Page 1: Customer Care
ALSO FROM IFB MICROWAVE OVEN Advancing the science of washing CAPACITY - 17 to 30 LITERS DISHWASHER CAPACITY - 12 PLACE SETTING CLOTHES DRYER CAPACITY - 5.5KG Customer Care OPERATING MANUAL Dial 1860 425 5678 - BSNL & MTNL Callers 3900 4321 - Other Callers or email... -
Page 3: Table Of Contents
CONTENTS KNOW YOUR MACHINE MODEL :DIVA SERIAL NO. WT DIV B INSTALLATION Pre Installation Unpacking DEALER’S NAME : Setting Up Water Inlet CUSTOMER’S NAME : Water Outlet Electrical Connection ADDRESS : USING YOUR MACHINE PIN CODE : Control Panel Enviromental protection/conservation issues TEL. -
Page 4: Know Your Machine
INSTALLATION REPORT KNOW YOUR MACHINE IFB WASHING MACHINE Model : __________________ Serial No. : ______________Customer’s Name : __________________ ON-OFF SWITCH/PROGRAMME _________________________________________________Tel. No. ___________________________ DETERGENT DISPENSER TRAY SELECTOR KNOB Address :___________________________________________________________________________ __________________________________________________________________________________ Installation Check Points Machine Delivered on : __________________ Machine Installed on :_______________ 1. -
Page 5: Installation
INSTALLATION Pre Installation 1. It is mandatory to have a 16 amp. 3-pin 230V AC, 50Hz electrical point with a 16 amp. MCB or Automatic short circuit protection device within 1 meter of the machine. Make sure it has proper earthing. 2. -
Page 6: Dealer's Name
6. Remove transit bolts. 7. Insert plastic caps provided into holes vacated and press till they click into place. MODEL :DIVA SERIAL NO. WT DIV B 8. Keep transit bolts carefully. They will be required in case you need to shift the machine again. -
Page 7: Water Inlet
TECHNICAL DATA Water Inlet WATER INLET 1. Connect inlet hose to water tap/line. Dimensions 55cm x 60 cm x 85 cm 2. Do not connect machine to a hot water (D x W x H ) supply. DRAIN Weight 55 kgs PIPE Capacity 5 kgs of dry clothes (cotton)*... - Page 8 Use of extension cord not recommended since it may not be Avoid the machine coming in contact with floor cleaning properly earthed. chemicals.* Use ISI marked sockets of reputed make for preventing loose Do not wash or spray water over the switch or control panel. contact of power supply cable.
-
Page 9: Control Panel
SAFETY PRECAUTIONS Ensure that the machine is properly balanced on four adjustable CONTROL PANEL feet. Ensure that the machine is connected to 3 pin socked with good Let’s take a look at the control panel and understand the working of each of its features. earth and 16 Amp MCB or other automatic short circuit Each feature serves a specific purpose in the complete operation of the machine. -
Page 10: Enviromental Protection/Conservation Issues
Environmental Protection/ Conservation Issues FAULT DIAGNOSIS Your washing machine uses water, energy and detergent efficiently, thereby protecting the environment and reducing your household costs. Why Does It Happen ? Using your washing machine in an efficient and environmentally friendly manner: WATER DOES NOT ENTER MACHINE/DETERGENT NOT BEING FLUSHED INTO DRUM. -
Page 11: Automatic Detergent Dispenser Tray
Automatic Detergent Dispenser Tray Frost Protection If the machine is being operated in very cold temperature, all Designed for automatic dispensing of detergent. The Detergent Dispenser Tray should filled with the water should be drained out after use. recommended detergent quantity before the start of a Remove Fluff Filter. -
Page 12: Programme Selection
Programme Selection Drum Rust Stains Never leave metal items e.g. paper clips, safety 1. COTTONS pins etc. in he drum as it creates superficial rust To be used for whites and coloureds of cotton or marks in drum. If there are any rust stains predominantly of cotton in case of mixed load. - Page 13 MAINTENANCE Easy Care Programme To be used for easycare fabrics like polyester blends or predominantly having such fabric in mixed load. STAGE I : Main Wash : Synthetic/delicates Clothes are soaked, tumbled in water with detergent for lesser duration than main wash Normal...
- Page 14 Programme Run Note : During the programme run the knob turns automatically in the clockwise direction only. Washing, rinsing and spining can be seen through the porthole window. At any moment the position of the knob with respect to its start position shows how far the programme has advanced.
-
Page 15: Sorting Of Garments
OPERATION Ironing The number of dots indicate the maximum recommended temperature Sorting Of Garments Machine to be used for machine washable fabrics only (Look Max 200 C,150 C, 110 C, for wash symbols given on your garments.) Non - iron Non-fast coloured should be washed with like colours only. -
Page 16: Wash Load Guide
Detergent To Be Used And Quantity Wash Load Guide Sheets Pajama/Kurta 400gms Bedspread The best washing results will be achieved by using the correct Cotton Shirt Blankets dosage of detergent . 500gms Cotton 280gms Wool 2.0kg Use the detergent as per the instructions on the detergent Others 200gms acrylic...
