Installation instructions

IZONA VentSurface
HI120 ISLAND models
Important!
SAVE THESE INSTRUCTIONS
The models shown in this document may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our local
website listed at the end of this document or contact your local Fisher & Paykel dealer.
1

SAFETY AND WARNINGS

Electrical shock hazard
Always disconnect the appliance from the mains electricity supply before
carrying out any servicing or maintenance operations.
Failure to do so could result in electrical shock or death.
Cut Hazard
Take care - panel edges are sharp.
Failure to use caution could result in injury or cuts.
Important safety instructions!
To avoid hazard, read and follow these instructions carefully before installing or
using this appliance.
Please make this information available to the person installing the appliance, as it
could reduce your installation costs.
This appliance is to be installed and connected to the electricity supply only by a
qualified electrician.
Installation must comply with your local building and electricity regulations.
Failure to install the appliance correctly could invalidate any warranty or liability
claims.
This appliance is designed for permanent fixture and has to be connected to the
mains electricity supply.
The appliance must not be installed above cookers with eye-level grills.
The appliance is heavy, take care when lifting or handling.
WARNING!
WARNING!
Before you install the appliance, please make sure that
the voltage (V) and frequency (Hz) indicated on the serial number plate as well as
the specifications on the rating plate on the inside of the appliance correspond to
the voltage and frequency of the mains supply.
the room in which the appliance is installed is well-ventilated.
the ceiling is able to withstand the total weight (56 kg) of the appliance suspended from it.
if the air is to be ducted, the flue is in good condition, especially if it has been out of
use for a long period of time.
If the air is to be ducted, it will not be discharged into a flue that is used for
exhausting fumes from appliances burning gas or other fuels.
the installation will comply with laws and regulations regarding ducting waste
gases.
for optimal efficiency, use smooth ducting for reduced noise and increased airflow. Flexible ducting
should only be used as a last resort.
When you install the appliance, please make sure that
a suitable isolating switch is incorporated in the permanent wiring, mounted
and positioned to comply with the local wiring rules and regulations. The switch
must be of an approved type installed in the fixed wiring and have a contact separation in all poles
that provide full disconnection under overvoltage category III conditions.
it is not installed and connected to flues where other appliances are installed
and which run off energy supplies other than electricity (eg water heaters, boilers,
gas cookers).
the power supply cable (type H05VV-F 3x0.75 mm
the letters L (power line) and N (neutral) mounted on the appliance and is secured
in position by a cable gland.
the power supply cable is connected to a suitable and easily accessible fixed power outlet or
isolating switch.
the power outlet or isolating switch remains accessible after installation and the appliance can be
disconnected from the electricity supply.
exhaust air is not discharged into a heating flue or wall cavity, unless the cavity is designed for that
purpose.
If you install using the external ducting through a side wall, ensure the surface area of the external
2
venting grill is no smaller than 150 cm
.
the glass and stainless steel components are handled with care. These are easily damaged if abraded
or knocked by tools.
NZ AU GB IE
2
) is connected to terminals marked with

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IZONA VentSurface HI120 ISLAND and is the answer not in the manual?

Questions and answers

Summary of Contents for Fisher & Paykel IZONA VentSurface HI120 ISLAND

  • Page 1: Installation Instructions

    (1,1) -1- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:51:59 PM (1,1) -1- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:51:59 PM Installation instructions IZONA VentSurface HI120 ISLAND models NZ AU GB IE Important! SAVE THESE INSTRUCTIONS The models shown in this document may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our local website listed at the end of this document or contact your local Fisher &...
  • Page 2: Product Dimensions

    (1,2) -1- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:51:59 PM (1,2) -1- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:51:59 PM PRODUCT DIMENSIONS CLEARANCE DIMENSIONS Installation diagrams for illustration purposes only ELECTRIC Clearances (mm) Product dimensions (mm) minimum clearance from bottom of VentSurface to: trivets or pot support surface of gas cooktops pot support surface of electric cooktops (including induction) overall height of product...
  • Page 3: Parts Supplied

    (2,1) -1- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:51:59 PM (2,1) -1- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:51:59 PM PARTS SUPPLIED Support frame 4 x 50 Screws (4) Ceiling for vertical flue Vertical flue Aluminium mounting Extendable mounting support 4 x 16 3.5 x 9.5...
  • Page 4 (2,2) -1- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:51:59 PM (2,2) -1- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:51:59 PM SECURE MOUNTING FRAME TO CEILING & MOUNT UPPER GLASS 6 mm holes Ensure the washers provided are used ATTACH PLASTIC VENT DUCT &...
  • Page 5 (1,1) -2- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:52:11 PM (1,1) -2- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:52:11 PM ATTACH VERTICAL MOUNTING BRACKETS & SLIDE ON FLUE COVER x 16 ATTACH MOUNTING BRACKETS TO MOUNTING FRAME & ATTACH FLUE COVER Important! VERY HEAVY: Ensure that the ceiling is able to withstand...
  • Page 6 (2,1) -2- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:52:11 PM (2,1) -2- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:52:11 PM OPTIMISING THE VENTSURFACE BY SELECTING COOKTOP TYPE To ensure best performance, the type of cooktop under the VentSurface needs to be selected after installing the appliance. To select the type of cooktop Make sure the VentSurface is on stand-by (plugged into a power outlet which is switched on but the fan is off ).
  • Page 7: Final Checklist

    (2,2) -2- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:52:11 PM (2,2) -2- 599489D izona vsisland install A2 NZGB.indd 21/7/09 2:52:11 PM FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Have you used the correct fixing screws? Have you used the wall anchors provided? Have you used the washers provided? Have you made sure that all standard requirements for ducting/ recirculation and electrical connection are met?
