Leader LV 5380 Specifications

V I D E O
MULTI SDI MONITOR
LV 5380
MULTI SDI MONITOR
GENERAL
The LV 5380 is a multi-SDI monitor equipped with a
precision video signal waveform and vectorscope dis-
play via a high-fidelity TFT LCD that produces high-
quality picture displays. It also offers an embedded
audio signal display featuring Lissajous and level-me-
ter configurations. Additional features include simul-
taneous display of two SDI signals, screen capture to
USB memory, and on-picture gamut error monitoring.
All these features are integrated into a thin, light instru-
ment that allows it to be used in any video production
or monitoring application.
FEATURES
■ High-Quality TFT LCD
Employs an XGA TFT LCD (1,024x768) that produces
high-quality picture displays.
■ Extensive Video Signal Displays
The waveform monitor display has gain adjustment,
sweep, and cursor measurement features along with
RGB and pseudo-composite information. The LV 5380
also provides vectorscope and embedded audio, Lis-
sajous and Levelmeter displays.
■ Multi-Functional Picture Display
The picture display has various adjustment features
such as color temperature selection, brightness,
contrast, gain, and bias. Other features include mono-
chrome, chroma up, onimage gamut error, and safety
marker displays.
■ Multi-Screen Display and 2-Channel Simultaneous Display
1) You can switch to multi-screen which simultaneously
shows video signal waveforms and pictures.
2) You can switch to multi-screen which simultaneously
shows video signal waveforms, picture, vectorscope,
and audio levels.
3) You can display two SDI signals simultaneously.
■ Dual link input*1
■ Status Display
The LV 5380 can display SDI signal's data dump and
error logs as well as the phase difference between the
external sync signal and SDI signal.
Compact Multi-SDI Monitor
The design is subject to change.
■ Display Mode Switch Keys
For quick operation, the LV 5380 provides dedicated
keys for switching between different display modes
such as video waveform, vectorscope, and picture dis-
plays. In addition, all keys can be back-lit.
■ Stereo Headphone Output
Delivers SDI signal's embedded audio signals in stereo
through the headphone output jacks.
■ External Sync Signal Input
Accepts tri-level sync signals or NTSC/PAL black burst
signals.
■ Presets
Stores up to 30 front panel presets.
■ Last Memory
Equipped with a feature that stores panel settings to
memory.
■ 75-mm VESA Mounting
Provides 75-mm VESA mounting holes on the rear
panel that allows the LV 5380 to be mounted on an arm
or stand. Tripod mounting facilities also provided.
■ External Remote Connector (Factory Option)
An external remote connector can be installed as a fac-
tory option. In addition, one of the connectors can be
modified so that a tally indicator can be displayed on
the screen.
■ Battery Mount (Factory Option)
A battery adapter can be installed on the rear panel as
a factory option.
OP73 : BATTERY MOUNT IDX (V-Mount)
OP74 : BATTERY MOUNT ANTON (AntonBauer)
■ CINELITE II (Cinelite+Cinezone) (Option)
Leader's CINELITE and CINEZONE features are added
as a single option in this instrument.
*1 To be supported in the future
*2 If you install the battery mount, you cannot use the 75-mm VESA mounting holes.
option
*2
