Summary of Contents for IFB SENORITA PLUS
-
Page 3: Table Of Contents
CONTENTS KNOW YOUR MACHINE INSTALLATION Pre Installation Unpacking Setting Up Water Inlet Water Outlet Electrical Connection USING YOUR MACHINE Control Panel Automatic Detergent Dispenser Tray Selector Buttons On/Off Switch with Temperature Selector Knob Programme Selector Knob Indicator Lamp Kinds of Wash Programmes Programme Selection Programme Selection Chart OPERATION... -
Page 4: Know Your Machine
ADVANTAGES OF TUMBLE WASH ADVANTAGES OF TUMBLE WASH MOST EFFECTIVE CLEANING AS THE CLOTHES PASS THROUGH SOAPY WATER AND ALSO FALL ON SOAP SOLUTION IMPROVING WETTING OF CLOTHES. RESEMBLES THE THUMPING AND RUBBING ACTION OF GENTLE HAND WASH. USES LESS WATER COMPARED TO TUB TYPE TOP LOADERS. LESS WATER MEANS LESS DETERGENT AND ELECTRICITY CONSUMPTION. -
Page 5: Installation
INSTALLATION PRE-INSTALLATION 1. Make sure there is a 16 amp. 3-pin electrical point preferably with a 16 amp. fuse, within 1 meter of the machine. Make sure it has proper earthing. 2. Fixed plumbing is recommended for the machine. water inlet of the WATER machine has a collar with3/4”parallel SUPPLY... -
Page 6: Setting Up
SETTING UP 1. MAKE SURE THAT THE MACHINE RESTS ON ALL FOUR FEET ON A LEVEL SURFACE.Adjustable screws are provided at the bottom to allow levelling. 2. Loosen securing nut. Adjust the screw to change level. Tighten securing nut to ensure that screw is locked into place. -
Page 8: Automatic Detergent Dispenser Tray
AUTOMATIC DETERGENT DISPENSER TRAY Designed for automatic dispensing of detergent as required, which avoids manual filling at each stage. The Detergent Dispenser Tray should be filled with detergent before the start of a programme. The tray has two chambers. 1. Pre-wash chamber: (Marked-I),to be filled with detergent in case a pre-wash programme has been chosen or heavily soiled clothes are being washed. -
Page 9: On/Off Switch/Temperature Selector Knob
ON/OFF SWITCH & TEMPERATURE SELECTOR KNOB To switch ON the machine and offer a choice of temperature settings to suit the kind of fabric being washed. To be turned clockwise from position ‘OFF’ to position ‘ON’ to switch ON the machine. A glowing indicator lamp indicates the machine is ON. -
Page 11: Programme Selection
PROGRAMME SELECTION 1. Cotton Programme STAGE 1 : Pre-Wash Clothes are soaked, tumbled in hot water with detergent to remove dirt and dirty water is pumped out. IN CASE CLOTHES ARE NOT HEAVILY SOILED, THE “PRE-WASH” CAN BE AVOIDED BY SETTING THE PROGRAMME SELECTOR KNOB TO ANY OF THE MAIN WASH PROGRAMMES. - Page 12 IN CASE CLOTHES ARE NOT HEAVILY SOILED, THE “PRE-WASH” CAN BE AVOIDED BY SETTING THE PROGRAMME SELECTOR KNOB TO ANY OF THE MAIN WASH PROGRAMMES. STAGE II : Main Wash - Normal wash / Delicates Clothes are soaked, tumbled in hot water with detergent for lesser duration than main wash of Normal Wash programme.
- Page 13 Exclusive spin drying programmes : Intense Spin & Short Spin Dry Can be used for spin drying hand washed / wet clothes. Turn programme selector knob directly to any of the spin drying points after loading the clothes. Switch ON the machine. IN CASE ELECTRICITY / WATER SUPPLY GOES OFF, THE MACHINE STOPS AND STARTS AGAIN FROM THE SAME POINT, AUTOMATICALLY , ON RESUMPTION OF ELECTRICITY / WATER SUPPLY.
-
Page 14: Programme Selection Chart
1. To select the right programme for your wash, a tabulated programme Chart is given on the Detergent Dispenser Drawer to indicate fabric type and wash temperature. PROGRAMME DETERGENT IN CHAMBER SELECTION WITH WITHOUT PRE-WASH PRE-WASH 1. Pre wash 2. Heavy wash 3. -
Page 15: Operation
OPERATION SORTING OF GARMENTS Machine to be used for machine washable fabrics only (Look for wash symbols given on your garments.) Wash woollens separately only if label on garments permits it. Non-fast coloured should be washed with like colours only at lower temperature . -
Page 16: Detergent To Be Used And Quantity
DETERGENT TO BE USED AND QUANTITY The best results will be achieved using correct amount of washing machine detergent. Approximate quantities to be used: Full load i.e. 5 kgs Detergents to be used as per directions indicated by the manufacturer on their package or with selfjudgement. -
Page 17: Wash Load Guide
WASH LOAD GUIDE Sheets Pajama/Kurta 400gms Cotton Shirts 500gms Cotton 280gms Others 200gms Other than Cotton (D) 650gms Blouses: 400gms cotton 140gms others 100gms Pillow slips: Sarees: Cotton 110gms Cotton 650gms others 85gms Synthetics 350gms Panties 60gms Bath towels 600gms Socks: Hand towels 260gms... -
Page 19: Programme Run
PROGRAMME RUN Note: During the programme run the knob turns automatically in the clockwise direction only. Washing, rinsing and spinning can be seen through the porthole window. At any moment the position of the knob with respect to its start position shows how far the programme has advanced. -
Page 20: Maintenance
MAINTENANCE FLUFF FILTER Open door flap by pressing on the right Clean filter under running water hand edge and pull out the plastic tray. Place shallow container under the tray to Replace filter and screw on tightly to collect water that comes out. ENSURE THAT THE FLUFF FILTER IS NOT BLOCKED, CLEAN WEEKLY OR AS OFTEN AS REQUIRED. -
Page 21: Drum
DRUM Rust Stains Never leave metal items e.g. paper clips, safety pins etc. in the drum as there is a danger of rusting. If there are any rust stains remove with a non-chlorine agent. Special non-metal sponges (never use steel wool) may also be used. SIEVES Cleaning of Water connection Sieves, filter Turn off Taps. -
Page 22: Fault Diagnosis
FAULT DIAGNOSIS WHY DOES IT HAPPEN? PILOT LAMP DOES NOT GLOW. Check if the machine is ON. Check for loose connections in plug/socket. Check for blown fuse WATER DOES NOT ENTER MACHINE/DETERGENT NOT BEING FLUSHED INTO DRUM. Check water supply Porthole door not firmly closed Water tap not turned on Bent inlet hose... -
Page 23: Safety Precautions
SAFETY PRECAUTIONS 1. Ensure that the machine is properly balanced on four adjustable feet. 2. Ensure that the machine is connected to 3 pin socket with earth and 16 amps fuse 3. The machine is tested with water during assembly for performance checking. -
Page 24: Technical Data
TECHNICAL DATA Dimensions(DxWxH) 56 cm x 60 cm x 85 cm Weight 60 kgs Capacity 5 Kgs of dry clothes (cotton)* Programmes 15 Wash Care Programmes Selector Buttons Water Plus, Spin Cancel Motor Rating 690 Watts (max) Spin Speed 600 rpm Heater Rating 1.55 kW Drum... - Page 26 MODEL : SENORITA PLUS SERIAL NO. WTSEN PL B DEALER’S NAME : CUSTOMER’S NAME : ADDRESS : PIN CODE : TEL. NO. (Resi.) (Off.) E-MAIL : MOTOR SR. NO. : DATE OF PURCHASE : MODEL : SENORITA PLUS SERIAL NO. WTSEN PL B DEALER’S NAME :...
- Page 27 ALSO FROM IFB MICROWAVE OVEN CAPACITY - 17 to 30 LITERS DISHWASHER CAPACITY - 12 PLACE SETTING CLOTHES DRYER CAPACITY - 5.5KG IFB Industries Limited, Plot No. IND - 5, Sector - 1, East Calcutta Township, Calcutta - 700 078...
