Summary of Contents for IFB Elite 5 Kg
- Page 1 CLOTHES DRYER CAPACITY - 5.5KG OPERATING MANUAL IFB Industries Limited, Plot No. IND - 5, Sector - 1, East Calcutta Township, Calcutta - 700 078 Visit us at www.ifbappliances.com USE ONLY GENUINE IFB SPARES & ACCESSORIES * Company shall not be responsible for defects arising due to usage of spurious parts and accessories...
- Page 3 CONTENTS KNOW YOUR MACHINE INSTALLATION MODEL : ELITE 5KG SERIAL NO. WTEL5kgB Pre Installation Unpacking Setting Up DEALER’S NAME : Water Inlet Water Outlet CUSTOMER’S NAME : Electrical Connection USING YOUR MACHINE ADDRESS : Control Panel Automatic Detergent Dispenser Tray PIN CODE : Selector Buttons Temperature Selector Knob...
- Page 4 Temperature Programme Control Knob Selector Knob Detergent Dispenser tray Indicator Lamp handle Cotton/Linen Woolens Pump Prewash Additives Normal Rinse Light Wash Quick Short Spin Start Button Additives Rinse Start Rinse Additives Long Spin Delicates Normal Prewash Selector Synthetics/Polyester Buttons Porthole Door Special Powder Coated Door Handle...
- Page 5 INSTALLATION TECHNICAL DATA PRE-INSTALLATION Dimensions(DxWxH) 56 cm x 60 cm x 85 cm 1. Make sure there is a 16 amp. 3-pin electrical point preferably with a 16 amp. fuse, within 1 meter of the machine. Make sure it has proper earthing. Weight 67 kgs 2.
- Page 6 SETTING UP SETTING UP The machine should be ideally installed on the floor. It can be installed on any suitable platform or trolley, if desired by the customer. 1. MAKE SURE THAT THE MACHINE RESTS ON ALL Clean the shell lower and detergent tray periodically by taking out the FOUR FEET ON A LEVEL SURFACE.Adjustable detergent tray.
- Page 7 MOTOR NOISE It is normal for noises to be heard while motor is running. However wash load, belt tension and motor mounting bolt should be checked for specified limits. PUMP NOISE It is normal for noises to be heard from the pump during the start-up and final stage of draining.
- Page 8 FAULT DIAGNOSIS AUTOMATIC DETERGENT DISPENSER TRAY WHY DOES IT HAPPEN? INDICATOR LAMP DOES NOT GLOW. Designed for automatic dispensing of detergent & Check if the machine is ON. additives as required,which avoids manual filling at each Check for loose connections in plug/socket. stage.
- Page 9 DRUM Rust Stains WATER SAVE DEVICE Button (WSD) Never leave metal items e.g. paper clips, safety pins etc. in “Water Save Device” button provides an option the drum as there is a danger of rusting. If there are any rust for Reducing 15 -25% of water for Small laundry stains remove with a non-chlorine agent.
- Page 10 MAINTENANCE INDICATOR LAMP Red lamp glows when the machine is switched COIN TRAP ON and switches OFF when machine is switched OFF. TEMPERATURE SELECTOR KNOB Drain Hose Temperature to be set only if a hot wash is required, Cold Coin Drain Plug otherwise there will be a cold wash in position Trap...
- Page 11 PROGRAMME SELECTOR KNOB PROGRAMME RUN To select the right programme as per the fabric Note: being washed and extent of soilage. Woolens Woolens Cotton/Linen Cotton/Linen During the programme run the knob turns automatically in the clockwise Pump Pump Prewash Prewash Additives Additives Normal...
- Page 12 IRONING Symbols on DD TRAY The number of dots indicate the maximum recommended temperature Pre - Wash Max 200 C, Max 150 C, Main Wash Max 110 C, Additive Non - iron DRY CLEANING PROGRAMME SELECTION Cotton wash programmes (Linen) A circle symbolizes dry cleaning.
- Page 13 Absorbed stains can be removed by rubbing gently a pad containing a STAGE IV : Spin Drying: - Long Spin suitable solvent over the stain from outer edge towards centre by Clothes are loosened by tumbling to spread out & remove water. Spin drying takes place at 600 r.p.m.
- Page 14 DETERGENT TO BE USED AND QUANTITY 3.The Wool Programme : ( Woolen) The best results will be achieved using correct amount of washing STAGE I : Wash machine detergent. This programme starts directly with the main wash. Approximate quantities to be used: The programme has a built-in Gentle wash function.
- Page 15 OPERATION Cool down cycle Hot water drained after Main wash cycle can be harmful for people and SORTING OF GARMENTS environment .Hot water is cooled down by taking additional cold water Machine to be used for machine washable fabrics only (Look for automatically, which also reduces concentration of detergent, thus wash symbols given on your garments.) ensures better rinse quality and eco friendly environment.
- Page 16 PROGRAMME SELECTION CHART (EXECUTIVE ELITE 5 KGS) 1.you can refer to the detailed programme Chart given below 30 fully automatic wash programmes available with respect to fabric type, degree of soilage, wash cycle, wash temperature and wash loads. PROGRAMME SELECTION DETERGENT TEMP MIN.
