Page 1 LV 5490 MULTI WAVEFORM MONITOR LV 5490SER01 SDI INPUT LV 5490SER02 SDI INPUT / EYE LV 5490SER03 DIGITAL AUDIO LV 5490SER04 FOCUS ASSIST LV 5490SER05 CIE DIAGRAM INSTRUCTION MANUAL...
Page 2 TABLE OF CONTENTS...
Page 6 Note about Reading This Manual The contents of this manual contain specialized terminology and may be difficult to understand. If you have any questions about the contents of this manual, please contact your local LEADER agent. Symbols and Terms The following symbols and terms are used in this instruction manual and on the instrument to indicate important warnings and notes.
Page 7 Failing to do so could lead to fire. Turn OFF the power switch, and remove the power cord from the outlet. After making sure that fire has not spread anywhere, contact your local LEADER agent.
Page 8 Using a power cord that does not meet the standards could lead to fire. If the power cord is damaged, stop using it, and contact your local LEADER agent. Using a damaged power cord could lead to electrical shock or fire.
Page 9 To ensure stable performance, we recommend that you have the instrument calibrated regularly. Also, if the instrument malfunctions, repairs are necessary. For repairs and calibration, contact your local LEADER agent. Routine Maintenance When you clean the instrument, remove the power plug from the outlet.
Page 10 1. INTRODUCTION INTRODUCTION Thank you for purchasing this LEADER instrument. To use this instrument safely, read this instruction manual thoroughly, and make sure that you know how to use the instrument properly. If some point about the operation of this instrument is still unclear after you have read this instruction manual, refer to the contact information on the back cover of the manual to contact LEADER, or contact your local LEADER agent.
Page 11 To continually use the last-memory feature, we recommend that you replace the backup battery with a new one every five years after you purchase the instrument. You cannot replace the backup battery yourself. For details, contact your nearest LEADER agent. 1.2.7 About the LCD Panel There may be a small number of pixels in the LCD panel that do not light or are always on.
Page 12 1. INTRODUCTION About Terminology Used in this Manual SER01/SER02/SER03/SER04/SER05 LV 5490SER01 is referred to as SER01; LV 5490SER02 is referred to as SER02; LV 5490SER03 is referred to as SER03, LV 5490SER04 is referred to as SER04, LV 5490SER05 is referred to as SER05. Single Input Mode This refers to the mode in which on the INPUT menu, DISPLAY is set to SINGLE.
Page 13 For 4K video formats, 3G-SDI dual link and quad link and HD-SDI quad link are supported. The display is a 9-inch full high definition LCD enabling the LV 5490 to also be used as a high-quality picture monitor. In addition, the LV 5490 is equipped with SDI and DVI-D output connectors.
Page 14 A USB mouse can be used to operate the panel. If the measurement screen is displayed on an external monitor in SDI or DVI-D, you can control the LV 5490 by using a USB mouse while viewing the external monitor.
Page 15 2. SPECIFICATIONS Time Code Display The LV 5490 can display the LTC or VITC that is embedded in an SDI signal and the D-VITC of an SD signal. The timecode can also be used for time stamps in the event log.
Page 16 2. SPECIFICATIONS Specifications 2.3.1 SDI Formats and Standards Table 2-1 SD video signal formats and standards Color System Quantization Image Field Frequency/Scanning Compliant Standard 4:2:2 10 bits 720×487 59.94/I SMPTE ST 259 720×576 50/I Table 2-2 HD video signal formats and standards Color System Quantization Image...
Page 17 2. SPECIFICATIONS Color System Quantization Image Frame (Field) Frequency/Scanning Compliant Standard RGB 4:4:4 10 bits 1280×720 60/59.94/50/30/29.97/25/24/23.98/P SMPTE ST 296 SMPTE ST 425-1 1920×1080 60/59.94/50/I SMPTE ST 274 SMPTE ST 425-1 30/29.97/25/24/23.98/P 30/29.97/25/24/23.98/PsF 2048×1080 30/29.97/25/24/23.98/P SMPTE ST 425-1 30/29.97/25/24/23.98/PsF SMPTE ST 2048-2 12 bits 1920×1080 60/59.94/50/I...
Page 18 2. SPECIFICATIONS Color System Quantization Image Frame (Field) Frequency/Scanning Compliant Standard RGB 4:4:4 10 bits 1920×1080 60/59.94/50/I SMPTE ST 274 SMPTE ST 372 30/29.97/25/24/23.98/P SMPTE ST 425-1 30/29.97/25/24/23.98/PsF 2048×1080 30/29.97/25/24/23.98/P SMPTE ST 372 SMPTE ST 425-1 30/29.97/25/24/23.98/PsF SMPTE ST 2048-2 12 bits 1920×1080 60/59.94/50/I...
Page 19 2. SPECIFICATIONS Table 2-7 HD (QL) video signal formats and standards Division Transmission Color System Quantization Image Frame Frequency/Scanning Compliant Standard System Square 4:2:2 10 bits 3840×2160 30/29.97/25/24/23.98/P 30/29.97/25/24/23.98/PsF 4096×2160 30/29.97/25/24/23.98/P 30/29.97/25/24/23.98/PsF When these signals are displayed, phase differences of up to 100 clocks (approx. 0.67 s) between links are automatically corrected.
Page 20 2. SPECIFICATIONS Division Transmission Color System Quantization Image Frame Frequency/Scanning Compliant Standard System 4096×2160 30/29.97/25/24/23.98/P SMPTE ST 425-5 SMPTE ST 2048-1 30/29.97/25/24/23.98/PsF 2 sample 4:2:2 10 bits 3840×2160 60/59.94/50/P SMPTE ST 425-5 interleave SMPTE ST 2036-1 4096×2160 60/59.94/50/48/47.95/P SMPTE ST 425-5 SMPTE ST 2048-1 12 bits 3840×2160...
Page 21 2. SPECIFICATIONS 2.3.3 SDI I/O Connectors SDI Input Connectors Connector Type Number of Input Connectors 4 (1A, 1B, 1C, 1D) Input Impedance Input Return Loss 5 MHz to 1.485 GHz 15 dB or more 1.485 to 2.97 GHz 10 dB or more Maximum Input Voltage SER01 ±2 V (DC + peak AC)
Page 22 2. SPECIFICATIONS 2.3.4 External Reference Input Connector Type Number of Input Connectors 1 pair Input Impedance -through Input Return Loss Maximum Input Voltage ±5 V (DC + peak AC) Input Signal Tri-level sync or NTSC/PAL black burst signal The waveform display position and the measured phase of the phase difference display based on the external sync signal may vary by ±1 clock depending on the timing when the external sync signal or SDI signal is connected or disconnected or when the device is restarted.
Page 23 2. SPECIFICATIONS 2.3.6 Monitor Output Connector SDI Output Connector Connector Type Number of Output Connectors 1 Output Impedance Output Return Loss 5 MHz to 1.485 GHz 15 dB or more 1.485 to 2.97 GHz 10 dB or more Output Voltage 800 mVp- Output Signal Outputs the LCD screen in HD, 3G-A, or 3G-B-DL.
Page 24 2. SPECIFICATIONS 2.3.7 Control Connectors USB Port Port Type Standard A Number of Ports 2 (one on front, one on rear) Specifications USB 2.0 Compatible Devices USB memory, USB mouse USB Memory Feature Saves captured data, preset data, and data dumps USB Mouse Feature Used to control on the screen Ethernet Port...
Page 25 Screen captures can be saved as bitmap files to USB memory, or they can be saved in a file format that the LV 5490 can load. Data Input Data saved to USB memory can be loaded and displayed on the LV 5490. 2.3.10 Frame Capture Function Captures frame data...
Page 26 2. SPECIFICATIONS 2.3.11 Pattern Generator Table 2-9 HD video signal formats and standards Color System Quantization Image Frame (Field) Frequency/Scanning Compliant Standard 4:2:2 10 bit 1920×1080 60/59.94/50/I SMPTE ST 274 SMPTE ST 292-1 30/29.97/25/24/23.98/P 30/29.97/25/24/23.98/PsF Table 2-10 3G-A, 3G-B-DL video signal formats and standards Color System Quantization Image...
Page 27 Preset Loading Method Front panel or remote control connector (*1) Copying All preset data can be copied from the LV 5490 to a USB memory device or from a USB memory device to the LV 5490. The number of presets loaded from the remote control connector can be 8 or 60.
Page 28 2. SPECIFICATIONS Alarm Indications Displayed on the screen when various errors occur, when the fan malfunctions, or when the internal temperature is abnormal 2.3.14 SDI Video Signal Waveform Display Waveform Operations Display Mode Overlay Overlays component signals Parade Displays component signals side by side Blanking Interval H and V blanking periods can be masked.
Page 29 2. SPECIFICATIONS Time Accuracy ±0.5 % Cursor Measurement Composition Horizontal Cursors 2 (REF and DELTA) Vertical Cursors 2 (REF and DELTA) Amplitude Measurement mV, %, R%, DEC, HEX Time Measurement Second display Frequency Display Computes and displays the frequency with the length of one period set to the time between two cursors Scale Type...
Page 30 2. SPECIFICATIONS 2.3.16 CIE Diagram Display (SER05) Display Standard CIE1931 (xy display), CIE1976 (u'v' display) Display Type Chromaticity diagram display, color temperature display Display Mode Chromaticity Diagram Display Luminance display, color display Color Temperature Display Luminance display Colorimetry BT.601(525), BT.601(625), BT.709, DCI, BT.2020 Clipping Clips negative values of the input signal to zero Displays negative values of the input signal according to...
Page 31 2. SPECIFICATIONS 2.3.18 Focus Assist Display (SER04) Detection Sensitivity LOW, MIDDLE, HIGH, V-HIGH (*1), U-HIGH (*1) Highlight Display Color WHITE, GREEN, BLUE, RED Picture Luminance Level OFF, EMBOSS, 25 %, 50 %, 75 %, 100 % If there is noise in the image, the noise will also be enhanced. 2.3.19 Digital Audio Display (SER03) Input Signal...
Page 32 1 to 5000 ms Parity Error Counts the number of times that the input signal's parity bit and the parity bit recalculated by the LV 5490 differ Validity Error Counts the number of times that the input signal's validity bit is 1...
Page 33 If the input signal is 3G-B, only stream 1 is supported. 2.3.21 SDI Analysis Features Event Log Display Function Records detected errors, events—such as the LV 5490 switching between input signals, and time stamps. Recording Capacity Up to 1000 events Operation...
Page 34 2. SPECIFICATIONS Stream 1/2 Displays each stream in a transmission structure Link A/B/1/2/3/4 Displays the selected link Line Select Displays the selected line Sample Select Displays from the selected sample Jump Feature Moves to EAV or SAV (Moves to 0 or 3839/4095 for 3G (DL), 3G (QL), or HD (QL) in PICTURE format) Data Output Text output to USB memory...
Page 35 2. SPECIFICATIONS Data Broadcast Trigger Signal (*2) Compliant Standard ARIB STD-B35 Display Format Text, hexadecimal, binary V-ANC User Data Display (*2) Compliant Standard ARIB TR-B23 Display Format Hexadecimal and binary AFD Packet Display Compliant Standard SMPTE ST 2016-3 Display Format Text, hexadecimal, binary User-Defined ANC Packet Display ANC Specification Method...
Page 36 2. SPECIFICATIONS 2.3.22 Eye Pattern Display (SER02) Display Displays the input SDI waveform before equalizing 3G, HD, SD Displays channel A, B, C, or D, whichever is selected HD (DL) Displays link A or B, whichever is selected 3G (DL) Displays link 1 or 2, whichever is selected 3G (QL), HD (QL) Displays link 1, 2, 3, or 4, whichever is selected...
Page 37 2. SPECIFICATIONS 2.3.23 Jitter Display (SER02) Display Displays the jitter component of an SDI signal 3G, HD, SD Displays channel A, B, C, or D, whichever is selected HD (DL) Displays link A or B, whichever is selected 3G (DL) Displays link 1 or 2, whichever is selected 3G (QL), HD (QL) Displays link 1, 2, 3, or 4, whichever is selected...
Page 38 2. SPECIFICATIONS 2.3.24 Eye Pattern and Jitter Detection (SER02) Error Detection On or off per item Error Threshold Settings Can be set individually for 3G, HD, and SD signals Event Log Stores eye patterns and jitter errors Threshold Values 100 % of the values in the SMPTE standard Eye-Pattern Amplitude Upper Limit 80 to 140 % (640 to 1120 mV)
Page 39 2. SPECIFICATIONS 2.3.25 General Specifications Environmental Conditions Operating Temperature 0 to 40 °C Operating Humidity Range 85 %RH or less (no condensation) Optimal Temperature 10 to 30 °C Operating Environment Indoors Elevation Up to 2,000 m Overvoltage Category Pollution Degree Power Requirements Voltage 90 to 250 VAC...
Page 40 3. PANEL DESCRIPTION PANEL DESCRIPTION Front Panel Figure 3-1 Front panel Table 3-1 Front panel description Name Description Handle Power Switch Headphone jack this jack, the LV 5490 transmits the audio signal embedded in the SDI signal or (SER03) INPUT...
Page 41 3. PANEL DESCRIPTION Name Description Switches the sync signal. When the internal sync signal is being used, this key’s MULTI you like. PSET AUDIO (SER03) VECT STATUS (SER02) V POS H POS Turn to adjust the horizontal position of the video signal waveform or other item. Press to return to the reference position.
Page 42: Rear Panel
3. PANEL DESCRIPTION Rear Panel Figure 3-2 Rear panel Table 3-2 Rear panel description Name Description RS-422/485 (custom order feature) ETHERNET Ethernet port. Supports TELNET, FTP, SNMP, HTTP, and SNTP. (This will be supported in the future.) AC inlet Ground terminal MONITOR Transmits the screen image.
Page 43 3. PANEL DESCRIPTION Name Description REMOTE 15-pin D-sub remote control connector. Can be used to execute actions such as recalling preset settings. DIGITAL AUDIO Audio signal I/O connectors. Switch between input and output using system INPUT/OUTPUT (SER03) SDI INPUT INPUT/OUTPUT system settings.
Page 44 BEFORE YOU BEGIN MEASURING Attaching the Cover Inlet Stopper A cover/inlet stopper is included with the LV 5490. Use this device to prevent the power cord from being pulled free of the AC inlet. To attach the cover/inlet stopper, follow the procedure below.
Page 45 Figure 4-1 Removing the protection panel Using the Stand You can use the stand to tilt the LV 5490. Tilting the LV 5490 may make the screen easier to view or make it easier to operate the front panel. If necessary, pull out the stand.
Page 46 To turn off the power, hold down the power switch for 2 seconds or more. The power switch LED and the instrument turn OFF. You can set the time from when the power is turned on until the LV 5490 starts on the Reference...
Page 47 USB mouse to the ports. You can connect the devices to either USB port, but you cannot connect the same type of devices to the LV 5490 simultaneously. USB devices can be connected or removed with the power turned on.
Page 48 INPUT menu or SELECT CH in the appropriate measurement screen. Test Signal 2A-2D output various patterns. You can superimpose a moving box, vary the phase, and so on. You can use the LV 5490 as a signal generator.
Page 49 4. BEFORE YOU BEGIN MEASURING Cables It has been confirmed that errors do not occur when the LV 5490 receives an 800 mVp-p stress pattern through the following cables. Input Signal Cable Type Input Connectors (1A to 1D) I/O Connectors (2A to 2D)
Page 50 4. BEFORE YOU BEGIN MEASURING External sync signals that are compatible with each input signal are indicated with a check mark in the following table. Proper measurement is possible only for combinations that are indicated with check marks. Table 4-4 External sync signal formats (SD, HD) Input Signal Format NTSC with 10 field ID (59.94Hz)(*1)
Page 51 4. BEFORE YOU BEGIN MEASURING Table 4-5 External sync signal formats (3G) NTSC with 10 field ID (59.94Hz)(*1) NTSC (59.94Hz) PAL (50Hz) 1080/60I 1080/59.94I 1080/50I 1080/30PsF 1080/29.97PsF 1080/25PsF 1080/24PsF 1080/23.98PsF 1080/30P 1080/29.97P 1080/25P 1080/24P 1080/23.98P 720/60P 720/59.94P 720/50P If the input signal is 1080/23.98PsF or 1080/23.98P, the 10 field ID is automatically detected.
Page 52 4. BEFORE YOU BEGIN MEASURING 4.8.3 Digital Audio I/O (SER03) Figure 4-6 Digital audio I/O connectors Input/Output Switching Reference Audio Signal Output If group A or B is set to output, the following signals are output. Use the signals for monitoring.
Page 53 4.8.4 Monitor Signal Output Figure 4-7 Monitor output connectors The SDI output connector and DVI-D output connector transmit the LV 5490 screen for a monitor device. Connect to an full high definition (1920×1080) display. Selecting the Sync Mode On the MONITOR OUT tab in the system settings, select internal synchronization or external synchronization.
Page 54 4. BEFORE YOU BEGIN MEASURING Operation Basics 4.9.1 Displaying the Function Menu The function menu is used to specify a variety of settings. Normally the function menu is displayed, but it can be cleared by pressing the measurement key that is currently selected. You can also set it to disappear automatically on the Reference If the measurement menu disappears, carry out one of the following operations to display it again.
Page 55 4. BEFORE YOU BEGIN MEASURING 4.9.3 Mouse Operations You can use the mouse to operate the keys on the screen to specify settings in the same manner as using the front panel keys. To display the keys, connect a mouse, and click in the screen.
Page 56 4. BEFORE YOU BEGIN MEASURING Right-Click Menu The menu below appears when you right-click the mouse. LAYOUT is an item that can only be set using the mouse. Table 4-7 Right-click menu Menu Description ALL CLEAR Hides the keys and function menu from the screen. Click in the screen to redisplay them.
Page 57 4.9.5 Setting the Key Lock You can prevent unintentional operations on the LV 5490 by enabling the key lock. The key lock disables all LV 5490 keys except for the power switch. Enabling the Key Lock Hold down SYS until the following message is displayed on the screen. While the key lock is enabled, the key lock icon appears in the upper right of the screen.
Page 58 4. BEFORE YOU BEGIN MEASURING 4.10 Measurement Screen Explanation The measurement screen layout can be arranged as you like. This section explains items that are common to all displays. Figure 4-13 Measurement screen explanation Table 4-8 Measurement screen explanation Name Description TEMPERATURE ERROR...
Page 59 4. BEFORE YOU BEGIN MEASURING Name Description OVER HEAT “OVER HEAT” appears when the internal temperature increases. “FAN ALARM” FAN ALARM appears when a fan error occurs. If either of these alarm appears, immediately turn the power off, and then check for problems with the operating environment.
Page 60: Basic Operation
5. BASIC OPERATION BASIC OPERATION Configuring Measurement Channels This section explains the procedure from applying an input to displaying the measurement screen for each of the different input signal formats. 5.1.1 Notes This section provides notes common to all input signal formats. INPUT FORMAT If the input signal or payload ID is not appropriate for the settings specified on the SDI IN tab in the system settings, the format of the signal currently received is displayed in red in...
Page 61 5. BASIC OPERATION 6 OPERATE CH MODE If you set 7 DISPLAY in the INPUT menu to SIMUL, 6 OPERATE CH MODE becomes available. If you change INDIVIDUAL to COM, all the settings are changed to those of the channel selected with 6 SELECT CH on each measurement screen.
Page 62 5. BASIC OPERATION 5.1.2 Measuring SD, HD, 3G-A, and 3G-B-DL Signals On the SDI IN tab in the system settings, set SDI System to SD/HD/3G-A/3G-B-DL. 1 SIGNAL IN OUT Figure 5-2 SDI IN tab If the input signal is HD or 3G, set the payload ID. Select Use or Not Use.
Page 63 5. BASIC OPERATION Press COMPLETE. Apply SDI signals to the SDI INPUT connectors on the rear panel. If Output is selected in step 3, do not apply signals to 2A to 2D. Figure 5-4 SDI input connectors Press INPUT to select the channels you want to measure. First, press 7 DISPLAY to select whether to measure a single channel (SINGLE) or multiple channels (SIMUL).
Page 64 Set the payload ID. Select Use or Not Use. If you select Not Use, set i/PsF Select. Even if Use is selected, if a 3G-B-DL signal is applied, the LV 5490 will detect is as a Press Select Input to apply up to eight signals (1A to 1D and 2A to 2D).
Page 65 5. BASIC OPERATION Press COMPLETE. Apply 3G-B-DS signals to the SDI INPUT connectors on the rear panel. If Output is selected in step 3, do not apply signals to 2A to 2D. Figure 5-8 SDI input connectors Press INPUT to select the channels you want to measure. First, press INPUT GROUP to select whether to measure 1A to 1D (1) or 2A to 2D (2).
Page 66 5. BASIC OPERATION 5.1.4 Measuring HD (DL) Signals On the SDI IN tab in the system settings, set SDI System to HD Dual Link. F 1 SIGNAL IN OUT Figure 5-10 SDI IN tab Set the payload ID. Select Use or Not Use. If you select Not Use, set i/PsF Select, Color System, and Pixel Depth.
Page 67 5. BASIC OPERATION Press COMPLETE. Apply SDI signals to the SDI INPUT connectors on the rear panel. If Output is selected in step 3, do not apply signals to 2A to 2D. Figure 5-12 SDI input connectors Press INPUT to select the channels you want to measure. First, press DISPLAY to select whether to measure a single channel (SINGLE) or multiple channels (SIMUL).
Page 68 Set the payload ID. Select Use or Not Use. If you select Not Use, set Division. Even if Use is selected, if a 3G-B-DL signal is applied, the LV 5490 will detect is as a Press Select Input to apply up to four signals (1A/1B, 1C/1D, 2A/2B, and 2C/2D).
Page 69 5. BASIC OPERATION Press COMPLETE. Apply 3G-B-DS signals to the SDI INPUT connectors on the rear panel. 1A/1B, 1C/1D, 2A/2B, and 2C/2D are pairs. If Output is selected in step 3, do not apply signals to 2A to 2D. Figure 5-16 SDI input connectors Press INPUT to select the channels you want to measure.
Page 70 5. BASIC OPERATION 5.1.6 Measuring HD (QL) Signals On the SDI IN tab in the system settings, set SDI System to 4K HD Quad Link. F 1 SIGNAL IN OUT Figure 5-18 SDI IN tab Press NEXT TAB, and then set SDI In/Out BNC. Select Input to apply up to two signals (1A to 1D and 2A to 2D).
Page 71 5. BASIC OPERATION Press COMPLETE. Apply HD signals to the SDI INPUT connectors on the rear panel. If Output is selected in step 2, do not apply signals to 2A to 2D. Figure 5-20 SDI input connectors Press INPUT to select the channels you want to measure. Press INPUT GROUP to select whether to measure 1A to 1D (1) or 2A to 2D (2).
Page 72 5. BASIC OPERATION 5.1.7 Measuring 3G (QL) Signals On the SDI IN tab in the system settings, set SDI System to 4K 3G Quad Link. 1 SIGNAL IN OUT Figure 5-22 SDI IN tab Set the payload ID. Select Use or Not Use. If you select Not Use, set Division, Color System, and Pixel Depth.
Page 73 5. BASIC OPERATION Press COMPLETE. Apply a 3G-A or 3G-B-DL signal to the SDI INPUT connectors on the rear panel. If Output is selected in step 3, do not apply signals to 2A to 2D. Figure 5-24 SDI input connectors Press INPUT to select the channels you want to measure.
Page 74 5. BASIC OPERATION Selecting the Measurement Mode The types of measurement screens available are WFM, VECT, PIC, AUDIO, STATUS, and EYE. There is also another type, MULTI, that combines these six types. Press a measurement key on the front panel to select the type. 5.2.1 Video Signal Waveform Display To display video signal waveforms, press WFM.
Page 75 5. BASIC OPERATION 5.2.3 Picture Display To show the picture display, press PIC. The available features include monochrome display, marker display, line select display, and focus assist display (SER04). Figure 5-28 Picture display 5.2.4 Audio Display (SER03) To show the audio display, press AUDIO. (If SER03 is not installed, the AUDIO key is disabled.) The available features include Lissajous display, surround display, meter display, and status display of the signal selected with...
Page 76 5. BASIC OPERATION 5.2.5 Status Display To show the status display, press STATUS. The available features include event log display and data dump display. Figure 5-30 Status display 5.2.6 Eye Pattern Display (SER02) To show eye patterns, press EYE. (If SER02 is not installed, the EYE key is disabled.) You can also show jitter by switching MODE.
Page 77 5. BASIC OPERATION 5.2.7 Multi Display To show a multi screen, which is a combination of measurement screens, press MULTI. You can select between five types of layouts by using 1 LAYOUT SELECT. To set each measurement screen, use 2 MULTI WFM to 7 MULTI EYE.
Page 78 5. BASIC OPERATION USER 3 The vector is displayed in the main screen, and the video signal waveform and picture are displayed as thumbnails. Figure 5-34 Multi display (USER 3) USER 4 The picture, video-signal-waveform, and vector are displayed top to bottom. This is suitable for simul mode.
Page 79 (five types) can be arranged freely. To do so, connect a mouse to the front or rear panel USB port. The layout that you specify will not be initialized even if you initialize the LV 5490. To initialize, LAYOUT INIT YES on the SYS menu: The entire layout is initialized.
Page 80 5. BASIC OPERATION 5.3.2 Layout Procedure As an example, this section explains how to change the layout of a multi display (User 1) in the following manner. a) Display the layout screen b) Change TIME in the upper right of the screen to DATE c) Superimpose the vector on the picture d) Add audio e) Add TIME to the status...
Page 81 5. BASIC OPERATION a) Display the layout screen Press MULTI, and set 1 LAYOUT SELECT to USER 1. There are five layouts for the multi screen. You can use USER 1 to USER 5 to switch between the layouts. Right-click in the measurement screen, and click LAYOUT. The layout screen appears.
Page 82 5. BASIC OPERATION If the layout window gets in the way, move it or close it. If you close it, you can redisplay it by double-clicking in the layout screen. If multiple items are on top of each other, items in the back may not be selectable. If you need to select such item, click the item on the Main or Sub tab.
Page 83 5. BASIC OPERATION 5.3.3 Layout Screen Description Figure 5-39 Layout screen Layout Window The Layout window is used to create layouts. Mode in the title bar displays the current measurement mode (WFM, USER 1 to USER 5, etc.). You can move the window by dragging and close it by clicking X in the upper right of the window.
Page 84 5. BASIC OPERATION Figure 5-40 Layout window Select Item Displays the selected item. Display Mode / Style Select the display format for simul mode. Display Mode applies to the entire screen, Style applies to the selected item. If Display Mode is set to TILE or if the selected item is AUDIO or EYE, Style cannot be selected.
Page 85 5. BASIC OPERATION For example, if the following screens are displayed in single input mode and you change to simul mode, the display changes depending on Display Mode as follows. Figure 5-41 Single input mode When Display Mode Is NORMAL The screen is divided by channel within each item.
Page 86 5. BASIC OPERATION When Display Mode Is TILE The screen is divided by channel. Figure 5-43 Tiled display Main Measurement item. Shows the video signal waveform display. Shows the picture display. VECT Click this after selecting the display mode on the VECT tab to show the vector waveform display.
Page 87 5. BASIC OPERATION Items for displaying information. FORMAT Displays the format (e.g., 1920x1080/59.94I YCbCr(422) 10bit HD). If you place this item, you can show and hide it using the GENERAL SETUP tab in the system settings. It is normally displayed in white, but if the input format is not appropriate, it turns red. INPUT Displays the input signal (e.g., SDI 1A).
Page 88 5. BASIC OPERATION Time Turns on and off the time display (e.g., TIME: 00:00:00). This option cannot be displayed for an AUDIO item, an EYE item, or an item on the Sub tab. If you enable this option, you can select the display format using the GENERAL SETUP tab in the system settings.
Page 89 5. BASIC OPERATION 11 AUDIO Selects the display mode of the AUDIO item. Select the mode before clicking the AUDIO item. LEVEL BAR + etc. This is the normal audio display. The display switches between Lissajous, surround, meter, and status. It cannot be arranged with the items below at the same time.
Page 90 5. BASIC OPERATION 12 STATUS Selects the display mode of the STATUS item. Select the mode before clicking the STATUS item. STATUS ALL This is the normal status display. The display switches between error count, data dump, etc. It cannot be arranged with the items below at the same time. If you want to arrange the items below, delete this item first.
Page 91 5. BASIC OPERATION 13 EYE Selects the display mode of the EYE item. Select the mode before clicking the EYE item. EYE / JITTER This is the normal eye pattern display. The display switches between eye pattern and jitter. It cannot be arranged with the items below at the same time. If you want to arrange the items below, delete this item first.
Page 92: System Settings
6. SYSTEM SETTINGS SYSTEM SETTINGS The system settings can be used to configure the LV 5490 and unit settings. Press SYS, and use the SYS menu. Figure 6-1 SYS menu Configuring the I/O Connectors To configure the I/O connector settings, use 1 SIGNAL IN OUT on the SYS menu.
Page 93 Selects the division transmission system when SDI System is 4K. Square / 2 Sample Interleave i/PsF Select The LV 5490 cannot detect the following formats. Therefore, select whether to use interlace or segmented frame for displaying. This cannot be selected when SDI System is 4K.
Page 94 6. SYSTEM SETTINGS Pixel Depth Select the quantization of the input signal. SDI System is 3G-B-DS or 4K 3G Dual Link, this is fixed to 10bit, and you cannot change 10bit / 12bit 6.1.2 Configuring the SDI I/O Connectors Use the SDI OUT tab to configure the SDI INPUT/OUTPUT connectors on the rear panel. 1 SIGNAL IN OUT 3 NEXT TAB Figure 6-3 SDI OUT tab...
Page 95 6. SYSTEM SETTINGS Select Out Select the signal to output from SDI INPUT/OUTPUT 2A for when Mode is set to Input Through. This is fixed to A ch (except for 3G(DL)) during multi link (cannot be set). A ch: Transmits the reclocked version of the signal that has been received by the SDI INPUT 1A connector.
Page 96 6. SYSTEM SETTINGS Pattern Select the output pattern. The selectable patterns are shown below. Depending on the pattern, you can turn on and off YCbCr or RGB separately. For COLOR RASTER, you can set the YCbCr or RGB levels separately. Moreover, if Structure is set to RGB, you can select the Interlock check box to synchronize the RGB levels.
Page 97 6. SYSTEM SETTINGS Speed When Moving Box is set to ON, set the moving box speed. Greater the value, higher the speed. 1 - 3 Phase Difference When System is set to Quad, you can adjust the Bch, Cch, and Dch phases relative to Ach.
Page 98 6. SYSTEM SETTINGS 6.1.4 Configuring the Monitor Output Connectors Use the MONITOR OUT tab to configure the MONITOR OUTPUT connectors on the rear panel and the LV 5490 LCD. 1 SIGNAL IN OUT 2 PREV TAB Figure 6-5 MONITOR OUT tab Freq.
Page 99 Boot Mode Select the boot mode. Normal: The LV 5490 starts normally. Fast: The LV 5490 starts quickly. The mode must be set to Normal when updating the firmware. Capture Mode Screen: The screen will be captured as still images.
Page 100 6. SYSTEM SETTINGS Format Turns on and off the format display (e.g., 1920x1080/59.94I YCbCr(422) 10bit HD). This setting is valid when a FORMAT item or Format option is placed in the layout. OFF / ON Date Select the display format of the date. y is the Gregorian year, m is the month, and d is the day.
Page 101 6. SYSTEM SETTINGS Recall Select the menu to be displayed when recalling presets. Select this first, and then register presets. Recall Menu: The PSET menu is displayed. Function Menu: The measurement menu is displayed. LCD Auto Off Select the length of time that must elapse without any key operations for the backlight to turn off automatically.
Page 102 Configuring Ethernet Settings Use the ETHERNET SETUP tab to configure Ethernet settings and view the MAC address. The settings that you specify here will not be initialized even if you initialize the LV 5490. In addition, they are not recorded to presets.
Page 103 6. SYSTEM SETTINGS 6.2.3 Remote Control Settings Use the REMOTE SETUP tab to configure remote control settings. Reference F 3 NEXT TAB (×2) Figure 6-8 REMOTE SETUP tab Remote Mode Select the method for loading presets. Bit: Use pin 2 (/P1) to pin 9 (/P8) to load presets 1 to 8. Binary: Set pin 2 (/P1) as the least significant bit and pin 7 (/P6) as the most significant bit, and use binary code to load presets 1 to 60.
Page 104 Setting the Date and Time Use the DATE&TIME tab to set the date and time. The settings that you specify here will not be initialized even if you initialize the LV 5490. In addition, they are not recorded to presets.
Page 105 If either of these alarm appears, immediately turn the power off, and then check for problems with the operating environment. If this alarm appears even though there are no problems with the operating environment, contact your local LEADER agent. Installing Options LICENSE on the SYS menu.
Page 106 The name of the option is deleted from the License List. “Failed” appears if the license key is not correct. Reenter the license key correctly. Restart the LV 5490. Adjusting the Backlight To adjust the backlight, use 5 LCD BACK LIGHT in the SYS menu.
Page 107 6. SYSTEM SETTINGS Initialization To initialize the LV 5490 settings and layout, use 7 INITIALIZE in the SYS menu. 7 INITIALIZE Figure 6-12 INITIALIZE menu 6.7.1 Initializing Settings To initialize the settings, press PARAM INIT YES. To cancel, press 5 INIT CANCEL.
Page 108 6. SYSTEM SETTINGS 6.7.2 Initializing the Layout To initialize the layout, press LAYOUT INIT YES. To cancel, press 5 INIT CANCEL. When you initialize the layout, the layouts configured in all measurement displays (11 total) will be initialized. To initialize the layout in each measurement display, click DEFAULT Reference DEFAULT LAYOUT 6.7.3...
Page 109 You can use the screen capture feature to capture still-image data of the screen. You can save the captured data to USB memory or overlay it on the input signal on the LV 5490 display. Frame Capture (Single input mode only) You can use the frame capture feature to capture single frames of data from the SDI signal.
Page 110 Display the screen you want to capture. Press CAP. When you press CAP, the LV 5490 stores a screen capture of the display in its internal memory. You can also take screen captures by pressing 2 REFRESH while the CAP menu is displayed.
Page 111 If you press CAP and perform an operation such as changing the measurement screen, the acquired screen capture data is deleted. However, by saving the screen capture data to a USB memory device in BSG format, you can display the screen capture data on the LV 5490 even after you restart the instrument.
Page 112 (Screen capture data that has been saved in BMP format and screen capture data that has been saved in BSG format on a different model cannot be displayed on the LV 5490.) Connect a USB memory device to the LV 5490.
Page 113 To delete screen capture data that has been saved to USB memory, follow the procedure below. (You can also delete the data on the PC.) Connect a USB memory device to the LV 5490. Press CAP. The CAP menu appears.
Page 114 The CAP menu appears. Unlike screen captures, frame data is not captured when you press CAP. Figure 7-7 CAP menu Capturing frame data manually Press TRIGGER to select MANUAL. Press 2 REFRESH. One frame of data is captured in the LV 5490.
Page 115 Figure 7-8 Error standby When the message below appears, press any key except for the power key. If an error occurs during error standby, the LV 5490 captures the frame data at that point and stops the frame capture. The applicable errors are those listed under “Applicable Errors” below whose detection setting has been set to ON through 5 STATUS SETUP on the STATUS menu.
Page 116 Saving to a USB Memory Device The frame data captured in the LV 5490 is cleared when the power is turned off. If you want to display it later even after the power is turned off, save the data to USB memory by following the procedure below (save the data in FRM format).
Page 117 USB memory device. This menu item does not appear when there is no frame data captured in the LV 5490. When the input signal is 1080i/59.94 and all the file types that you can select with FILE TYPE are set to ON, it takes about 50 seconds to save the data.
Page 118 Press 1 RECALL. To display frame data, the LV 5490 must be receiving a signal whose format is the same as that of the saved data. The FORMAT item at the bottom of the display shows the format of the saved data. It is displayed in green if the format is the same as the current format or in red if the format is not the same.
Page 119 To delete frame capture data that has been saved to a USB memory device, follow the procedure below. (You can also use a PC to delete the data.) Connect a USB memory device to the LV 5490. Press CAP. The CAP menu appears.
Page 120 8. PRESET SETTINGS PRESET SETTINGS The preset feature stores up to 60 sets of panel settings. It can be used to easily recall fixed settings. Also, you can use the same settings on multiple LV 5490s by copying presets to USB memory.
Page 121 8. PRESET SETTINGS Press 1 COMMENT INPUT. The comment input display appears. You can also copy a comment from a preset that already has a comment saved to it. To copy a comment, on the preset registration display, move the cursor to the preset that has the comment that you want to copy, and press the function dial ( D).
Page 122 8. PRESET SETTINGS Recalling Presets To recall a preset, follow the procedure below. Press PSET. The PSET menu appears. Figure 8-4 PSET menu Press a key from 1 No.1 to 6 No.6. If the preset that you want to load is number 7 or greater, press 7 more or turn the function dial ( D).
Page 123 8. PRESET SETTINGS Deleting Presets To delete a preset, follow the procedure below. Hold down PSET. The preset registration display appears. Figure 8-5 Preset registration display Turn the function dial ( D) to select the file that you want to delete. Press 3 DELETE.
Page 124 Note that if you use a PC to change the names of the files stored in the USB memory, you will no longer be able to copy the altered presets from USB memory to an LV 5490. USB memory device...
Page 125 8. PRESET SETTINGS Copying All Presets from USB Memory to the LV 5490 To copy all the presets from USB memory to the LV 5490, follow the procedure below. Connect a USB memory device to the LV 5490. Hold down PSET.
Page 126: Remote Control
9. REMOTE CONTROL REMOTE CONTROL You can use the remote control connector on the rear panel to load presets, transmit alarm signals, and perform other operations. Use the supplied 15-pin D-sub connector to control the LV 5490. Pinout Example This section contains a diagram of the remote control connector, displayed as it appears on the rear panel, and a table that describes the connector's pinout.
Page 127 9. REMOTE CONTROL Configuring the LV 5490 “Remote Control Settings.” SYSTEM SETUP NEXT TAB (×2) Figure 9-2 REMOTE SETUP tab Remote Control The input connectors respond to active-low signals. Do not apply negative voltages or voltages that exceed +5 V. After you make a setting, a period of time of 350 ms or more in which the electrical potential is stable is required, so wait at least 1 second before you make the subsequent setting.
Page 128 9. REMOTE CONTROL After a setting is made, it may take about 3 seconds for the operation to finish. If you configure subsequent settings before the initial operation finishes, only the last setting will take effect. All settings in between will be discarded. (In the following example, remote control 2 will be discarded.) Figure 9-4 Remote control timing 2 Loading Presets...
Page 129 9. REMOTE CONTROL The control table when Remote Mode is set to Binary is shown below. Table 9-3 Loading presets (Binary) Preset...
Page 130 Preset Alarm Output The LV 5490 outputs an alarm from pin 14 (ALARM) when any of the conditions below is true. The applicable alarm output channels are all the channels in the selected group (1A to 1D or 2A to 2D). However, when measuring 3G-B-DS or 3G (DL), alarms are output only for the currently displayed channels.
Page 131: Menu Tree
This chapter shows the menu trees that correspond to each key. The default settings are underlined. The menus that are displayed vary depending on the LV 5490 settings and whether a USB memory device is connected to the LV 5490.
Page 132 10. MENU TREE 10.2 INPUT Menu...
Page 133 10. MENU TREE 10.3 SYS Menu...
Page 134 10. MENU TREE 10.4 CAP Menu...
Page 135 10. MENU TREE 10.5 PSET Menu...
Page 136 [LV 5490] A feature for clearing icons, such as that appears when a USB connection is made, has been added. [LV 5490] The tab menu that was used previously is now displayed until the power is turn off and on.
Page 137 [LV 5490] The LCD backlight can now be turned off automatically. [LV 5490] The layouts of all measurement displays can now be initialized at once. [SER01] Support has been added for HD dual link and 3G-SDI level B dual stream.
Page 138 Index ALL COPY INT->USB ..........115 LAYOUT INIT YES ............99 ALL COPY USB->INT ..........116 LCD BACK LIGHT ............97 ALL INIT YES ............99 LCD OFF ..............97 LICENSE ..............96 BMP ................. 102 BSG ................. 102 PARAM INIT YES ............98 PSET ................ 111 CAP .................
Page 140 LEADER ELECTRONICS CORP. 2-6-33 Tsunashima-Higashi, Kohoku-ku, Yokohama 223-8505, Japan PHONE:81-45-541-2123 FAX:81-45-541-2823 http://www.leader.co.jp July 16, 2014 Ver. 4 (FW Ver. 1.5)
