- Page 1 4-Port HDMI® Audio/Video Splitter with 2x2 Video Wall Function - 4K Actual product may vary from photos User Manual SKU#: ST124HDVW For the latest information and specifications visit www.startech.com/ST124HDVW Manual Revision: 11/22/2019...
-
Page 2: Fcc Compliance Statement
Industry Canada Statement This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada. CAN ICES-3 (B)/NMB-3(B) To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 3 This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual...
-
Page 4: Safety Statements
き回しを行い、 電気障害やつまづきの危険性など、 安全上のリスクを回避す るようにしてください。 Misure di sicurezza • I terminiali dei fili elettrici non devono essere realizzate con il prodotto e/o le linee elettriche sotto tensione. • I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o pericoli per la sicurezza. Säkerhetsåtgärder • M ontering av kabelavslutningar får inte göras när produkten och/eller elledningarna är strömförda. • K ablar (inklusive elkablar och laddningskablar) ska dras och placeras på så sätt att risk för snubblingsolyckor och andra olyckor kan undvikas. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 5: Table Of Contents
Connection Guide ............................. 3 Requirements ..................4 Installation ....................4 Operation ....................6 VideoWallApp PC Tool ..........................6 Serial Control .............................. 7 Telnet Control ............................. 8 Serial and Telnet Commands ........................ 9 Warranty ....................15 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 6: Product Diagram
Solid Green when an HDMI HDMI Display • Display Device is detected Device LED Indicators Solid Green when an HDMI HDMI Source • Source Device is detected Device LED Indicator To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 7: Rear View
Connect to a Computer using a Serial RS-232 Control • Cable for Serial Control Port Connect an HDMI Source Device HDMI Input Port • using an HDMI M/M Cable To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 8: Connection Guide
Connection Guide To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 9: Requirements
HDMI Display Devices. See Figure 1 to determine the HDMI Output Port configuration (ex. HDMI Output Port A on the Splitter corresponds with the top-left HDMI Display Device). To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 10 Connect an RS-232 Cable to the RS-232 Enabled Computer and to the RS-232 Control Port on the Splitter. See Figure 2 for pinout and default details. Figure 2 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 11: Operation
Selection button to select a preset layout. Add or Remove Bezels To add a bezel, select Bezel On/Off. Enter the bezel values for the Horizontal and Vertical bezels. Select Set to apply these settings. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 12: Serial Control
Output tab then select the Audio Icon and adjust the volume to the desired level. Serial Control Connect to the Splitter using a third party Serial Client. Serial and Telnet Enter the commands found in the Commands section. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 13: Telnet Control
Type “cmd” in the search field. Press Enter. Click Start. Windows® XP Select Run. Type “cmd”. Press Enter. Click Go. macOS® X Select Applications. Select Utilities. Select Terminal. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 14: Serial And Telnet Commands
Set IP Address mode • Available values for N1: • 0 [Static IP Mode] • 1 [DHCP Mode] • get ip mode Show current IP Address assignment • mode To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 15 1 sync Show the Connection Status of the • status HDMI Source Device: Available values for N1: • 0 [No sync] • 1 [Sync active] • To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 16: Source Device
Set input HDCP Mode for the HDMI • mode N1 Source Device: Available values for N1: • 0 [Disable] • 1 [Follow in] • 2 [Follow out] • To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 17 4 [HDCP2.2 failed] • set audio out Set Audio Output Mute: • mute N1 off [unmute] • on [mute] • get audio out Show Audio Output Mute status • mute To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 18 • 1~15 [horizontal] • Available values for N2: • 1~15 [vertical] • get video wall Show Video Wall Horizontal and • layout Vertical maximum HDMI Display Device count To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 19 • 0~15 • get video wall Show Video Wall Index Number • unit index set user N1 Upload a new EDID (in HEX format) • edid data N2 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 20: Warranty
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 21 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
