GE Security CyberDome II Specifications page 2

Integrated ptz dome camera
Hide thumbs Also See for CyberDome II:

Advertisement

CyberDome II Options
Available Housings
Flush mount ceiling
Plenum-rated flush mount
Pendant mount
Pendant mount with heater
Wall mount
Heavy duty
Heavy duty with heater
Rugged pendant
Rugged pendant with heater
Pressurized pendant mount
with heater
Available Cameras (NTSC or PAL)
22x color camera
18x day/night camera
23x day/night camera with WDR
26x day/night camera
36x day/night camera with WDR
Bubble Specifications
Choose from four different acrylic
bubbles or two polycarbonate bubbles,
based on how you wish to balance
discreet camera position and available
light. Polycarbonate bubbles work
with heavy-duty and rugged pendant
housings only.
Bubble
Clear acrylic
Smoke acrylic
Chrome mirrored acrylic
Gold mirrored acrylic
Clear polycarbonate
Smoke polycarbonate
General Specifications
Manual pan speed: 0.5 to 200°/sec
Manual tilt speed: 0.5 to 120°/sec
Max. pan/tilt speed: 340°/sec
Presets: 128 with 24-character title
Preset tours: 4 tours with
64 presets each
Shadow tours: 4 with 5 min. each
Protocols: Digiplex RS422, Impac
RS485, ASCII RS422, Pelco D,
Pelco P, Pelco Coaxitron, Ultrak,
AD 4800, AD Manchester, BBV,
Bosch Biphase, Bosch RS232, KD6,
Panasonic, VCL, Vicon
Operating temperature, without
heater: 32 to 122°F (0 to 50°C)
Operating temperature, with heater:
-40 to 122°F (-40 to 50°C)
Regulatory: FCC, CE, C-Tick, UL, RoHS
Flush mount ceiling and plenum-rated flush mount
The indoor flush-mount housing is designed for in-ceiling
applications. A T-bar support kit is included. A flush-mount
housing for plenum-rated applications is also available.
Electrical
• Operating voltage: 24 VAC +/- 4 VAC
• Power: 25 W startup; 20 W running
Mechanical
• Environmental enclosure: Rated IP50
• Dimensions: 9.5 in. dia. x 9.6 in. high (241 x 243 mm)
• Weight (housing, PTZ): 6 lb., 8.5 oz. (2.96 kg)
• Construction: Gray ABS plastic
Pendant mount and pendant mount with heater
The weatherproof pendant-mount housing can be used for indoor
or outdoor applications. Both the pendant mount and pendant
mount with heater and fan are rated IP66. With the heater/fan
option, the housing can be used in temperatures to -40°F (-40°C).
Electrical
• Operating voltage: 24 VAC +/- 4 VAC
• Power: 25 W startup; 20 W running
• Power, with heater: 93 W startup; 45 W running
Mechanical
• Environmental enclosure: Rated IP66
• Dimensions: 9.5 in. dia. x 11.9 in. high (241 x 303 mm)
• Weight (housing, heater, PTZ): 6 lb., 8.5 oz. (2.96 kg)
• Construction: Gray ABS plastic
Wall mount and wall mount with heater
The weatherproof wall-mount housing can be used for indoor
or outdoor applications. The wall arm is constructed of cast
aluminum. Both the wall mount and wall mount with heater and
fan are rated IP66. With the heater option, the housing can be used
in temperatures to -40°F (-40°C).
Electrical
• Operating voltage: 24 VAC +/- 4 VAC
• Power: 25 W startup; 20 W running
• Power, with heater: 93 W startup; 45 W running
Light loss
Mechanical
none
• Environmental enclosure: Rated IP66
1/2 f-stop
• Dimensions: 9.5 in. dia. x 9.6 in. high (241 x 243 mm)
• Weight (housing, heater, PTZ): 8 lb., 8.5 oz. (3.87 kg)
2 f-stop
• Construction: Gray ABS plastic
2 f-stop
Heavy duty and heavy duty with heater
none
The weatherproof heavy-duty housing is designed to hold up under
1/2 f-stop
tough outdoor use. Both the heavy duty and heavy duty with heater
and fan come with adjustable wall mount brackets. With the heater
option, the housing can be used in temperatures to -13°F (-25°C).
Electrical
• Operating voltage: 24 VAC +/- 4 VAC
• Power: 25 W startup; 20 W running
• Power, with heater: 153 W startup; 66 W running
Mechanical
• Dimensions: 10.56 in. wide x 9.64 in. high (268 x 236 mm)
• Weight (housing, heater, PTZ): 13 lb., 8 oz. (6.12 kg)
• Construction: Cast aluminum
Rugged pendant and rugged pendant with heater
The weatherproof rugged pendant housing is for outdoor applications
that require tamper resistance. Both the rugged pendant and
rugged pendant with heater and fan are rated IP66. With the heater
option, the housing can be used in temperatures to -40°F (-40°C).
Electrical
• Operating voltage: 24 VAC +/- 4 VAC
• Power: 25 W startup; 20 W running
• Power, with heater: 153 W startup; 66 W running
Mechanical
• Environmental enclosure: Rated IP66
• Dimensions: 9.5 in. dia. x 11.1 in. high (241 x 283 mm)
• Weight (housing, heater, and PTZ): 12 lb., 8.5 oz. (5.68 kg)
• Construction: Cast aluminum
10.44 in. (265 mm)
7 in. (177.8 mm)
10 in. (254 mm)
10.56 in. (268 mm)
