WASHING MACHINE USER MANUAL

Senator VSS 8012

Senator MXS 8012

Senator SXS 8012

UF421PKMAN622 H

Table of Contents

Need help?

Do you have a question about the DeepClean Senator VSS 8012 and is the answer not in the manual?

Questions and answers

Summary of Contents for IFB DeepClean Senator VSS 8012

Page 1 WASHING MACHINE USER MANUAL Senator VSS 8012 Senator MXS 8012 Senator SXS 8012 UF421PKMAN622 H...
Page 3 Welcome to the IFB Family Get ready to experience excellence in washing and long lasting peace of mind. Happy Laundry Days to you! Front Load Washer...
Page 4: Table Of Contents
Contents The A to Z of Your Washing Machine The Display Panel Safety Guidelines Installation Instructions Caution About eWaste Section 1 Getting Started With Your Washing Machine Installation and Safety Guidelines Before You Start Section 2 Running Your Machine 6 Easy Steps For Doing Your Laundry Finishing Program Guide Wash Options...
Page 5 PRECAUTIONS This appliance meets the required safety standards, but using it improperly could cause injury or property damage. Make sure to read this manual carefully—it covers safety, installation, use and maintenance. Use detergents with low foam to prevent any problems. Following these guidelines will help you get the most out of your new washing machine and keep it running smoothly while avoiding accidents or damage.
Page 6: The A To Z Of Your Washing Machine
The A to Z of Your Washing Machine Program Display Start/ Top Lid Power Selector Panel Pause Detergent Dispenser Drawer Door Handle Porthole Door Adjustable Feet Filter for Levelling Cabinet Door...
Page 7 The A to Z of Your Washing Machine Power Display Program Selector Spin Temperature Options Select Start/Pause...
Page 8: The Display Panel
The Display Panel SPIN Button to select the different Spin Speeds available. TEMP Button to select the different Temperatures available. OPTIONS Button to select the Options available. SELECT Button to select the different options available corresponding to the program. START/PAUSE Touch this button once to Start or Pause the machine.
Page 9 The Display Panel Start/Pause: Glows when program is running, ﬂashes during Pause mode. Glows to indicate the Time left. Glows to indicate the Maximum Capacity of the program in Kg. Glows during selection of Temperature. Glows during selection of Spin Speed. Spin Cancel: Glows when Spin Speed ‘0’...
Page 10 The Display Panel OPTIONS The corresponding options will— GLOW when selected, FLASH if available for selection and remain OFF if not selectable. Tap: Glows when water is ﬁlling. Drain: Glows when water is draining. Door—Shows Door Status. Glows when door is open, ﬂashes when door is unlocking and remains OFF when door is locked.
Page 11: Safety Guidelines
ﬁtters, electricians, or technicians. All washing machine installation work must be carried out only by authorised IFB Care Service Personnel. Use only the new hoses provided with the machine; old hoses should never be reused.
Page 12 Your machine comes with ventilating openings on the base. Always put it directly on the ﬂoor after removing any carpets. Keep your machine safe from direct sunlight and rainfall. Avoid installing the machine in damp areas or bathrooms exposed to direct showers Don’t put the machine on a sloping, uneven, or unstable surface.
Page 13: Instructions
(like fusing, voltage and frequency) match your electricity supply. If you’re not sure, reach out to IFB Care for help. Avoid washing or drying articles contaminated with combustible or explosive substances, such as oil, paint, gasoline, or solvents, to prevent ﬁre or explosions.
Page 14: Caution
Caution A WORD OF WARNING The manufacturer isn’t responsible if there’s a problem with the earthing system. Make sure your machine is connected to a grounded outlet with a 16A Fuse or MCB. If you’re unsure whether the machine is properly grounded, get it checked by a qualiﬁed technician or licensed electrician.
Page 15 Only use a new hose kit to connect your machine to the water supply on site. Don’t try to reuse old hoses. If any parts need replacing, make sure to use genuine IFB spare parts. That way, you can be sure your machine meets safety standards.
Page 16 Caution Keep your machine dry to avoid corrosion/rusting. Don’t spill water on the machine. If spills occur, wipe it dry. Your machine should be kept away from ﬂoor cleaning chemicals. Don’t wash or spray water over the switch or control panel. Keep the machine dry to prevent corrosion and rusting.
Page 17: Use Of Appliance
Caution Your machine has been built according to current safety requirements. During assembly, the machine is tested with water to make sure it performs correctly. Sometimes, a few water droplets may be left inside the drum. Replace the trolley immediately if excessive vibrations are observed, as it can affect the machine’s reliability and lifespan.
Page 18: About Ewaste
About eWaste eWaste, or Waste Electrical and Electronic Equipment (WEET), refers to discarded appliances using electricity. To responsibly manage eWaste, follow the guidelines below. • Always dispose of end-of-lifecycle products by contacting an authorised local eWaste recycler. • Do drop off used electronic products, batteries, or accessories at authorised eWaste recyclers.
Page 19 Provisions of Hazardous Substances outlined in eWaste Management Rule, 2016. FOR DETAILED INFORMATION AND DISPOSAL REQUEST Contact IFB Care at 080 695 45678. Provide your details to our representative to arrange for proper product disposal.
Page 20: Getting Started
Getting started with your washing machine SECTION Installation and Safety Guidelines SELECTING THE RIGHT SPOT Place the machine on a level ﬂoor. Make sure the machine is close to both water and electrical connections. REMOVING TRANSIT BOLTS Use a spanner to remove the transit bolts.
Page 21 Getting started with your washing machine SECTION Installation and Safety Guidelines LEVELLING Level the machine by using adjustable screws, as shown. Make sure all 4 feet are grounded. Levelled Levelled Locked and Locked...
Page 22 Getting Started With Your Washing Machine SECTION Installation and Safety Guidelines CONNECTION TO WATER SUPPLY The water inlet of the machine has a collar with parallel internal threads. Water supply point with a ¾” external/parallel thread should be within 1 m of the machine. Don’t stretch the water supply hose.
Page 23 Getting Started With Your Washing Machine SECTION Installation and Safety Guidelines CONNECTION TO DRAIN HOSE (contd) Is the sink on the left side? Follow this diagram. 100 cm Is the sink on the right side? Follow this diagram. 140 cm...
Page 24: Before You Start
Getting Started With Your Washing Machine SECTION Installation and Safety Guidelines ELECTRICAL CONNECTION A 16 Amp, 3 pin 220-240 V AC, 50 Hz electrical point with a 16 Amp MCB within 1 m of the machine is mandatory. Make sure your home has proper earthing and the connection between the socket...
Page 25: Running Your Machine
Running Your Machine SECTION 6 Easy Steps for Doing Your Laundry SORT THE LAUNDRY Pre treat collars, cuffs and stains. Check for wash care symbols. Close zippers, hooks and strings. Empty the pockets of your clothes.
Page 26 Running Your Machine SECTION 6 Easy Steps for Doing Your Laundry LOAD THE LAUNDRY Make sure the laundry drum is empty. Load garments one by one. Close the door and press till you hear a click.
Page 27 Note To be used to dispense Fragrances (Sensora) only during Refresh cycle. If liquid detergent is used, use the liquid detergent Additives/Fragrances dispenser supplied in the (IFB Sensora) main wash chamber. Liquid Detergent Dispenser...
Page 28 Running Your Machine SECTION Note Always use detergents that are recommended for front load washing machines. Using the wrong detergent can cause laundry issues. Avoid using soap ﬂakes or granulated soap powders in your washing machine. When washing woollens or silk, make sure to use the detergent type recommended by the manufacturer.
Page 29 Running Your Machine SECTION 6 Easy Steps for Doing Your Laundry SELECT PROGRAM Switch ON the machine. Turn the Program Selector knob to the required program. Start/Pause LED will ﬂash. Choose Wash Option. To change/cancel the program during the wash, press the Power ON/OFF button and wait for 2 secs, then select...
Page 30 Running Your Machine SECTION 6 Easy Steps for Doing Your Laundry START WASHING (contd) Door status will be displayed after pressing the Start/Pause button. If the Water Level inside the drum is above the rubber or the temperature inside the drum is high, the door won’t open.
Page 31: Finishing
Running Your Machine SECTION Finishing Remove the laundry and wipe the moisture from the door and door seal. Leave the door slightly open. Wipe the panel and cabinet with a dry cloth to remove the moisture. Turn OFF the tap.
Page 32: Program Guide
Running Your Machine SECTION Program Guide PROGRAM TYPE OF LAUNDRY Mixed Soiled Cotton, synthetic and easy-care garments. Not recommended for special garments like silk/delicates, dark clothes, wool, duvets, curtains, etc. Cotton Normal Cotton colour-fast garments. /Cotton Eco Shirts, pants, uniforms, bed and table linen, Plus/Uniform towels, night dresses, pyjamas, underwear, etc.
Page 33 Running Your Machine SECTION Program Guide PROGRAM TYPE OF LAUNDRY Woollens Machine washable woollen garments only. Use appropriate detergent. Sports Wear Singlets, leggings, jogging clothes and running wear. Machine washable curtains made of cotton Curtains and easy care fabrics. Washes large items such as blankets, bedcovers, sofa covers, pillow cases and bedspreads.
Page 34: Wash Options
Running Your Machine SECTION Wash Options OPTIONS Details Temperature Temp You can change the default temperature in the given range. Press the Temperature button on the control and select from Cold, 30°C, 40°C, 60°C, 95°C, P-°C, P 30°C, P 40°C, P 60°C, P 95°C, and Repeat.
Page 35 Running Your Machine SECTION Wash Options OPTIONS Details Pre Wash If Pre Wash option is selected, the clothes are given Select a preliminary wash before the main wash. Press the Options button on the control panel to select the Pre Wash option. The Pre Wash option name and corresponding symbol will ﬂash on the display.
Page 36 Running Your Machine SECTION Wash Options OPTIONS Details Extra Rinse A maximum of 2 additional rinses can be selected. Select Press the Option button on the control panel till the Extra Rinse option name and its corresponding symbol ﬂash. Press the Select button to select or deselect Extra Rinse option within 8 secs.
Page 37 Running Your Machine SECTION Wash Options OPTIONS Details Time Saver This option allows you to save time by decreasing Select the programmed wash time. Press the Option button on the control panel till the Time Saver option name and its corresponding symbol ﬂash.
Page 38 Running Your Machine SECTION Wash Options OPTIONS Details Rinse Hold If clothes are left unattended for a long time it Options may cause creasing. This option pauses the program during its ﬁnal rinse to prevent this. ‘rinS HOLd’ message will appear on the display. You can cancel the current program or input your desired Speed/Spin and continue.
Page 39 Running Your Machine SECTION Wash Options OPTIONS Details Tub Clean Run this program to eliminate impurities, scaling, bacteria and unpleasant smell from the washing machine. IMPORTANT Do not put laundry in the washing machine during Tub Clean. Before running the Tub Clean program, empty the washing machine drum.
Page 40 Running Your Machine SECTION Wash Options OPTIONS Details Tub Clean Reminder The Tub Clean program reminder will appear on your washing machine after every 40 wash cycles. You can run the Tub Clean program or skip. It is recommended to run the Tub Clean program after every 40 cycles to keep your washing machine clean.
Page 41 Running Your Machine SECTION Washing Symbols—A Guide RESISTANT MATERIAL DELICATE FABRIC WASHABLE AT 95°C WASHABLE AT 60°C WASHABLE AT 40°C WASHABLE AT 30°C HAND WASH DRY CLEAN ONLY WOOL SEAL BLEACHABLE IN COLD WATER DON’T BLEACH DON’T DRY CLEAN DRY FLAT HANG TO DRY DRY ON CLOTHES HANGER TUMBLE DRY, NORMAL HEAT...
Page 42: Wash Guide Map
Running Your Machine SECTION Wash Guide Map LAUNDRY WEIGHT in KG PROGRAM Mixed Soiled Temperature °C Cold, 30, 40 Spin Speed RPM 400–1000/No Final Spin Cotton Normal Temperature °C Cold, 30, 40, 60, 95 Spin Speed RPM 400–1200/No Final Spin Anti Allergen Temperature °C 40, 60...
Page 43 Running Your Machine SECTION Wash Guide Map LAUNDRY WEIGHT in KG PROGRAM Cotton Eco Plus Temperature °C 40, 60** Spin Speed RPM 400–1200/No Final Spin Synthetic/ Daily Temperature °C Cold, 30, 40, 60 Spin Speed RPM 400–800/No Final Spin Cradle Wash®...
Page 44 Running Your Machine SECTION Wash Guide Map LAUNDRY WEIGHT in KG PROGRAM Woollens Temperature °C Cold, 30, 40 Spin Speed RPM 400–800/No Final Spin Sports Wear Temperature °C Cold, 40 Spin Speed RPM 400–800/No Final Spin Curtains Temperature °C Cold, 40, 60 Spin Speed RPM 400–800/No Final Spin Uniform Temperature °C Cold, 40, 60...
Page 45 Running Your Machine SECTION Wash Guide Map LAUNDRY WEIGHT in KG PROGRAM Spin Dry/ Drain Temperature °C Spin Speed RPM 400–1200/No Final Spin Additives/ Rinse+Spin Temperature °C Spin Speed RPM 400–1200/No Final Spin Tub Clean Temperature °C Cold, 60, 95 Spin Speed RPM Note ** Program setting for BEE test in conformity with IEC 60456 with 1400 Spin Speed selection settings.
Page 46 Running Your Machine SECTION Wash Guide Map Note With Cotton Eco 60** program, the actual wash temperature attained will be lower than 60°C, although the wash performance will be at par with the Cotton 60°C program. The actual performance of the machine can vary based on a few factors like water pressure, water hardness, temperature, the amount and type of laundry, detergent used, and other conditions like foam or unbalance detection.
Page 47: Key Features
Running Your Machine SECTION Key Features ADVANCED WASH TECHNOLOGY Powered by Ai Available on selected models only The intuitive sensing logic in the machine detects two parameters important for fabric care during cleaning— · Type of fabric Cotton, Mixed or Synthetic ·...
Page 48 Running Your Machine SECTION Key Features ADVANCED WASH TECHNOLOGY Aqua Energie The technology that energises water to carry the detergent deep into the fabric. CradleWash® India’s ﬁrst wash program for the care of delicate fabrics. Crescent Moon Drum The crescent moon design of the drum allows the water to cushion the wash and protect the fabric.
Page 49 Running Your Machine SECTION Key Features WASH PROGRAMS AND OPTIONS More than 100 thoughtfully designed programs and options to give your clothes the ultimate wash experience. Time, Energy, Water Saving Cotton Eco Plus, Express Wash Time Saver Fabric Friendly Wash Cotton Normal, Synthetic/Daily, CradleWash®, Woollens, Mixed Soiled...
Page 50: Machine Care
Running Your Machine SECTION Key Features MACHINE CARE Auto Tub Clean Automatically ensures tub hygiene after the wash. Auto Foam Control System Auto detection and control of excess foaming. High-Low Voltage Protection A microcontroller continuously monitors the voltage ﬂuctuations and stops the program if it goes below 150±...
Page 51 Running Your Machine SECTION Key Features USER CONVENIENCE Child Lock Prevents children from tampering with the machine settings. Laundry Add Lets you add laundry even after the cycle has started. Anti Crease Reduces wrinkling of clothes for easy ironing.
Page 52: Your Machine
Get More From Your Machine SECTION Tips for best results BEFORE WASHING Empty all pockets. Remove everything including coins, keys, pins, notes etc. Close all zips and fasten all hooks. Check the wash care label and avoid non-machine washable items. WHILE SORTING Separate polyester fabrics from cotton.
Page 53 Put the stained area face down on a paper towel or white cloth. Apply the stain remover You can also use to the back of the stain so IFB Fabo Stain Remover that the stain is forced for stubborn stains out of the cloth.
Page 54: Stain Treatment
Get More From Your Machine SECTION Stain Treatment...
Page 55 Get More From Your Machine SECTION Stain Treatment STAIN TREATMENT Use ice in a plastic bag to harden the gum. Chewing gum Adhesive Scrape off what you can and then sponge Tape with white spirits. Rubber Cement Blood Rinse and soak immediately in cold water with an enzyme pre wash.
Page 56 Get More From Your Machine SECTION Stain Treatment STAIN TREATMENT Treat as soon as possible by sponging with Fruit cold water. Rub a little detergent on the stain and wash. Grass Sponge with white spirits. Rub in an enzyme pre wash and then wash. Grease Sponge with white spirits or dry-cleaning ﬂuid and then wash.
Page 57 Get More From Your Machine SECTION Stain Treatment STAIN TREATMENT Treat while still wet. Rinse in warm water Water Based Paint and wash. Scorch Marks Dampen a cloth with hydrogen peroxide. Lay it over the affected area and press with a hot iron. Some inks are impossible to remove.
Page 58: Maintenance And Cleaning
Get More From Your Machine SECTION Maintenance and Cleaning CLEANING THE DETERGENT DISPENSER DRAWER Remove detergent residue regularly. Clean the detergent dispenser drawer with warm water. Remove and clean the siphon under running warm water. Detergent residue can build in the dispenser housing, clean it before reinstalling the dispenser.
Page 59 Get More From Your Machine SECTION Maintenance and Cleaning CLEANING THE WATER HOSE MESH FILTER Turn OFF taps and disconnect the power supply to the machine. Unscrew the inlet hose from the machine and tap the drain water from the hose. Remove the ﬁlter mesh from the tap end of the inlet hose and clean under...
Page 60 Get More From Your Machine SECTION Maintenance and Cleaning CLEANING THE FILTER The ﬁlter should be cleaned frequently in order to increase the life of the drain pump. Open the detachable bottom door with a coin or a key. Place a shallow container near the bottom drawer.
Page 61 Get More From Your Machine SECTION Let’s make washing easier. Here is a list of clothes and their approximate weights to help you figure out a perfect wash load. CLOTHING WEIGHTS Bottoms Sheets Lungi/Dhoti 200 g Cotton (Double) 1 Kg Skirts 200 g Cotton (Single)
Page 62 Get More From Your Machine SECTION This table may help you plan a laundry load of 8 Kg. LAUNDRY ITEMS 8 Kg Bath Towels Shirts Blouses Skirts Pair of Pants Pair of Jeans T-shirts Set of Pyjamas Tea Towels The chart indicates average weights of clothes.
Page 63: Useful Information
Opening the door Check if the machine is not possible. is displaying the ‘dL Er’ message. Child Lock is active. Disable the Child Lock and wait until the Door display glows. If the problem persists, contact IFB Care.
Page 64 Machine door is not Close the machine securely closed. door properly. Inlet hose is bent, Straighten the inlet sieve, inlet valve or hose. Check; unclog the hose is clogged. the sieve, valve and hose. If the problem persists, contact IFB Care.
Page 65 Check and tighten the Inlet hose Water leakage inlet hose connection. connection is loose. in the machine. Filter is not securely Check and tighten tightened. the ﬁlter. Inlet hose is leaking. Contact IFB Care. If the problem persists, contact IFB Care.
Page 66 Clean and ensure that Filter is partially the ﬁlter is unclogged. clogged. Add a few clothes to Load is unbalanced. balance the load. Rearrange the load to allow proper spinning. If the problem persists, contact IFB Care.
Page 67 Select the Start/Pause is active. button at Rinse Hold stage. Filter is clogged. Clean and ensure that the ﬁlter is unclogged. Excessively foaming Use detergents detergent is used. recommended for Front Load Washing Machines only. If the problem persists, contact IFB Care.
Page 68 Use only the required Blue stains fabric additives. amount of fabric on clothes. additives. Do not pour additives directly on the fabric. Additives of inferior Use good quality fabric quality being used. additives. If the problem persists, contact IFB Care.
Page 69 Excessive use of Use proper amount detergent. of detergent. Cold wash program. Use hot wash program. Button not pressed All the buttons are Buttons not properly. sensitive and need working. to be pressed softly. If the problem persists, contact IFB Care.
Page 70 In case of a disbalance in load, the machine Balance time makes attempts to redistribute the clothes on display remains to minimise vibrations. This can extend the unchanged. duration of the program. If the problem persists, contact IFB Care.
Page 71 Useful Information About Your Washing Machine SECTION Display THE LED DISPLAY GIVES YOU COMPLETE INFORMATION • Program Selection • Wash Option Selection • Program Balance Time • Program Status • Problem/Fault Indications, if any • Child Lock Selection • Door Status...
Page 72: Display & Error Codes
SECTION Display Messages & Error Codes For any code displayed that is not present in the following list or if the suggested solution does not ﬁx the problem, contact IFB Care or an authorised dealer. DISPLAY PROBABLE CAUSE SOLUTION rinS HOLd—Indicates...
Page 73 2 secs. Run door area. Drain program. After END, rearrange the clothes and restart the required program. If the same message appears again, switch OFF the appliance and contact IFB Care.
Page 74 2 secs and restart. If the same message appears again, switch OFF the appliance and contact IFB Care. Switch OFF the washing machine, wait for 2 secs and restart. If the same message appears again, turn...
Page 75 Add a few clothes to balance and rearrange to allow proper functioning. For further assistance please download My IFB App for service registrations or you call us on our call centre number 08045845678/ 080 695 45678...
Page 76: Technical Specifications
Useful Information About Your Washing Machine SECTION Technical Specifications Senator VSS 8012 MODEL Senator MXS 8012 Senator SXS 8012 POWER SUPPLY 220–240 V Single Phase 50 Hz DIMENSIONS 598 x 624 x 875 Net Size WxDxH NEW WEIGHT 71 Kg CAPACITY 8.0 Kg Dry Cotton WASH CARE...
Page 77: Revisions Sheet
Senator VSS 8012 Senator MXS 8012 Senator SXS 8012 Characteristic Symbol Critical (Cc) Significant (Sc) MATERIAL MANUAL No Revision Paper UF421PKMAN622 IFB Industries Limited, Goa Rev Information Date Change Checked Date Approved Date New Model Changed 18/02 steam by 2022...
Page 78 +91 080 458 45678/080 695 45678 +91 92310 04321 www.ifbappliances.com...

This manual is also suitable for:

Deepclean senator mxs 8012Deepclean senator sxs 8012Uf421pkman622 h
