Insert cable wiring
GROUND
RETURN
SEND
General Wiring Information
Y-Adapter
2 Outputs to 1 Input
No !
TO
INPUT
Allen & Heath
WIRING NOTES
INSERT
S
T
R
UNBALANCED
BALANCED
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
2= hot (+ ) 1= ground
BALANCED
XLR MALE
3= cold (-)
BALANCED
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
2= hot (+ ) 1= ground
BALANCED
XLR MALE
3= cold (-)
RETURN
S
SEND
S
LINK RING TO SLEEVE TO UNBALANCE
RCA phono jacks
RCA PHONO CABLE
UNBALANCED
INSTRUMENT CABLE
TRS JACK CABLE
MIC CABLE
BALANCED
XLR FEMALE
TRS to XLR-F CABLE
BALANCED
XLR FEMALE
TRS to XLR-M CABLE
35
PROCESSOR
T
R
T
R
adapter
UNBALANCED
BALANCED
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
1= ground 2= hot (+ )
3= cold (-)
1= ground 2= hot (+ )
3= cold (-)
BALANCED
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
XB-14 MK2 User Guide
OUT
IN
Y-Adapter
1 Output to 2 Inputs
Yes
FROM
OUTPUT
