Hardware Guide
Front Panel
Note: The DB9 Male Connector at the Terminal Blocks are connected to
the same signals internally. They are not two individual ports. As such,
the signals coming from the Terminal Blocks and the DB9 connector are
identical
Rear Panel
Instruction Manual
5-Pin Terminal Blocks
RS422/485
RXD (down) and TXD
(up) Activity LEDs
To USB Host Port
DB9 Male Connector
DIP Switch Settings
2
