- Page 1 RDO-7W Installation and Operating Instructions Owners Copy: Please keep the instructions for future reference This manual contains IMPORTANT SAFETY information DO NOT PROCEED WITH THE INSTALLATION BEFORE READING THOROUGHLY Version number: RDO-7W...
- Page 2 START BY READING THESE IMPORTANT SAFETY INSTRUCTIONS WARNING • Failure to comply with the following instructions may result in serious personal injury or property damage. • Read and follow all instructions carefully. • The garage door opener is designed and tested to offer safe service provided it is installed and operated in strict accordance with the instructions in this manual.
- Page 3 IP RATING CHART Protection of persons and protection of equipment indicated by the IP Protection provided by enclosures code. for electrical equipment is indicated by the IP codes two: CHARACTERISTIC NUMERALS The first numeral indicates The second numeral indicates protection of persons protection of equipment against access to against harmful ingress of...
- Page 4 CONTENTS READ BEFORE INSTALLATION SAFETY INSTRUCTIONS ......................1 IP RATING CHART ........................2 INSTALLATION 1 KIT CONTENTS ......................... 4 2 TOOLS REQUIRED ........................4 3 DOOR REQUIREMENTS ......................4 4 TESTING THE DOOR ....................... 5 5 INSTALLING THE STOP COLLAR ................... 5 6 INSTALLING THE WEIGHT BAR (OPTIONAL) ................
- Page 5 KIT CONTENTS TOOLS REQUIRED 1. Opener 1. Adjustable wrench for U-bolts already installed on the door 2. Clamp bracket 2. 8 mm socket, 10 mm socket and 13 mm extended socket 3. keys and socket wrench 4. Warning label 3. 300 mm socket extension (for minimum side-room 5.
- Page 6 TESTING THE DOOR Complete the following test to ensure your door is well balanced, and not sticking or binding: • Disable all locks and remove any ropes connected to the garage door. • Lift the door to about halfway and then release it. The door should remain spring balanced.
- Page 7 CONTROL PANEL 1. Terminal Block: used for external accessories (see chart below). carving Function Polarity Comment 24v dc 50 mA accessory output available for a universal Accessory Power receiver (output not active in Low Standby mode) IR Beams IR Beam Input: (pulsing type only) Common terminal for push button, IR Beams &...
- Page 8 THE RELEASE HANDLE & CORD DO NOT DISENGAGE THE OPENER TO MANUAL OPERATION WITH CHILDREN, PERSONS OR OTHER OBJECTS INCLUDING MOTOR VEHICLES WITHIN THE DOORWAY: (The door is under significant tension and if the door has developed a fault or incorrect tension, it may be unsafe and may fall rapidly.) The manual release mechanism enables the door to be manually operated during power outages or in an emergency.
- Page 9 PINNING THE DOOR Note: A ballooning door may delay the safety reversal Free curtain Ballooning Add fasteners here response and can compromise garage door security. • To remedy any ballooning place self tapping metal screws or rivets where the curtain leaves the roll. Secure these through the curtain into the drum wheel at each end of the roll.
- Page 10 INSTALLATION PROCEDURE Do not allow people to walk under or around the door during the installation process as serious injury can occur. NOTE: The opener can be installed on either side of the door. The following instructions are for RIGHT SIDE INSTALLATIONS (as illustrated i.e. Rope inside the garage looking out).
- Page 11 SETTING INSTALLATION SIDE / TRAVEL LIMITS / CLOSING FORCE Setting Travel Limits means how far your door goes up and down. Your opener must also be configured for right or left side installation, if not the door will rotate in the reverse direction. NOTE: The opener is factory configured for right side installation.
- Page 12 Long press (About 4 seconds) Adjust the gear Confirm Setting TESTING CLOSE DIRECTION FORCE Testing Close Direction Force is important. The garage door must reverse on contact with a 40 mm obstacle laid flat on the floor. Failure to properly adjust the opener may result in serious personal injury from a closing garage door.
- Page 13 AUTO CLOSE MODE Auto close is NOT recommended for households with young children. NOTE: IR beams should be installed before the Auto Close Mode is turned on ● Operate the door in the down direction. The door must reverse upon contact with the obstacle.
- Page 14 Long press (less than 8 seconds) The storage is full 4. Remove all remote controls: Long press "CODE" key (more than 8 seconds). The yellow light will go off after flashing and return to standby mode, indicating that all remote-control devices have been cleared. Long press (more than 8 seconds) The yellow light goes out Removal succeeded...
- Page 15 Long press (About 4 seconds) half-open function has been turned on 2. Cancel half-open function: First, close the door to the closing position, and then press the “SET” key and the “UP” key at the same time for about 4 seconds, then you can hear a long beep, and the red light flashed once. It indicates that the half-open function has been cancelled.
- Page 16 TYPICAL WIRING DIAGRA Information for Service Personnel NOTE: The terminal block is weather protected by a rubber grommet. When using external wiring, the cable holes can be punched through with a small screwdriver. These holes should be sealed with silicon sealant in order to maintain the weatherproof rating. +24V PE GND External...
- Page 17 OPERATION OF YOUR OPENER Your opener can be activated by any of the following devices: • Opener Control Panel: UP & DOWN buttons • Remote Control Transmitter: The key that have been coded • Wireless wall switch: Code key (Optional) •...
- Page 18 TROUBLESHOOTING 1. The opener will not operate from either the 9. The opener motor hums briefly, then will not UP/DOWN ACTIVATION button or the transmitters: work: • Does the opener have electric power? Plug a lamp into • Check that the door is not in manual release mode. the outlet.
- Page 20 Installation and Operating Instructions Owners Copy: Please keep the instructions for future reference http://www.eazylift.com.cn/ Version number : ELT-EDR1020V1.0...
