- Page 1 GARAGE DOOR OPENER OWNER’S MANUAL ( S66 ) XUCHANG SUPERLIFT M & E EQUIPMENT Co.,Ltd Address: NO.1298, XJ Avenue, Xuchang, Henan, P.R.China. Tel: 0086 374 277 2299 Fax: 0086 374 277 3675...
-
Page 2: Table Of Contents
Contents 1. Required tool list ________________________________________________________01 2. Important safety instructions ______________________________________________ 01 3. Opener installation _______________________________________________________02 3.1 Important installation instruction __________________________________________02 3.2 Installation sketch map __________________________________________________03 3.3 Assembling opener _____________________________________________________03 3.4 Hoisting opener ______________________________________________ 04 4. Adjustment instruction ____________________________________________________05 4.1 Switch on power _______________________________________________05 4.2 Manipulation instruction _______________________________... -
Page 3: Required Tool List
IMPORTANT SAFETY INSTRUCTIONS WARNING – IT IS VITAL FOR THE SAFETY OF PERSONS TO FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS 1. Required tool list Name Specification Quantity Remark Electric drill Herringbone ladder (V-ladder) Mobile wrench or socket wrench 1 set Band tape Screw driver Cross-header screw driver... -
Page 4: Opener Installation
3. Installation instructions 3.1. Important installation instructions In order to reduce the risk of serious injuries or death, please read and follow all instructions provided! 1) Install only on a properly balanced door. An improperly balanced door has the potential to inflict severe injury. -
Page 5: Installation Sketch Map
3.2. Installation sketch map The completed installation is showed as figure 1. Figure 1 3.3. Opener assembling Remove the rail and opener from the package and place them on a clean & smooth working surface. Adjusting the front and rear position of clutch, making the internal spline of the chain/belt wheel on the rail align with the external spline of No.4. -
Page 6: Hoisting Opener
3.4. Hoisting opener 3.4.1. Locating installation front bracket The centerline of front bracket should be coincided with the lintel center line (As Figure 4).The centerline of two horizontal installation hole is not lower than the highest point of garage door operation trail, and fixed by the bolts. -
Page 7: Adjustment Instruction
Note: the installation and wiring must comply with the architectural working standard and electrical rules. 4.2. Manipulation instruction S66 opener adopts with 7 LBD and one digital tube to display all information. (As figure 9) In ready status, the digital tube could twinkle with “－”, it indicates the position of the door: Top indicates opening position;... -
Page 8: Function Setting
press “set”, you will go out of setting status. If there is not any pressing button operation in 25 seconds, it will go out of setting status. 4.3. Function setting 4.3.1. Auto detect Function: Auto detect photo beam, opening and closing door position and loading force. Press button “set”... -
Page 9: Fault Information
4.4. Fault information The S66 opener could auto detect the error during running, and display the error information. When error occurs, digital tube could display the error code, the radix point will also flash quickly. After 5 seconds of flash of error information, it will automatically recover to display normally. -
Page 10: Locking Door By Hand
5. Locking door by hand As shown in Figure 10, if the door is open when power off, you can disconnect clutch, pull the door to close position by hand, the door can be locked in the limitation hole of rail. When power on, it is not necessary to open lock by hand, only operate remoter or push button directly. -
Page 11: Push Button Installation
required to distinguish. Note: Wiring should be beautiful and neat, and use the clamper to fix. After finishing installation, the right and left lens of photo beams should in the same line, and the setting of “PH” should be “1”or “2” in the second level setting, otherwise the photo beams will not function. 6.2. -
Page 12: Trouble Shooting
9. Trouble shooting Trouble Reason Solution The opener can’t work, without ●Opener is not power on ●Switch on the power, inspect display on LED ●Fuse of main control board “ POWER” socket damaged ●Change the same type fuse. The opener can’t work, LED ●Travel adjustment error ●Readjust limit position display 1.
