3 - Connect the drive(s) to the Power Adapter

WARNING: When connecting the hard drive to the Power Adapter, please
ensure that the mini-switches (located on the main power switch) are set to the
OFF position, prior to establishing a connection. Failure to do so could result in
damage to the drive, or an electrical shock to the user.
WARNING: Do not connect the Hard Drive Adapter to the host computer, while
the host computer is in a powered state. This could result in data loss or
physical damage to the drive.
SATA Drive
a. Insert the SATA power connector
provided by the power adapter into the
power port on the rear panel of the
SATA hard drive.
40-pin IDE Drive
a. Insert the LP4 power connector
provided by the power adapter into the
power port on the rear panel of the hard
drive.

4 - Connect the Hard Drive Adapter to the host computer

a. With the host computer powered down insert the USB connector into an available
USB port on the host computer. Move the mini-switch on the Hard Drive Adapter
Power Switch to the ON position, to enable the selected drives.
b. Power on the host computer.
b. Once booted, the operating system will detect the connected adapter, and prepare
the drives for use.
