Inter-m PA-2100M Technical Specifications

Features
• 100W (PA-2100M) or 200W (PA-2200M)
of Output Power into 4Ω Ω Ω Ω Ω or 70V/100V
• Three Balanced Mic Inputs and
Two Aux Inputs
• CD/MP3 Player
• Cassette Deck with Play and Record
Capabilities
• Five-Band Equalizer
• Voice-Activated Priority Muting
via Mic1
• Four-Tone Manual Pre-Page Chime
• Pre-Amp Out (Post-Tone Controls)
for External Signal Processing
• Power Amp Input (Normalized)
for Patching of External Signals
• Two-Zone Speaker Selector Buttons
Description
The PA-2100M/2200M is a mixer/amplifier designed for
applications where a variety of music and paging sources
are required, including restaurants, banquet halls,
community centers and retail shops. It has 100W(PA-
2100) or 200W(PA-2200) of output power and offers an
auto-reverse cassette deck, CD/MP3 player, two
auxiliary inputs and three balanced microphone inputs.
All sources are mixable, with individual gain controls.
Voice-activated priority muting, with an adjustable
muting level on Mic1 for muting all other channels . A
five-band equalizer provides ±12dB tone adjustment and
a four-note chime button provides a pleasant pre-page
tone. The cassette deck features auto-reverse and
record/playback capabilities. Indication of amplifier
output levels and AC power is supplied by front-panel
LED displays. Speaker outputs are provided for either
low impedance 4Ω loads or switch-selectable70V/100V
high impedance loads. Two speaker zones for high
impedance loads are independently selectable from the
front panel. The PA-2100M/2200M is powered by 100-
120VAC or 220-240VAC 50/60Hz (depending on country
requirements), and comes packaged in a shelf-mount
enclosure.
Mixer/Amplifier
with CD/MP3/Cassette

Technical Specifications

ELECTRICAL
Rated Output (RMS)
Speaker Output/Impedance
Input Sensitivity /Impedance
MIC 1-3
AUX
AMP IN
Frequency Response
MIC 1-3
AUX
AMP IN
THD
Signal-to-Noise Ratio
MIC 1-3
AUX
CD
Type
Frequency Response
THD
Cassette Deck
Frequency Response
THD
GENERAL
Power Source
Power Consumption
Weight
Dimensions (W x H x D)
PA-2100M/
2200M
PA-2100M PA-2200M
100W 200W
20V/4Ω, 28.3V/4Ω,
70V/49Ω, 70V/24.5Ω,
100V/100Ω 100V/50Ω
1mV/20kΩ
350mV/20kΩ
1V/10kΩ
100Hz -12kHz
60Hz - 15kHz
150Hz - 12kHz
<1%
>60dB
>75dB
Single Disc
20Hz - 20kHz
Less than 0.2%
125Hz - 8kHz
Less than 2%
100-120VAC or 220-240VAC
120W 230W
31.7lbs. 39.7lbs.
14.5kg 18kg
17.3" x 7" x 15.4"
440mm x 177mm x 390mm
