN9, COM2: CN10, COM3: CN23, COM4: CN26, COM5: CN67, COM6: CN70 ) The AIMB-740-6CB1 offers six serial ports, CN9 as COM1 and CN10 as COM2, CN23 as COM3, CN26 as COM4, CN67 as COM5, CN70 as COM6..

  • Page 36: Ps/2 Keyboard And Mouse Connector (Cn11)

    using other IRQs may cause unexpected resource conflict. If you want to disable the ports or change the parameters, you can do this in the system BIOS setup. Different devices implement the RS-232/422/485 standards in different ways. If you are having problems with a serial device, be sure to check the pin assignments for the connector.

  • Page 37: External Keyboard Connector (Cn12)

    2.9 External Keyboard connector (CN12) In addition to the PS/2 mouse/keyboard connector on the AIMB-740- 6CB1's rear plate, there is also an extra onboard external keyboard con- nector. This gives system integrators greater flexibility in designing their systems. 2.10 CPU Fan connector (CN14) If fan is used, this connector supports cooling fans of 500mA (6W) or less.

  • Page 38: System Fan Connector (Cn15 And Cn37)

    2.11 System FAN connector (CN15 and CN37) If fan is used, this connector supports cooling fans of 500mA (6W) or less. 2.12 Front Panel connector (CN16, 17, 18, 19, 21&29) There are several external switches to monitor and control the AIMB- 740-6CB1.

  • Page 39: Table 2.1: Ps/2 Or Atx Power Supply Led Status

    2.12.2 External speaker (CN17) CN17 is a 4-pin connector for an external speaker. If there is no external speaker, the AIMB-740-6CB1 provides an onboard buzzer as an alterna- tive. To enable the buzzer, set pins 3-4 as closed 2.12.3 Reset (CN18) Many computer cases offer the convenience of a reset button.

  • Page 40: H/W Monitor Alarm (Cn22)

    2.12.6 SM Bus connector (CN29) This connector is reserved for Advantech's SNMP-1000 HTTP/SNMP Remote System Manager. The SNMP-1000 allows users to monitor the internal voltages, temperature and fans from a remote computer through an Ethernet network.

  • Page 41: Usb And Lan Ports (Cn31 And Cn32)

    2.14 USB and LAN ports (CN31 and CN32) The AIMB-740-6CB1 provides up to six USB (Universal Serial Bus) ports, which gives complete Plug & Play and hot swapping for up to 127 external devices.The USB interface complies with USB Specification Rev.

  • Page 42: Cf Socket (Cn44, Optional)

    2.15 CF socket (CN44, optional) The AIMB-740-6CB1 provides one optional CF socket, which is compat- ible with type I and type II CF cards. The CF socket shares the same resource with secondary IDE interface. CF card is only available for mas- ter mode.

  • Page 43: Audio Input From Cd-Rom (Cd In; Cn56)

    2.17 Audio Input from CD-ROM (CD IN; CN56) The CD IN is a connector for CD-ROM to input the audio signal. 2.18 Aux Line-In connector (AUX IN; CN57) The connector is for audio device with Line-in connector. Chapter 2...

  • Page 44: Modem-In Connector (Mdm In; Cn58)

    2.19 Modem-In connector (MDM IN; CN58) The connector is for modem with internal audio connector. 2.20 Front Panel Audio connector (FP AUDIO; CN59) The FPAUDIO is a front panel audio connector compliant with Intel® Front Panel I/O Connectivity Design Guide. To direct the audio signal output to the rear audio ports, the 5 and 6 pins, 9 and 10 pins must be shorted by jumper to activate the rear panel audio function.

  • Page 45: 8-Pin Alarm Board Connector (Cn62)

    2.21 8-pin Alarm Board connector (CN62) The 8-pin alarm board connector is for Advantech chassis with alarm board. 2.22 Case Open connector (CN64) The 2-pin case open connector is for chassis with case open censor. While opening the case, the buzzer on motherboard will ring.

  • Page 46: Connecting To Snmp-1000 Remote Manager

    2.24 Auxiliary 4-pin Power connector (ATX1) To ensure the sufficiency of power supply for Pentium® 4 motherboard, one auxiliary 4 pin power connector is available on AIMB-740-6CB1. It is strongly suggested to use ATX1 while the system is unstable. 2.25 RS 232/422/485 selection (J13 & J14)

  • Page 47: Serial Port Pin-Out Selection Signal (Ri)/Power (5V Or 12V) (J15)

    2.26 Serial Port Pin-out selection Signal (RI)/Power (5V or 12V) (J15) User’s can use jumper settings to change pin outs of the RI pins of COM1~COM6. 2.27 SW1 CPU selection (SW1) Make sure the switch setting of SW1 correspond to the CPU type you are using, if the switch setting of SW1 is incorrect, the system will NOT boot to avoid from CPU damage.
  • Page 48 AIMB-740-B/741-B User’s Manual...
  • Page 49 Award BIOS Setup Chapter 3...

  • Page 50: Chapter 3 Award Bios Setup

    Chapter 3 Award BIOS Setup 3.1 Introduction Award’s BIOS ROM has a built-in setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed memory (CMOS RAM) so that it retains the setup information when the power is turned off.

  • Page 51: Entering Setup

    3.2 Entering Setup Turn on the computer and press <Del> to allow you to enter the BIOS setup. Figure 3.1: Award BIOS Setup initial screen 3.3 Standard CMOS Setup Choose the “Standard CMOS Features” option from the “Initial Setup Screen” menu, and the screen below will be displayed. This menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory.

  • Page 52: Advanced Bios Features

    The “Advanced BIOS Features” screen appears when choosing the “Advanced BIOS Features” item from the “Initial Setup Screen” menu. It allows the user to configure the AIMB-740-6CB1 according to his partic- ular requirements. Below are some major items that are provided in the Advanced BIOS Features screen.

  • Page 53: Quick Power On Self Test

    3.4.4 Quick Power On Self Test Allows the system to skip certain tests while booting. This will decrease the time needed to boot the system. 3.4.5 First/Second/Third Boot Device The BIOS tries to load the OS with the devices in the sequence selected. Choices are: "Floppy", "LS120", "HDD-0", "SCSI", "CDROM", "HDD- 1", "HDD-2", "HDD-3", "ZIP100", "USB-FDD", "USB-ZIP", "USB- CDROM", "USB-HDD", "LAN", "Disabled".

  • Page 54: Advanced Chipset Features

    3.4.13 Security Option Select whether the password is required every time the system boots or only when you enter setup. "System" The system will not boot, and access to Setup will be denied if the correct password is not entered at the prompt. "Setup"...

  • Page 55: Figure 3.4: Advanced Chipset Features Screen

    Figure 3.4: Advanced chipset features screen 3.5.1 DRAM Timing Selectable This item allows you to control the DRAM speed. The selections are "Manual" or "By SPD". 3.5.2 CAS Latency Time This controls the latency between DDR RAM read command and the time that the data actually becomes available.

  • Page 56: Memory Frequency

    3.5.7 Memory Frequency To adjust the frequency of memory. The choice : "PC100", "PC133" and "Auto". 3.5.8 System BIOS Cacheable Selecting Enabled allows caching of the system BIOS ROM at F0000h- FFFFFh, resulting in better system performance. However, if any pro- gram writes to this memory area, a system error may occur.

  • Page 57: Integrated Peripherals

    3.6 Integrated Peripherals 3.6.1 On-Chip Primary/Secondary PCI IDE IDE Primary (Secondary) Master/Slave PIO/UDMA Mode (Auto) Each channel (Primary and Secondary) has both a master and a slave, making four IDE devices possible. Because each IDE device may have a different Mode timing (0, 1, 2, 3, 4), it is necessary for these to be independent.

  • Page 58: Ac97 Audio

    3.6.5 AC97 Audio Select Disable if you do not want to use AC-97 audio. Option is "Auto", "Disabled". 3.6.6 Init Display First This item allows you to choose which one to activate first, PCI Slot or on- chip VGA. The choices: "PCI Slot", "Onboard/AGP". 3.6.7 Onboard LAN1 Control Options are "Enabled"...

  • Page 59: Table 3.1: Com Port Irq Assignment

    3.6.14 Onboard Serial Port 1 ~ 6 Please refer to the below COM port IRQ and I/O address assignment, inappropriate assignment may cause unexpected resource conflict. Table 3.1: COM Port IRQ Assignment COM Port COM 1 IRQ 3 / IRQ 4 COM 2 COM 3 IRQ 5 / IRQ 10 /...

  • Page 60: Onboard Parallel Port

    3.6.20 Onboard Parallel Port This field sets the address of the on-board parallel port connector. You can select either "378/IRQ7", "278/IRQ5", "3BC/IRQ7", or "Disabled". If you install an I/O card with a parallel port, make sure there is no conflict in the address assignments.

  • Page 61: Power Management Setup

    3.7 Power Management Setup The power management setup controls the single board computer's “green” features to save power. The following screen shows the manufac- turer’s defaults: Figure 3.6: Power management setup screen (1) 3.7.1 ACPI function The choice: "Enabled", "Disabled". 3.7.2 ACPI Suspend Type The Choice : "S1(POS)", and "S3(STR)".

  • Page 62: Video Off Method

    User Defined Allows you to set each mode individually. When not dis- (Default) abled, each of the ranges are from 1 min. to 1 hr. except for HDD Power Down which ranges from 1 min. to 15 min. and disable. 3.7.4 Video Off Method To select the method to off the video.

  • Page 63: Figure 3.7: Power Management Setup Screen (2)

    3.7.14 FDD, COM, LPT PORT When Enabled, the system will resume from suspend mode if FDD, COM port, or LPT port is active. The choice: "Enabled", "Disabled". 3.7.15 PCI PIRQ [A-D]# When Enabled, the system will resume from suspend mode if interrupt occurs.

  • Page 64: Pnp/Pci Configurations

    3.8 PnP/PCI Configurations Figure 3.8: PnP/PCI configurations screen 3.8.1 Reset Configuration Data Default is Disable. Select Enable to reset Extended System Configura- tion Data (ESCD) if you have installed a new add-on and system configu- ration has caused such a conflict that OS cannot boot. 3.8.2 Resources Controlled By The commands here are "Auto (ESCD)"...

  • Page 65: Pc Health Status

    3.9 PC Health Status 3.9.1 CPU Warning Temperature This item will prevent the CPU from overheating. The choices are: "Dis- abled", "50C/122F", "53C/127F", "56C/133F", "60C/140F", "63C/145F", "66C/151F", "70C/158F". Figure 3.9: PC health status screen 3.9.2 Current CPU Temperature This shows you the current CPU temperature. 3.9.3 Current System FAN1/FAN2 Speed This shows you the current System FAN1/FAN2 operating speed.

  • Page 66: Spread Spectrum Control

    3.10 Spread Spectrum Control Figure 3.10: Spread Spectrum Control screen 3.10.1 CPU Clock Ratio Key in a DEC number to setup the CPU Clock Ratio. (Min=8; Max=50). This item only shows up under some special situations. 3.10.2 Spread Spectrum To enable/disable the spread spectrum. The Choice : "Enabled", "Dis- abled".

  • Page 67: Save & Exit Setup

    Please Confirm Your Password Enter the current password and press <Enter>. After pressing <Enter> (ROM password) or the current password (user-defined), you can change the password stored in the CMOS. The password must be no longer than eight (8) characters. Remember, to enable the password setting feature, you must first select either “Setup”...
  • Page 68 AIMB-740-B/741-B User’s Manual...
  • Page 69 Chipset Software Installation Utility Chapter 4...

  • Page 70: Chapter 4 Chipset Software Installation Utility

    Chapter 4 Chipset Software Installation Utility 4.1 Before you begin To facilitate the installation of the enhanced display device drivers and utility software, you should read the instructions in this chapter carefully before you attempt installation. The device drivers for the AIMB-740- 6CB1 board are located on the software installation CD.

  • Page 71: Windows Xp Driver Setup

    720 pixel DVD content, and MPEG-2 motion compensation for soft- ware DVD Note: This utility is used for the following versions of Windows system, and it has to be installed before installing all the other drivers: Windows 98SE Windows 2000 Windows Me Windows XP 4.3 Windows XP Driver Setup...
  • Page 72 Click "Yes" when you see the following message. Click "Next" when you see the following message. AIMB-740-B/741-B User’s Manual...
  • Page 73 When the following message appears, click "Finish" to complete the installation and restart Windows. Chapter 4...
  • Page 74 AIMB-740-B/741-B User’s Manual...
  • Page 75 VGA Setup Chapter 5...

  • Page 76: Chapter 5 Vga Setup (For Aimb-740-6Cb1)

    Chapter 5 VGA Setup (for AIMB-740- 6CB1) 5.1 Introduction The AIMB-740-6CB1 has VGA onboard, you need to install the VGA driver to enable the function. The Intel® 845GV Graphics Memory Controller Hub (the 845GV GMCH) is Intel’s first memory controller hub with integrated graphics for the Intel Pentium®...

  • Page 77: Windows Xp Driver Setup

    as Non-Local Video Memory (NLVM), and a highly efficient memory utilization scheme. DVMT ensures the most efficient use of available memory regardless of frame buffer or main memory sizing for maximum 2D/3D Graphics performance. DVMT dynamically responds to system requirements, and applications demands, by allocating the proper amount of display, texturing and buffer memory after the operating system has booted.
  • Page 78 installation procedure is for Windows XP. For other operating systems, please follow the on-screen installation guide Please click on "Next" to continue the installation AIMB-740-B/741-B User’s Manual...
  • Page 79 You will see a welcome window. Please chick on "Next" to con- tinue the installation. Click "Yes" when you see the following message. Chapter 5...
  • Page 80 Click on "Yes" to continue the installation Click "Finish" to complete the installation and restart the computer now or later. AIMB-740-B/741-B User’s Manual...
  • Page 81 When the following message appears, you can choose to restart the computer now or later. Chapter 5...
  • Page 82 AIMB-740-B/741-B User’s Manual...
  • Page 83 LAN Configuration Chapter 6...

  • Page 84: Chapter 6 Lan Configuration

    Chapter 6 LAN Configuration 6.1 Introduction The AIMB-740-6CB1 features the 32-bit 10/100/1000 Mbps Ethernet network interface. This interface supports bus mastering architecture and auto-negotiation features. Therefore standard twisted-pair cabling, with an RJ-45 connector for 10 Mbps and 100 Mbps connections, can be used.

  • Page 85: Installation

    CSI utility has been installed in your system. See Chapter 4 for information on installing the CSI utility. The AIMB-740-6CB1's onboard Ethernet interface supports all major network operating systems. However, the installation procedure varies with different operating systems. In the following sections, refer to the one that provides driver setup procedure for the operating system you are using.
  • Page 86 Select "Typical" and click "Next" to continue. Click "Install" to start the installation procedure. AIMB-740-B/741-B User’s Manual...
  • Page 87 Click "Finish" to complete the installation and show the results. Chapter 6...
  • Page 88 AIMB-740-B/741-B User’s Manual...
  • Page 89 USB 2.0 Configuration Chapter 7...

  • Page 90: Chapter 7 Usb 2.0 Configuration

    Chapter 7 USB 2.0 Configuration 7.1 Introduction The AIMB-740-6CB1 is designed with Intel ICH4 which supports both USB1.1 and USB 2.0 high-speed transmission. It still remains the stan- dard with today's USB device. High-speed USB 2.0 provides data transfer up to 480Mb/s which is 40 times faster than USB 1.1. It is ideal for today's speed-demanding I/O peripherals.
  • Page 91 1. From Windows 2000, select Start and click on Setting. In the window of Setting, click on icon System. Choose the option "Hardware", and then click on "Device Man- ager" Chapter 7...
  • Page 92 In Device Manager, choose "USB Controller" and then double click. Choose the option "Driver" and then click on "Update Driver". AIM-740-B/741-B User’s Manual...
  • Page 93 In Upgrade Device Driver Wizard, click on "Next". In Upgrade Device Wizard, choose "search for a suitable device for my driver" and then click on " Next". Chapter 7...
  • Page 94 Tick "Specify a location" and click "Next" In the following windows, please specify the location "D:\Drv_USB\w2k" and then click on "OK". AIM-740-B/741-B User’s Manual...
  • Page 95 In the following window, please click on "Finish" to complete USB driver installation. Chapter 7...
  • Page 96 AIM-740-B/741-B User’s Manual...
  • Page 97 Ultra ATA Storage Driver Setup Chapter 8...

  • Page 98: Chapter 8 Ultra Ata Storage Driver Setup

    Chapter 8 Ultra ATA Storage Driver Setup 8.1 Introduction This driver takes advantage of the latest Intel ® Ultra ATA controller fea- tures to improve both storage subsystem performance and overall system performance. A useful diagnostic tool, Intel Ultra ATA Companion®, shows technical information of the ATA subsystem.
  • Page 99 Click on "Next" when you see the following message. When you see the following message, click on "Yes" to accept the License Agreement. Chapter 8...
  • Page 100 Click on "Next" when you see the following message. Click on "Next" to continue. AIMB-740-B/741-B User’s Manual...

  • Page 101: Displaying Driver Information

    When the following message appears, click "Finish" to complete the installation and restart Windows. 8.4 Displaying Driver Information From the desktop of Windows, click on "Start" and select "Pro- grams." Then select "Intel Ultra ATA Storage Driver" and then "Companion." Chapter 8...
  • Page 102 Click on the "Device Parameters" or the "Storage Report" tab to view related information. AIMB-740-B/741-B User’s Manual...
  • Page 103 Onboard Security Setup Chapter 9...

  • Page 104: Chapter 9 Onboard Security Setup

    W83627HF. Onboard security (OBS) functions monitor key hardware. They help you maintain your system's stability and durability. The AIMB-740-6CB1 can monitor 5 sets of system positive voltages, 2 sets of system negative voltages, CPU cooling fan speed, and CPU temperature.
  • Page 105 Click "Next" when you see the following message. Click "Next" when you see the following message. Chapter 9...
  • Page 106 Click "Next" when you see the following message. Click "Next" to continue. AIMB-740-B/741-B User’s Manual...

  • Page 107: Using The Obs Hardware Doctor Utility

    Click "Finish" when you see the following message. 9.3 Using the OBS Hardware Doctor Utility After completing the setup, all the OBS functions are permanently enabled. When a monitored reading exceeds safe limits, a warning mes- sage will be displayed and an error beep tone will activate to attract your attention.
  • Page 108 From the desktop of Windows, click on "Start" and select "Pro- grams", select "Winbond HWDoctor" and click "HWDOCTOR." It is recommended that you load the default values for all the OBS settings. However, if desired, you can establish new conditions for voltage, fan speed, and temperature.
  • Page 109 Chapter 9...
  • Page 110 AIMB-740-B/741-B User’s Manual...
  • Page 111 Programming the Watchdog Timer Appendix A...

  • Page 112: Appendix A Programming The Watchdog Timer

    Appendix A Programming the watchdog timer A.1 Programming the Watchdog Timer The AIMB-740-6CB1's watchdog timer can be used to monitor system software operation and take corrective action if the software fails to func- tion after the programmed period. This section describes the operation of the watchdog timer and how to program it.
  • Page 113 Unlock W83627H Select register of watchdog timer Enable the function of the watchdog timer Use the function of the watchdog time Lock W83627HF Appendix A...
  • Page 114 Watchdog Timer Registers Address of register (2E) Attribute Read/Write Value (2F) and description 87 (hex) ----- Write this address to I/O address port 2E (hex) twice to unlock theW83627HF 07 (hex) write Write 08 (hex) to select reg- ister of watchdog timer. 30 (hex) write Write 01 (hex) to enable...
  • Page 115 F7 (hex) read/write Bit 6: Write 1 to enable key- board to reset the timer, 0 to disable.[default] Bit 5: Write 1 to generate a timeout signal immediately and automatically return to 0. [default=0] Bit 4: Read status of watch- dog timer, 1 means timer is ""time out""."...
  • Page 116 ;----------------------------------------------------------- Dec dx ; Set second as counting unit Mov al,0f5h Out dx,al al,dx And al,not 08h Out dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 10 seconds and Mov al,0f6h start counting Out dx,al Mov al,10 Out dx,al ;----------------------------------------------------------- Dec dx ;...
  • Page 117 ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Set minute as counting unit Mov al,0f5h Out dx,al al,dx Or al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 5 minutes and Mov al,0f6h start counting Out dx,al...
  • Page 118 Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be reset by mouse Mov al,0f7h Out dx,al al,dx...
  • Page 119 Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be strobed Mov al,0f7h reset by keyboard Out dx,al...
  • Page 120 Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register...
  • Page 121 I/O Pin Assignments Appendix B...

  • Page 122: Appendix B Pin Assignments

    Appendix B Pin Assignments B.1 IDE Hard Drive connector (CN1, CN2) Table B.1: IDE hard drive connector (CN1, CN2) Signal Signal IDE RESET* DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13...

  • Page 123: Floppy Drive Connector (Cn3)

    B.2 Floppy Drive connector (CN3) Table B.2: Floppy drive connector (CN3) Signal Signal FDHDIN* FDEDIN* INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * low active Appendix B...

  • Page 124: Parallel Port Connector (Cn4)

    B.3 Parallel Port connector (CN4) Table B.3: Parallel port connector (CN4) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active AIMB-740-B/741-B User’s Manual...

  • Page 125: Usb Connector (Cn6)

    B.4 USB connector (CN6) Table B.4: USB1/USB2 connector (CN6) USB1 Signal USB2 Signal +5 V +5 V Chassis GND N/CA B.5 VGA connector (CN7) Table B.5: VGA connector (CN7) Signal Signal GREEN BLUE H-SYNC V-SYNC Appendix B...

  • Page 126: Com1/Com2 Rs-232 Serial Port (Cn9, Cn10)

    B.6 COM1/COM2 RS-232 Serial Port (CN9, CN10) Table B.6: COM1/2 RS-232 serial port (CN9/10) Signal AIMB-740-B/741-B User’s Manual...

  • Page 127: Keyboard And Mouse Connector (Cn11)

    B.7 Keyboard and Mouse connector (CN11) Table B.7: Keyboard and mouse connector (CN11) Signal KB DATA KB VCC KB CLK B.8 External Keyboard connector (CN12) Table B.8: External keyboard connector (CN12) Signal DATA Appendix B...

  • Page 128: Cpu/System Fan Power Connector (Cn14/15/37)

    B.9 CPU/System Fan Power connector (CN14/15/37) Table B.9: CPU/System Fan Power Conn (CN14/15/37) Signal +12V Detect B.10 Power LED (CN16) You can use an LED to indicate when the motherboard is on. Pin 1 of CN16 supplies the LED's power, and Pin 3 is the ground. Table B.10: Power LED and keylock conn (CN16) Function LED power (+5 V)

  • Page 129: External Speaker Connector (Cn17)

    B.11 External Speaker connector (CN17) The motherboard has its own buzzer. You can also connect it to the exter- nal speaker on your computer chassis. Table B.11: External Speaker Connector (CN17) Function Buzzer Buzzer Speaker out B.12 Reset connector (CN18) Table B.12: Reset connector (CN18) Signal RESET...

  • Page 130: Hdd Led Connector (Cn19)

    B.13 HDD LED connector (CN19) Table B.13: HDD LED connector (CN19) Signal VCC (LED+) IDE LED (LED-) B.14 ATX Soft Power Switch (CN21)) Table B.14: ATX soft power switch (CN21) Signal 5VSB PWR-BTN AIMB-740-B/741-B User’s Manual...

  • Page 131: H/W Monitor Alarm (Cn22)

    B.15 H/W Monitor Alarm (CN22) Table B.15: H/W monitor alarm (CN22) Signal Enable OBS alarm Disable OBS alarm B.16 SM Bus connector (CN29) Table B.16: SM Bus connector (CN 29) Signal SMB_DATA SMB_CLK Appendix B...

  • Page 132: Usb Ports

    B.17 USB ports (CN31 and CN32 Table B.17: USB port Signal Signal Data0+ Data0- B.18 LAN ports (CN31 and CN32 Table B.18: Ethernet 10/100Base-T RJ-45 port Signal Signal XMT+ XMT- RCV- RCV+ AIMB-740-B/741-B User’s Manual...

  • Page 133: Cf Socket (Cn44)

    B.19 CF socket (CN44) Table B.19: CF socket (CN44) Signal Signal #CD1 #CS1 #CS1 #VS1 ATA SEL #IORD #IOWR INTRQ #CSEL #VS2 #RESET IORDY #INPACK #REG #DASP #PDIAG #IOIS16 #CD2 Appendix B...

  • Page 134: Line Out, Mic In Connector (Cn55)

    B.20 Line Out, Mic IN connector (CN55) B.21 Audio input from CD-ROM (CD IN; CN56) Table B.20: Audio in from CD-ROM (CD IN; CN56) Signal Signal CD_L CD_R AIMB-740-B/741-B User’s Manual...

  • Page 135: Aux Line-In Connector (Aux In; Cn57)

    B.22 Aux Line-In connector (AUX IN; CN57) Table B.21: Aux Line-In connector (AUX IN; CN57) Signal Signal AUX_L AUX_R B.23 Modem-In connector (MDM IN; CN58) Table B.22: Modem-In connector (MDM IN; CN58) Signal Signal PHONE_IN MONOOUT Appendix B...

  • Page 136: Front Panel Audio Connector (Fp Audio; Cn59)

    B.24 Front Panel audio connector (FP AUDIO; CN59) Table B.23: Front audio conn (FP AUDIO; CN59) Signal Signal LOUT_RR MIC_BIAS LOUT_L LOUT_R LOUT_LL B.25 8-pin Alarm Board connector (CN62) Table B.24: 8-pin Alarm Board Connector (CN62) Signal Signal 5VSB VCC3 -12V +12V AIMB-740-B/741-B User’s Manual...

  • Page 137: Case Open Connector (Cn64; Only Aimb-740-6Cb1)

    B.26 Case Open connector (CN64; only AIMB-740- 6CB1) Table B.25: Case Open connector (CN64; only AIMB-740-6CB1) Signal CASEOP B.27 Front Panel LAN LED connector (CN65; only AIMB-740-6CB1) Table B.26: Front Panel LAN LED connector (CN65; only AIMB-740-6CB1) USB1 Signal USB2 Signal LAN1_LINK LAN2_LINK LAN1_ACT LAN2_LINK...

  • Page 138: System I/O Ports

    B.28 System I/O Ports Table B.27: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 022-023 Chipset address 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register 0A0-0BF Interrupt controller 2 0C0-0DF...

  • Page 139: Dma Channel Assignments

    B.29 DMA Channel Assignments Table B.28: DMA channel assignments Channel Function Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available B.30 Interrupt Assignments Table B.29: Interrupt assignments Priority Interrupt# Interrupt source Parity error detected IRQ0 Interval timer IRQ1...

  • Page 140: 1St Mb Memory Map

    B.31 1st MB Memory Map Table B.30: 1st MB memory map Addr. range (Hex) Device E0000h - FFFFFh BIOS CC000h - DFFFFh Unused C0000h - CBFFFh VGA BIOS A0000h - BFFFFh Video Memory 00000h - 9FFFFh Base memory B.32 PCI Bus Map Table B.31: PCI bus map (for V/VE/E2 version;...
  • Page 141 GPIO Programming Source Code Appendix C...

  • Page 142: Appendix Cgpio Programming Source Code

    Appendix C GPIO Programming Source Code .MODEL small,c .486p .DOSSEG .STACK .CONST SMBus_PortEQU5000h GPIO_AddressEQU9Ch Control_RegEQU0 Output_RegEQU1 Input_RegEQU2 SEQ_LEN .DATA COUNT START_AXISDB? GPO_AXISDB? GPI_AXISDB ? TEST1_GPODW? TEST1_GPIDW? GPI_STR 'GPI $' GPO_STR 'GPO $' STS_STR 'STS $' FAIL_STRDB 'Test Failed .. $' PASS_STRDB 'Test Pass ..
  • Page 143 ;[]==========================================================[] GPIO_TableDB16h, 17h, 20h, 21h, 22h, 14h, 11h, 12h 31h, 32h, 33h, 23h, 24h, 25h, 26h, 27h ;[]==========================================================[] ; GPIO_1X at 10h, GPIO_2X at 20h, GPIO_3X at 40h ;[]==========================================================[] REG_TableDB 10h, 20h, 40h .CODE ;[]==========================================================[] ; MACRO ;[]==========================================================[] PRINT MACRO String push ax push dx ifnb...
  • Page 144 ENDM P_HEXMACROHEX_Num pusha ah, ah ifnb <HEX_Num> al, HEX_Num endif bl, 10 dx, ax eax, 16 ax, dx ah, 0Eh al, '0' eax, 24 ah, 0Eh al, '0' popa ENDM MACRO pusha ah, 7 al, 0 cx, 0 dx, 184fh bh, 7 popa ENDM...
  • Page 145 push push dh, row dl, col bx, 0 ah, 2 ENDM DELAY_MMACRO push cx, 1000 NEWIODELAY loop short @B ENDM NEWIODELAYMACRO 0EBh, al ENDM .STARTUP ax, @DATA ds, ax ax, ax ;make the cursor disapper ah, 01 ch, 20h START_AXIS, 0 ax, SEQ_1 Appendix C...
  • Page 146 bx, SEQ_2 call Do_Test1 START_AXIS, 7 ax, SEQ_2 bx, SEQ_1 call Do_Test1 ;make the cursor default ah, 01 ch, 0bh cl, 0ch ah, 4Ch .EXIT ;[]==========================================================[] ;Input : AX - GPO sequence BX - GPI sequence ;[]==========================================================[] Do_Test1Proc Near pusha TEST1_GPO, ax TEST1_GPI, bx al, START_AXIS...
  • Page 147 PRINT GPO_STR ; print gpo info. bx, TEST1_GPO cx, SEQ_LEN gpo_num: ax, cx ax, SEQ_LEN xlat P_HEX al P_CHAR20h loop gpo_num START_AXIS SET_CURSOR START_AXIS, 0 PRINT STS_STR START_AXIS SET_CURSOR START_AXIS, 0 PRINT GPI_STR ; print gpi info. bx, TEST1_GPI cx, SEQ_LEN gpi_num: ax, cx ax, SEQ_LEN...
  • Page 148 dx, cx dx, SEQ_LEN bx, TEST1_GPO SET_CURSOR GPO_AXIS, 4 call Belt_GPO_SEQ SET_CURSOR GPI_AXIS, 4 bx, TEST1_GPI call Dsp_GPI_SEQ COUNT != (SEQ_LEN - 1) fail_test .ENDIF DELAY_M loop run_test1 short ok_test fail_test: START_AXIS SET_CURSOR START_AXIS, 0 PRINT FAIL_STR P_CHAR07h DELAY_M P_CHAR07h DELAY_M end_test ok_test:...
  • Page 149 ;[]==========================================================[] Belt_GPO_SEQProcNear pusha cx, SEQ_LEN reset_seq: ax, cx ax, SEQ_LEN xlat ah, ah call Set_GPO_Level loop reset_seq cx, SEQ_LEN gpo_sts: ax, cx ax, SEQ_LEN ax, dx P_HEX 0 p_1: P_HEX 1 p_0: P_CHAR20h loop gpo_sts ax, dx xlat ah, 1 call Set_GPO_Level popa...
  • Page 150 ;[]==========================================================[] ;Input : BX - GPI sequence Table offset ;Output : COUNT - number of GPI Low ;[]==========================================================[] Dsp_GPI_SEQProcNear pusha COUNT, 0 cx, SEQ_LEN gpi_sts: ax, cx ax, SEQ_LEN xlat call Get_GPI_Status P_HEX al P_CHAR20h al == 0 inc COUNT .ENDIF loop gpi_sts...
  • Page 151 push call Get_GPIO_Info cl, bl cl, Control_Reg call I2CReadByte push cl, bl cl, Control_Reg al, bh call I2CWriteByte cl, bl cl, Input_Reg call I2CReadByte test al, bh GPI_High al, al Get_End GPI_High: al, 1 Get_End: Get_GPI_StatusEndp ;[]==========================================================[] ;Input : AL - GPIO number For example, AL is 20 if use GPIO 20 AH - 1 = High 0 = Low...
  • Page 152 ;[]==========================================================[] Set_GPO_LevelProcNear pusha call Get_GPIO_Info ; set output function cl, bl cl, Control_Reg call I2CReadByte cl, bl cl, Control_Reg al, bh call I2CWriteByte ; output data cl, bl cl, Output_Reg call I2CReadByte ah, ah Set_High al, bh Write_Byte Set_High: al, bh Write_Byte: cl, bl cl, Output_Reg...
  • Page 153 ;Output : BH - GPIO bit mask BL - GPIO register index ;[]==========================================================[] Get_GPIO_InfoProcNear push ;push ax to store ah push push push ax, @DATA ds, ax bx, GPIO_Table xlat cl, al cl, 0F0h bl, cl ; patch for F75111 bl, 30h Not_GPIO_3X bl, 40h...
  • Page 154 Get_GPIO_InfoEndp ;[]==========================================================[] ;Input : CL - register index ;Output : AL - value read ;[]==========================================================[] I2CReadByte ProcNear push push push dx, SMBus_Port + 04h al, GPIO_Address + 1 dx, al NEWIODELAY NEWIODELAY call Chk_SMBus_Ready al, cl dx, SMBus_Port + 03h dx, al ;index NEWIODELAY...
  • Page 155 dx, SMBus_Port + 05h al, dx NEWIODELAY NEWIODELAY I2CReadByte Endp ;[]==========================================================[] ;Input : CL - register index AL - value to write ;[]==========================================================[] I2CWriteByte ProcNear pusha push dx, SMBus_Port + 04h al, GPIO_Address dx, al NEWIODELAY NEWIODELAY call Chk_SMBus_Ready al, cl dx, SMBus_Port + 03h dx, al NEWIODELAY...
  • Page 156 NEWIODELAY dx, SMBus_Port + 02h al, 48h dx, al NEWIODELAY NEWIODELAY cx, 100h NEWIODELAY loop short @B call Chk_SMBus_Ready popa I2CWriteByte Endp Chk_SMBus_ReadyProcNear pusha dx, SMBus_Port + 0 ; status port Chk_I2C_OK: al, dx ; get status NEWIODELAY dx, al ;...
  • Page 157 short SMBus_Err short Chk_I2C_OK ;SMBus error due to timeout SMBus_Err: Clear_final: popa Chk_SMBus_ReadyEndp Appendix C...
  • Page 158 AIMB-740-B/741-B User’s Manual...
