Fusion MS-NRX200 Quick Manual page 4

INSTALLATION OVER A NMEA2000 NETWORK.
As previously mentioned, the FUSION MS-NRX200 can be connected to a NMEA2000 network in two
ways as described below.
(a) Using an existing NMEA2000 Network.
An existing NMEA2000 network can be used to connect the remote control to your FUSION Marine
Stereo. The Fusion cable kit MS-N2KCONN will be required for each Fusion device connected to the
NMEA2000 network.
MS-N2KCONN - NMEA2000 Connection Pack
1 x NMEA2000 T-Connector
1 x Drop Cable, FUSION to NMEA2000 Micro-C
POWER ON/OFF – NMEA2000 REPEATER MODE
If the remote control has been configured to display NMEA2000 data sentences it can be turned on
independently of the FUSION Marine Stereo. This permits the user to monitor NMEA data without turn-
ing on the stereo.
Press to turn on the remote control. The remote control will enter NMEA2000 repeater mode and
will NOT turn on the stereo. The stereo can be turned on from the remote control by pressing the Menu
key to exit the NMEA2000 repeater mode. To return to the repeater mode press and hold the Source
key.
When in NMEA2000 repeater mode the remote will monitor the state of the stereo. If the stereo is
turned on then the remote will allow the user to change volume and mute the stereo, play, pause and
skip track (back and forwards) without leaving NMEA2000 repeater mode.
TURNING ON THE REMOTE CONTROL WITH THE MARINE STEREO TURNED ON
Press to turn ON the remote control. It will detect the stereo is on and enter the remote control
mode.
CHANGING REMOTE CONTROL MODE
