Microtek ArtixScan 120tf Specifications page 2

Includes FULL versions of 3 professional
RGB and CMYK imaging software titles
SilverFast ™
• Scan raw high-bit images that can
be imported directly into Photoshop
• Dust & Scratch Removal works on color and black & white film
• GANE ® reduces film grain and ACR restores faded colors
• Real-time negative film optimization with over 120 profiles
Genuine Fractals
• Enlarge images up to 800% with
no loss in quality
• Lossless file compression
ScanWizard
• Scan in CMYK, RGB or LCH
ScanWizardPro TX
• Intelligent image categories
• Improved negative scanning produces the most consistent
and accurate color reproduction available
Delivering the details
With a 10,000-element Kodak CCD the ArtixScan 120tf captures
the most minute details in an image. A 6 x 6 cm negative
scanned at 4000 dpi collects over 500MB of data to deliver the
subtle nuances not seen by the naked eye. With this amazing
amount of information, your film can be enlarged to produce
300 dpi prints over 30" wide while retaining razor-sharp detail.
Microtek Lab, Inc.
16941 Keegan Avenue, Carson, CA 90746
www.microtek.com
© 2002 Microtek Lab, Inc. Digital imagery © 2003 Photo Disc. The following are trademarks or registered trademarks of their
respective companies: Microtek, ArtixScan, ScanWizard of Microtek Lab, Inc.; Windows of Microsoft Corporation; iMac, G3,
G4, Macintosh, Mac and the Mac logo are trademarks of Apple Computer, Inc., registered in the U.S. and other countries. The
"Built for Mac OS X" graphic is a trademark of Apple Computer, Inc., used under license. All other trademarks or registered
trademarks are the property of their respective holders. Specifications and software bundles are subject to change without
MLISS-AS120TF-0203
notice. Not responsible for typographical errors.
ArtixScan 120tf
HDR
Scanner Type
Film Type
Scanning Area &
Batch Scanning
(accuracy ±0.07mm)
™ 2.5
Optical Resolution
Optical Density
A/D Conversion
™ Pro TX
Output Data
Multiple Sampling
Color Management
Focus
Exposure
Panel Indicators
Light Source / Life
Optics
Interface
Dimensions
Weight
Power
Environment
Original size: 1/16" x 1/16"
Regulatory
Certification
Package Contents
Optional Accessory
Original size: 1/16" x 1/16"
System
Requirements
PC & Compatibles
Macintosh
The ArtixScan family of professional scanners
ArtixScan 4000tf
Single-pass, 35mm and 120 color film scanner
35mm and 120 film; positive, negative, color or monochrome
35mm slide 30mm x 38mm (4724 x 5984 pixels)
35mm filmstrip 30mm x 38mm (4724 x 5984 pixels)
6 x 4.5cm 56.5mm x 45mm (8897 x 7086 pixels)
6 x 6cm 56.5mm x 60mm (8897 x 9448 pixels)
6 x 7cm 56.5mm x 70mm (8897 x 11023 pixels)
6 x 9cm 56.5mm x 90mm (8897 x 14173 pixels)
4,000 dpi (10,000-element Kodak ® tri-linear CCD array)
4.2 maximum optical density
14-bits per color channel
16-bits, 8-bits per channel (user selectable)
2, 4, 8, 16 times (user selectable)
Built-in Kodak Digital Science ™ color management; uses standard ICC profiles; includes
over 140 profiles; Apple ColorSync ® and Microsoft
Auto focus (user selectable, on/off)
Auto and manual exposure control
Power, ready and busy status indicated by two front LEDs
Multi-wave cold cathode fluorescent / 6,000 hours continuous use
Proprietary, custom-built lens with anti-reflective coating
FireWire (IEEE 1394 standard) and SCSI-2
19.8" L x 10.8" W x 5.6" H (504mm L x 274mm W x 142mm H)
17.6 lbs (8kg)
Power Supply Auto-switching universal, 100-240 VAC, 1.2A max, 47/63Hz
Power Consumption 40 Watts max, Energy Star
Temperature 50° to 95°F (10° to 35°C)
Humidity 20% to 85% RH
Max Operating Alt. 6,562 ft. (2,000m)
Safety: ANSI/UL1950-1997, CAN/CSA C22.2 No. 950-95, CB ICE60950 EMI: FCC Class B,
CE (EN55022/1998, EN55024/1998), BSMI, VCCI Acoustics: 60dBA max per ISO 7779
ArtixScan ® 120tf scanner, 35mm slide holder (4 slides), 35mm filmstrip holder (6 frames), 120 film
holder, FireWire card (PC), 6-pin FireWire cable, 50- to 50-pin SCSI cable, power cord, Kodak 35mm
Q60 target, dust cover, LizardTech ™ Genuine Fractals
Scanner ICC Profiler, Microtek ® ScanWizard ™ Pro TX
N/A
CD-ROM drive (for installing software), Color monitor with 24-bit color capability
64MB RAM (128MB or more recommended)
FireWire (IEEE 1394) Pentium II PC or later, FireWire port or available PCI slot,
Windows 98 SE/2000/Me/XP
SCSI-2 Pentium II PC or later, Windows 95/98/2000/Me/XP
FireWire (IEEE 1394) iMac, Mac G3/G4, built-in FireWire port,
Mac OS 9.x, 10.1.3 to 10.2; Built for Mac OS X
SCSI-2 Power PC class or later w/ ASPI compliant SCSI port,
Mac OS 8.6 to 9.x, 10.1.3 to 10.2; Built for Mac OS X
ArtixScan 120tf
ArtixScan 1800f
batch up to 4 frames
batch up to 6 frames
batch up to 5 frames
batch up to 4 frames
batch up to 3 frames
batch up to 2 frames
® ICM compatible
® compliant
™ 2.5, LaserSoft ™ SilverFast ® HDR, Microtek ®
ArtixScan 2500f
