- Page 1 Dell UZ2215H/UZ2315H/UZ2715H User’s Guide Model: UZ2215H/UZ2315H/UZ2715H Regulatory model: UZ2215Hf/UZ2315Hf/UZ2715Hb...
- Page 2 Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries, Intel is a registered trademark of Intel Corporation in the U.S.
-
Page 3: Table Of Contents
Using the On-Screen Display (OSD) Menu..41 Setting the Maximum Resolution....55 Using Tilt (For UZ2215H and UZ2715H) .. - Page 4 ......Contacting Dell ......
-
Page 5: About Your Monitor
NOTE: To set up with any other stand, please refer to the respective stand setup guide for setup instructions. • Monitor UZ2215H and UZ2715H UZ2315H • Stand • Power Cable (Varies by... - Page 6 • Power Adapter • HDMI Cable • DP Cable (DP to Mini-DP) • USB 3.0 Upstream Cable (Enables the USB Ports on the Monitor) • Drivers and Documentation Media • Quick Setup Guide • Product and Safety Information Guide About Your Monitor...
-
Page 7: Product Features
Product Features The Dell UZ2215H/UZ2315H/UZ2715H flat panel display has an active matrix, Thin-Film Transistor (TFT), Liquid Crystal Display (LCD), and LED backlight. The monitor features include: • UZ2215H: 54.61 cm (21.5-inch) viewable area display (measured diagonally). 1920 x 1080 resolution, plus full-screen support for lower resolutions. -
Page 8: Identifying Parts And Controls
Identifying Parts and Controls Front View Front Panel Controls Label Description Microphone Webcam (Full HD) Function buttons (For more information, see Operating the Monitor) Power On/Off button (with LED indicator) About Your Monitor... -
Page 9: Back View
Back View UZ2715H UZ2215H / UZ2715H Back View with Monitor Stand UZ2215H / UZ2315H UZ2315H Back View with Monitor Stand Label Description VESA mounting holes (100 mm x Wall mount monitor using VESA- 100 mm - behind attached VESA compatible wall mount kit (100 mm x Cover) 100 mm). -
Page 10: Side View
Side View UZ2215H / UZ2715H UZ2315H Label Description Headphone-out / Microphone-in combo jack Connect the headset. About Your Monitor... -
Page 11: Bottom View
Bottom View Bottom View without Monitor Stand Label Description Adapter connector Connect the power cable. DP in connector Connect your computer with DP cable. HDMI (MHL) port Connect your MHL devices with MHL cable. connector VGA connector Connect your computer VGA cable (optional purchase). -
Page 12: Monitor Specifications
16.7 million colors Color gamut CIE1976 (83%)* CIE1976 (88%)** * [UZ2215H] [UZ2315H] color gamut (typical) is based on CIE1976 (83%) and CIE1931 (72%) test standards. ** [UZ2715H] color gamut (typical) is based on CIE1976 (88%) and CIE1931 (72%) test standards. -
Page 13: Resolution Specifications
Resolution Specifications Model UZ2215H/UZ2315H/UZ2715H Horizontal scan range 30 kHz to 83 kHz (automatic) Vertical scan range 56 Hz to 76 Hz (automatic) Maximum preset resolution 1920 x 1080 at 60 Hz Supported Video Modes Model UZ2215H/UZ2315H/UZ2715H Video display capabilities 480p, 480i, 576p, 720p, 1080p, 576i, 1080i (HDMI &... -
Page 14: Mhl Source Display Modes
UZ2715H Display Mode Horizontal Vertical Pixel Clock Sync Polarity Frequency (kHz) Frequency (MHz) (Horizontal/ (Hz) Vertical) VESA, 720 x 400 31.5 70.1 28.3 VESA, 640 x 480 31.5 59.9 25.2 VESA, 640 x 480 37.5 75.0 31.5 VESA, 800 x 600 39.9 60.3 40.0... -
Page 15: Electrical Specifications
Output: 19.5 V/4.62 A voltage/ current Inrush current 115 V/230 V: 150 A (Max.) *Qualified Compatible AC/DC adapters. CAUTION: To avoid damage to the monitor, use only the adapter designed for this particular Dell monitor. Brand Manufacturer Model Polarity Dell Lite-On... - Page 16 Omni-directional digital microphone x 2 Specification Interface USB 2.0 High Speed Power Supply 3.3 volts +/- 5% Speaker Specifications Model UZ2215H UZ2315H UZ2715H Speaker 2 x 3.0 W 2 x 5.0 W Frequency Response 250 Hz - 20 kHz Operating Temperature -25 °C ~ 70 °C...
-
Page 17: Physical Characteristics
Physical Characteristics Model UZ2215H Connector type 15-pin D-subminiature (Blue connector); DP (Black connector); HDMI (MHL); USB 3.0 (Black Tongue); Headphone-Out / Mic-in (Combo) Signal cable type • Digital: detachable, HDMI, 19 pins • Digital: detachable, MHL, 19 pins • Digital: detachable, DP to Mini-DP, 20 pins •... - Page 18 Model UZ2315H Connector type 15-pin D-subminiature (Blue connector); DP (Black connector); HDMI (MHL); USB 3.0 (Black Tongue); Headphone-Out / Mic-in (Combo) Signal cable type • Digital: detachable, HDMI, 19 pins • Digital: detachable, MHL, 19 pins • Digital: detachable, DP to Mini-DP, 20 pins •...
- Page 19 Model UZ2715H Connector type 15-pin D-subminiature (Blue connector); DP (Black connector); HDMI (MHL); USB 3.0 (Black Tongue); Headphone-Out / Mic-in (Combo) Signal cable type • Digital: detachable, HDMI, 19 pins • Digital: detachable, MHL, 19 pins • Digital: detachable, DP to Mini-DP, 20 pins •...
-
Page 20: Environmental Characteristics
Environmental Characteristics Model UZ2215H UZ2315H UZ2715H Temperature Operating 0 °C to 40 °C (32 °F to 104 °F) Non-operating • Storage: -20 °C to 60 °C (-4 °F to 140 °F) • Shipping: -20 °C to 60 °C (-4 °F to 140 °F) -
Page 21: Power Management Modes
Power Save Mode*. If the computer detects input from the keyboard, mouse, or other input devices, the monitor automatically resumes functioning. The following table shows the power consumption and signaling of this automatic power saving feature. UZ2215H VESA Modes Horizontal Vertical Video... - Page 22 The OSD functions only in the normal operation mode. When any button is pressed in the Active-off mode, one of the following messages will be displayed: Activate the computer and the monitor to gain access to the OSD. ® NOTE: This monitor is ENERGY STAR -compliant.
-
Page 23: Pin Assignments
Pin Assignments VGA Connector 15-pin Side of the Number Connected Signal Cable Video-Red Video-Green Video-Blue Self-test GND-R GND-G GND-B Computer 5 V/3.3 V GND-sync DDC data H-sync V-sync DDC clock About Your Monitor... - Page 24 DisplayPort Connector 20-pin Side of the Number Connected Signal Cable ML0(p) ML0(n) ML1(p) ML1(n) ML2(p) ML2(n) ML3(p) ML3(n) AUX(p) AUX(n) Re-PWR +3.3 V DP_PWR About Your Monitor...
- Page 25 HDMI Connector 19-pin Side of the Number Connected Signal Cable TMDS DATA 2+ TMDS DATA 2 SHIELD TMDS DATA 2- TMDS DATA 1+ TMDS DATA 1 SHIELD TMDS DATA 1- TMDS DATA 0+ TMDS DATA 0 SHIELD TMDS DATA 0- TMDS CLOCK+ TMDS CLOCK SHIELD TMDS CLOCK-...
-
Page 26: Plug And Play Capability
MHL Connector 19-pin Side of the Number Connected Signal Cable TMDS DATA 2+ TMDS DATA 2 SHIELD TMDS DATA 2- TMDS DATA 1+ TMDS DATA 1- MHL+ TMDS DATA 0 SHIELD MHL- TMDS CLOCK+ TMDS CLOCK- Reserved (N.C. on device) DDC CLOCK (SCL) DDC DATA (SDA) VBUS (+5V, 900mA maximum) -
Page 27: Universal Serial Bus (Usb) Interface
Universal Serial Bus (USB) Interface This section gives you information about the USB ports that are available on the monitor. NOTE: This monitor is Super-Speed USB 3.0 compatible. Transfer Speed Data Rate Power Consumption* Super-speed 5 Gbps 4.5 W (Max, each port) High speed 480 Mbps 4.5 W (Max, each port) -
Page 28: Lcd Monitor Quality And Pixel Policy
During the LCD Monitor manufacturing process, it is not uncommon for one or more pixels to become fixed in an unchanging state which are hard to see and do not affect the display quality or usability. For more information on Dell Monitor Quality and Pixel Policy, see Dell Support site at: http://www.dell.com/support/monitors. -
Page 29: Maintenance Guidelines
Maintenance Guidelines Cleaning Your Monitor CAUTION: Read and follow the Safety Instructions before cleaning the monitor. WARNING: Before cleaning the monitor, unplug the monitor power cable from the electrical outlet. For best practices, follow the instructions in the list below while unpacking, cleaning, or handling your monitor: •... - Page 30 About Your Monitor...
-
Page 31: Setting Up The Monitor
Setting Up the Monitor Attaching the Stand NOTE: The stand is detached when the monitor is shipped from the factory. NOTE: This is applicable for a monitor with a stand. When any other stand is bought, please refer to the respective stand setup guide for the set up instructions. To attach the monitor stand: Remove the cover and place the monitor on it. - Page 32 Connecting the blue VGA cable Connecting the HDMI cable Connecting the MHL cable Setting Up the Monitor...
-
Page 33: Connecting The Usb 3.0 Cable
Connecting the black DisplayPort (DP to mini-DP) cable Connecting the USB 3.0 cable After you have completed connecting the VGA/DP/HDMI cable, follow the procedures below to connect the USB 3.0 cable to the computer and complete your monitor setup: Connect the upstream USB 3.0 port (cable supplied) to an appropriate USB 3.0 port on your computer. - Page 34 Using the Mobile-High Definition Link (MHL) NOTE: This monitor is MHL certified. NOTE: To use the MHL function, use only MHL certified cable and source devices that support MHL output. NOTE: Some MHL source devices may take more than a few seconds or longer to output an image, depending on MHL source devices.
-
Page 35: Organizing Your Cables
Organizing Your Cables After attaching all necessary cables to your monitor and computer, (See Connecting Your Monitor for cable attachment,) organize all cables as shown above. Removing the Monitor Stand NOTE: To prevent scratches on the LCD screen while removing the stand, make sure that the monitor is placed on a soft, clean surface. -
Page 36: Wall Mounting (Optional)
Mount the monitor on the wall by following the instructions that comes with the wall mounting kit. NOTE: For use only with UL-listed wall mount bracket with minimum weight/load bearing capacity of 3.1 kg (UZ2215H) / 3.7 kg (UZ2315H) / 4.7 kg (UZ2715H). Setting Up the Monitor... -
Page 37: Operating The Monitor
Operating the Monitor Power On the Monitor Press the button to turn On the monitor. Using the Front Panel Controls ® ® Use the control buttons on the front of the monitor to link up Microsoft Lync Software or adjust the characteristics of the image being displayed. As you use these buttons, an On-Screen Display (OSD) or LED indicator shows the numeric values or activities of the characteristics as they change. - Page 38 The following table describes the front panel buttons and OSD buttons: Front Panel Button / Description OSD Button Use the Hook button to accept an incoming invite notification. Hook Use the Mute button to mute audio. MUTE • Use Volume Down button to decrease OSD bar volume.
- Page 39 ® ® Accessing Microsoft Lync with the Panel Buttons ® ® To enable Microsoft Lync functions with your monitor, make sure that the USB upstream cable is connected between your computer and the monitor. If not, the following message will be displayed: NOTE: The front panel buttons, excluding Volume Up and Volume Down, function ®...
- Page 40 Mute To mute the audio, press the Mute button. The mute-button light turns on when audio is muted. Volume Down/Volume Up To adjust the volume, press the Volume Down or Volume Up buttons. The activated OSD shows the numeric values of the volume level. Microphone Mute To mute the microphone, press the Microphone Mute button.
-
Page 41: Using The On-Screen Display (Osd) Menu
Using the On-Screen Display (OSD) Menu Accessing the Menu System NOTE: If you change the settings and then either proceed to another menu or exit the OSD menu, the monitor automatically saves those changes. The changes are also saved if you change the settings and then wait for the OSD menu to disappear. Press the button to launch the OSD menu and display the main menu. - Page 42 Main Menu for digital (DP) input to move between the setting options. As you move from one icon to another, the option name is highlighted. See the following table for a complete list of all the options available for the monitor. to activate the highlighted option.
- Page 43 Icon Menu and Description Submenus Brightness/ Use this menu to activate Brightness/Contrast adjustment. Contrast Brightness Brightness adjusts the luminance of the backlight. to increase the brightness and use to decrease the brightness (min. 0 / max. 100). NOTE: Manual adjustment of Brightness is disabled when Dynamic Contrast is switched On.
- Page 44 Input Source Use the Input Source menu to select between the different video signals that may be connected to your monitor. Select the VGA input when you are using the analog (VGA) connector. to select the VGA input source. DisplayPort Select the DisplayPort input when you are using the DisplayPort (DP) connector.
- Page 45 Input Color Allows you to set the video input mode to: Format RGB: Select this option if your monitor is connected to a computer (or DVD player) using the HDMI cable (or DisplayPort cable); or MHL devices using the MHL cable. YPbPr: Select this option if your monitor is connected to a DVD player by YPbPr using HDMI cable (or DisplayPort cable);...
- Page 46 Preset Modes When you select Preset Modes, you can choose Standard, Multimedia, Movie, Game, Paper, Color Temp., or Custom Color from the list. • Standard: Loads the monitor's default color settings. This is the default preset mode. • Multimedia: Loads color settings ideal for multimedia applications.
- Page 47 Saturation This feature can adjust the color saturation of the video image. Use to adjust the saturation from '0' to '100'. to increase the monochrome appearance of the video image. to increase the colorful appearance of the video image. NOTE: Saturation adjustment is available only when you select Movie or Game preset mode.
- Page 48 Dynamic Allows you to increase the level of contrast to provide sharper and more detailed image quality. Contrast to select the Dynamic Contrast "On" or "Off". NOTE: Dynamic Contrast provides higher contrast if you select Game or Movie preset mode. Response Time Allows you to set the Response Time to Normal or Overdrive.
- Page 49 Menu Settings Select this option to adjust the settings of the OSD, such as, the languages of the OSD, the amount of time the menu remains on screen, and so on. Language Language options set the OSD display to one of the eight languages (English, Spanish, French, German, Brazilian Portuguese, Russian, Simplified Chinese, or Japanese).
- Page 50 Other Settings DDC/CI DDC/CI (Display Data Channel/Command Interface) allows your monitor parameters (brightness, color balance, and etc.) to be adjustable via the software on your computer. You can disable this feature by selecting Disable. Enable this feature for best user experience and optimum performance of your monitor.
- Page 51 Helps reduce minor cases of image retention. Depending on the degree of image retention, the program may take some time to run. Conditioning You can enable this feature by selecting Enable. Reset all settings under the Other Settings menu to the factory Reset Other preset values.
- Page 52 OSD Warning Messages When the Dynamic Contrast feature is enabled (in these preset modes: Game or Movie), manual brightness adjustment is disabled. When the monitor does not support a particular resolution mode, you will see the following message: This means that the monitor cannot synchronize with the signal that it is receiving from the computer.
- Page 53 When the monitor enters the Power Save mode, the following message appears: Activate the computer and wake up the monitor to gain access to the OSD. If you press any button other than the power button, one of the following messages will appear depending on the selected input: VGA/DP/HDMI (MHL) input Operating the Monitor...
- Page 54 If either VGA, HDMI (MHL), or DP input is selected and the corresponding cable is not connected, a floating dialog box as shown below appears. Troubleshooting for more information. Operating the Monitor...
-
Page 55: Setting The Maximum Resolution
Depending on your computer, complete one of the following procedures: If you have a Dell desktop or portable computer: • Go to http://www.dell.com/support, enter your service tag, and download the latest driver for your graphics card. If you are using a non-Dell computer (portable or desktop): •... -
Page 56: Using Tilt, Swivel, And Vertical Extension
Using Tilt, Swivel, and Vertical Extension (For UZ2315H) NOTE: This is applicable for a monitor with a stand. When any other stand is bought, please refer to the respective stand setup guide for set up instructions. Tilt, Swivel With the stand attached to the monitor, you can tilt and swivel the monitor for the most comfortable viewing angle. -
Page 57: Rotating The Monitor
Rotating the Monitor Before you rotate the monitor, your monitor should be fully vertically extended (Vertical Extension) and fully tilted up to avoid hitting the bottom edge of the monitor. Rotate clockwise Operating the Monitor... -
Page 58: Uz2315H)
After you have rotated your monitor, you need to complete the procedure below to adjust the Rotation Display Settings of your system. NOTE: If you are using the monitor with a non-Dell computer, you need to go the graphics driver website or your computer manufacturer website for information on rotating the 'contents' on your display. -
Page 59: Troubleshooting
Troubleshooting WARNING: Before you begin any of the procedures in this section, follow the Safety Instructions. Self-Test Your monitor provides a self-test feature that allows you to check whether your monitor is functioning properly. If your monitor and computer are properly connected but the monitor screen remains dark, run the monitor self-test by performing the following steps: Turn off both your computer and the monitor. -
Page 60: Built-In Diagnostics
This box also appears during normal system operation, if the video cable becomes disconnected or damaged. Turn Off your monitor and reconnect the video cable; then turn On both your computer and the monitor. If your monitor screen remains blank after you use the previous procedure, check your video controller and computer, because your monitor is functioning properly. -
Page 61: Common Problems
To run the built-in diagnostics: Ensure that the screen is clean (no dust particles on the surface of the screen). Unplug the video cable(s) from the back of the computer or monitor. The monitor then goes into the self-test mode. Press and hold Button 3 and Button 6 on the front panel simultaneously for 2 seconds. - Page 62 • Cycle power On-Off. spots • Pixel that is permanently Off is a natural defect that can occur in LCD technology. • For more information on Dell Monitor Quality and Pixel Policy, see Dell Support site at: http://www.dell.com/ support/monitors. Stuck-on Pixels LCD screen has •...
-
Page 63: Product Specific Problems
Intermittent Monitor • Ensure that the video cable connecting the monitor to the Problems malfunctions on computer is connected properly and is secure. & off • Reset the monitor to Factory Settings. • Perform monitor self-test feature check to determine if the intermittent problem occurs in self-test mode. -
Page 64: Universal Serial Bus (Usb) Specific Problems
The picture The picture • Due to different video formats (aspect ratio) of DVDs, the does not fill the cannot fill the monitor may display in full screen. entire screen height or width • Run the built-in diagnostics. of the screen Universal Serial Bus (USB) Specific Problems Specific What You... -
Page 65: Mobile High-Definition Link (Mhl) Specific Problems
Cannot hear any • Ensure that you have set the default playback device as coming from sound during "DELL UZ2x15H" on your system. the speakers calls • Turn Off the monitor, unplug the monitor power cord, replug it, and then turn On the monitor. - Page 66 Troubleshooting...
-
Page 67: Appendix
For customers in the United States, call 800-WWW-DELL (800-999-3355). NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing slip, bill, or Dell product catalog. Dell provides several online and telephone-based support and service options. -
Page 68: Setting Up Your Monitor
After installing the drivers for your graphics adapter, attempt to set the resolution to 1920 x 1080 again. NOTE: If you are unable to set the resolution to 1920 x 1080, please contact Dell™ to inquire about a graphics adapter that supports these resolutions. - Page 69 After installing the drivers for your graphics adapter, attempt to set the resolution to 1920 x 1080 again. NOTE: If you are unable to set the recommended resolution, please contact the manufacturer of your computer or consider purchasing a graphics adapter that will support the video resolution.
