• 7-Day, 5-2-Day or 5-1-1-Day Programmable
• Configurable
• 2-Stage Heat/2-Stage Cool Systems
• 2-Stage Heat Pump Systems
• Large Display With Backlight
• Selectable Fahrenheit or Celsius
• Compatible with Gas, Oil, or Electric
• SimpleSet™ Field Programming
• Status Indicator Light
• Relay Outputs
(minimum voltage drop in thermostat)
• Remote Sensor Compatible
• Ideally Suited for:
–
Residential (New Construction/Replacement)
–
Light Commercial
Installation, Operation & Application Guide
For more information on our complete range of American-made
products – plus wiring diagrams, troubleshooting tips and more,
visit us at www.icmcontrols.com
SC 581 1
Programmable Electronic Thermostat
2 Heat/2 Cool
Auto Changeover
Hardwire
Advertisement
Table of Contents
Related Manuals for ICM Controls SC 5811
Summary of Contents for ICM Controls SC 5811
- Page 1 SC 581 1 2 Heat/2 Cool Auto Changeover Hardwire Programmable Electronic Thermostat • 7-Day, 5-2-Day or 5-1-1-Day Programmable • Configurable • 2-Stage Heat/2-Stage Cool Systems • 2-Stage Heat Pump Systems • Large Display With Backlight • Selectable Fahrenheit or Celsius • Compatible with Gas, Oil, or Electric • SimpleSet™ Field Programming • Status Indicator Light • Relay Outputs (minimum voltage drop in thermostat) • Remote Sensor Compatible • Ideally Suited for: – Residential (New Construction/Replacement) – Light Commercial Installation, Operation & Application Guide For more information on our complete range of American-made products –...
-
Page 2: Table Of Contents
Table of Contents Parts Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Icon Descriptions . -
Page 3: Parts Diagram
Parts Diagram Up button Down button S1 S2 R Y1 W2 Y2 Right (fan) button RESET CONFIG Left (system) button Field programming pins Configuration switch Reset switch... -
Page 4: Icon Descriptions
Icon Descriptions Room temperature offset activated Fan operation icon Lock mode activated Cooling operation icon Heating operation icon Specifications Electrical rating: • 24 VAC (18-30 VAC) • 1 amp maximum per terminal • 3 amp maximum total load Temperature control range: 45°F to 90°F (7°C to 32°C) Accuracy: ± 1°F (± 0 .5°C) System configurations: 2-stage heat, 2-stage cool, heat pump, gas, oil, electric Timing: Anti-short Cycle: 4 minutes (bypass anti-short cycle delay by returning to OFF mode for 5 seconds) Backlight Operation: 10 seconds Terminations: S1, S2, R, C, W/O/B, Y1, W2, Y2, G... -
Page 5: Important Safety Information
Important Safety Information WARNING!: Always turn off power at the main power supply before installing, cleaning, or removing thermostat. • This thermostat is for 24 VAC applications only; do not use on voltages over 30 VAC • Do not short across terminals of gas valve or system control to test operation; this will damage your thermostat and void your warranty • All wiring must conform to local and national electrical and building codes • Do not use air conditioning when the outdoor temperature is below 50 degrees; this can damage your A/C system and cause personal injuries • Use this thermostat only as described in this manual Package Contents/Tools Required Package includes: SC5811 thermostat on base, thermostat cover, wiring labels, screws and wall anchors, Installation, Operation and Application Guide Tools required for installation: Drill with 3/16” bit, hammer, screwdriver To Remove Existing Thermostat ELECTRICAL SHOCK HAZARD – Turn off power at the main service panel by removing the fuse or switching the appropriate circuit breaker to the OFF position before removing the existing thermostat. 1 . Turn off power to the heating and cooling system by removing the fuse or switching the appropriate circuit breaker off . 2 . Remove cover of old thermostat . This should expose the wires . 3 . Label the existing wires with the enclosed wire labels before removing wires . 4 . After labeling wires, remove wires from wire terminals . -
Page 6: To Install Thermostat
To Install Thermostat ELECTRICAL SHOCK HAZARD – Turn off power at the main service panel by removing the fuse or switching the appropriate circuit breaker to the OFF position before removing the existing thermostat. IMPORTANT: Thermostat installation must conform to local and national building and electrical codes and ordinances . Note: Mount the thermostat about five feet above the floor . Do not mount the thermostat on an outside wall, in direct sunlight, behind a door, or in an area affected by a vent or duct . 1 . Turn off power to the heating and cooling system by removing the fuse or switching the appropriate circuit breaker off . 2 . To remove cover, pull gently at the seam at the top . 3 . Put thermostat base against the wall where you plan to mount it (Be sure wires will feed through the wire opening in the base of the thermostat) . 4 . Mark the placement of the mounting holes . 5 . Set thermostat base and cover away from working area . 6 . Using a 3/16” drill bit, drill holes in the places you have marked for mounting . 7 . Use a hammer to tap supplied anchors in mounting holes . -
Page 7: Wiring Diagrams
Wiring Diagrams Heat/Cool Systems Optional remote or outdoor sensor Transformer 24 VAC Heat #1 Cool #1 Heat #2 Cool #2 * outdoor sensor only reads outdoor temperature... -
Page 8: Single Compressor Heat Pump With Electric Backup
Single Compressor Dual Compressor heat pump with electric backup heat pump with electric backup Optional Optional remote or remote or outdoor sensor outdoor sensor Transformer Transformer 24 VAC 24 VAC Reversing Valve Reversing Valve Compressor Compressor #1 Auxiliary Heat #1 Emergency Heat Compressor #2 * outdoor sensor only reads outdoor temperature... -
Page 9: Remote Sensor Installation (Optional)
Remote Sensor Installation (Optional) 1 . Remove cover from remote sensor housing . 2 . Select an appropriate location for mounting the remote sensor . 3 . Mount remote sensor unit using hardware provided . 4 . Install two strand shielded wire between remote sensor and thermostat . Shielded wire must be used . Do not run remote sensor wire in conduit with other wires . • Wire 1 should run between the S1 terminal on the thermostat and the S1 terminal on the remote sensor • Wire 2 should run between the S2 terminal on the thermostat and the S2 terminal on the remote sensor • Connect the shielding of the wire to the S2 terminal on the thermostat 5 . Configure the thermostat to operate with the remote indoor sensor (see Configuration Mode setting 13, Page 14) or use it for an outdoor sensor . Remote Sensor: (Shown: Optional ICM ACC-RT103 Remote Indoor Sensor; for outdoor sensor, order ACC-OD103.) Note: Remote or outdoor sensor reading can be displayed by simultaneously pressing the Down and SYS buttons . -
Page 10: Terminal Designator Descriptions
Terminal Designator Descriptions R – 24 VAC hot C – 24 VAC common W 1/O/B – Configurable W1 – 1st stage heat for non-heat pump systems O – cool active reversing valve B – heat active reversing valve Y1 – 1st stage cool, 1st stage heat for heat pumps W2 – 2nd stage heat for non-heat pump systems, emergency heat for heat pump systems Y2 – 2nd stage cool for 2 compressor systems, 2nd stage heat for 2 compressor heat pump systems G – Fan SC581 1 Output Chart Cool Cool Heat Heat Heat/Cool Y1,G YI,Y2,G W1,G* W1,W2,G* Heat Pump (One Compressor) Y1,G,O Y1,G,O Y1,G,B Y1,W2,G,B Heat Pump (Two Compressors) Y1,G,O Y1,Y2,G,O Y1,G,B Y1,Y2,G,B... -
Page 11: Configuration Mode
Configuration Mode The configuration mode is used to set the SC5811 to match your heating/cooling system . The SC5811 functions with heat pump, air conditioning, gas, oil or electric heat systems . To configure the SC5811, perform the following steps: 1 . Verify the SC5811 is in the OFF mode . Press the SYS (left) button until off mode displays . 2 . Remove the cover of the thermostat by gently pulling near one of the corners at the top of the thermostat . 3 . Press the CONFIG button for 1 second while the SC5811 is in OFF mode . CONFIG S1 S2 R Y1 W2 RESET CONFIG Press the up or down button to change settings within each screen . button Down button Press the right button to advance to the next screen . Note: Pressing the left button will return you to the previous screen . Left Right button button... -
Page 12: Configuration Mode Settings
Configuration Mode Settings The setup screens for Configuration Mode are as follows: 1 . Temperature Scale (F or C) Choose Fahrenheit or Celsius . Press the up or down button to select . Press the right button to advance to the next screen . 2 . 1 Stage Temperature Differential (1°F to 5°F) (0 .5°C to 2 .5°C) Set the number of degrees between your “setpoint” temperature and your “turn on” temperature . Press the up or down button to set differential value . Press the right button to advance to the next screen . 3 . 2 Stage Temperature Differential (1°F to 5°F) (0 .5°C to 2 .5°C) Set the number of degrees between when stage 1 turns on and when stage 2 turns on . Press the up or down button to set differential value . Press the right button to advance to the next screen . - Page 13 4 . Staged Off Outputs Select whether the outputs for heating and cooling are staged off independently or are satisfied simultaneously . 1 = outputs staged off independently 0 = outputs off simultaneously Press the up or down button to set . Press the right button to advance to the next screen . 5 . Minimum Deadband (1°F to 9°F) (1°C to 5°C) Set the minimum separation between heat setpoint and cool setpoint in Auto Changeover Mode . Press the up or down button to set deadband value . Press the right button to advance to the next screen .
- Page 14 6 . System – Set for heat pump, non-heat pump, reversing valve operation and number of compressors in your system . Reversing Number of Compressors Type of Choose System Valve Active or Compressor Stages Heat Heat Pump Heat Non-Heat Pump Heat Electric Press the up or down button to select . Press the right button to advance to the next screen .
- Page 15 7. Auxiliary Delay ON – (0-30 minutes) – Set the delay time in minutes for auxiliary heat to be locked out after a call for second stage . This extra savings feature is used to temporarily lock out auxiliary heat devices, allowing just heat pump to try to satisfy heat call . Press the up or down button to select . Press the right button to advance to the next screen . 8 . Lockout (0-8°, NITE, COOL-HEAT) – Select the number of degrees set temperature can be changed during keypad lockout or select to lockout during NITE period only . COOL-HEAT lockout allows adjustment of the set temperatures to the maximum heat set temperature selected in Step 9 and minimum cool set temperature selected in Step 10 . Note: The mode cannot be changed when the thermostat is locked . Press the up or down button to select . Press the right button to advance to the next screen . 9 . Maximum Heat Setpoint (45°F to 90°F) (7°C to 32°C) Adjust to control the maximum heat set temperature allowed . Press the up or down button to select . Press the right button to advance to the next screen . 10 . Minimum Cool Setpoint (45°F to 90°F) (7°C to 32°C) Adjust to control the minimum cool set temperature allowed . Press the up or down button to select .
- Page 16 11 . Room Temperature Offset (+9°F to -9°F) (+4 .5°C to -4 .5°C) Adjust to calibrate displayed room temperature to match actual room temperature . Note: When not set to 0, will display . Press the up or down button to select . Press the right button to advance to the next screen . 12 . Maximum Cycles Allowed Per Hour (- -, 2-6) - - = as many as needed, 2-6 = maximum cycles/hour Press the up or down button to select . Press the right button to advance to the next screen . 13 . Temperature Sensor (1-4) 1 . Only on-board sensor determines room temperature . 2 . Only remote sensor determines room temperature . 3 . Average temperature of on-board and remote sensor . 4 . Only on-board sensor will be used until NITE period, and then only remote sensor is used . Note: If there is no remote sensor, option 1 must be selected . Press the up or down button to select .
- Page 17 14 . Cooling Fan Delay Off Time (0, 30, 60, 90 seconds) Select the fan purge time for cooling . Press the up or down button to select . Press the right button to advance to the next screen . 15 . Status Indicator Light (Led 0, 1, 2) 0 = Status indicator never on 1 = Status indicator on with first stage 2 = Status indicator on with second stage Press the up or down button to select . Press the CONFIG button for 2 seconds to exit configuration .
-
Page 18: Mode Of Operation
Mode of Operation The SC5811 is a programmable, manual or auto changeover, 2-stage heat, 2-stage cool thermostat . It functions with air conditioning, heat pumps, gas, oil or electric heat systems . An outdoor sensor can be used to monitor the outdoor temperature . The thermostat activates the heating appliance when the room temperature is below the set heat temperature (by the differential temperature) and the red indicator light (configurable) on the thermostat will light . The SC5811 will stop outputting and the red light will turn off when the call for heat has been satisfied . With heat pumps, the thermostat will not let the compressor come on for 4 minutes after it turns off . This protects your compressor . When the room temperature is greater than the set cool temperature (by the differential temperature), the cooling device is activated and the green indicator light (configurable) on the thermostat will turn on . The SC5811 will stop outputting and the green light will turn off when the call for cooling is satisfied . The thermostat will not let the compressor come on for 4 minutes after it turns off . This protects your compressor . The SC5811 has five possible operating modes: OFF, Heat, Cool, Heat & Cool, and Program mode . In off mode, the thermostat will not turn on heating or cooling devices . The manual fan can be turned on in all operating modes using the fan button . In heat mode, the thermostat controls the heating system . In the cool mode, the thermostat controls the cooling system . In heat & cool mode, the thermostat controls both the heating and cooling systems . In program mode, the thermostat will automatically be controlled by the set program . Program mode can function with heat mode, cool mode, or heat & cool mode . The clock display alternates with the set temperature display for heat & cool mode . -
Page 19: Button Functions
Button Functions Up button Down button SYStem (left) FAN (right) PROG Used to increase the time, set temperatures and to adjust configuration settings . DOWN Used to decrease the time, set temperatures and to adjust configuration settings . SYS (left) Used to change from OFF, HEAT, COOL and AUTO changeover modes FAN (right) Used to turn on and off the indoor fan . PROG (SYS and FAN) Used to change from program operation to manual operation . UP and PROG Held in simultaneously for 10 seconds to lock and unlock the thermostat . DOWN and SYS Pressed simultaneously to display outdoor temperature if outdoor remote sensor is connected . -
Page 20: Operating Modes
Operating Modes There are five possible operating modes for the SC5811 . Off, Cool, Heat, and Cool & Heat modes are accessed by pressing the SYS (left) button . Program mode is accessed by pressing the SYS (left) and FAN (right) buttons simultaneously . OFF Mode • In this mode, the thermostat will not turn on the heating or cooling devices Note: The indoor fan can be turned on manually in every operating mode by pressing the FAN (right) button . The word FAN shows on the display and the fan icon appears when the fan operates . Heat Mode • In this mode, the thermostat controls the heating system . When the heat outputs, the flame icon apprears on the display . Note: For heat pumps, there is a four minute delay for your compressor to restart after it has turned off . To bypass the compressor time delay, go to OFF mode for 5 seconds . -
Page 21: Cool Mode
Emergency Heat Mode (Heat pump systems only) • In emergency heat mode, the heat pump system will be disabled and auxiliary heat will become the primary source of heat . Cool Mode • In this mode, the thermostat controls the cooling system . When the cooling outputs, the snowflake icon apprears on the display . Note: There is a four minute delay for your compressor to restart after it has turned off . To bypass the compressor time delay, go to OFF mode for 5 seconds . Cool and Heat Mode (Auto Changeover) • In this mode, the thermostat controls the cooling and heating systems, automatically changing over from one to the other as needed . • The timing display alternates with the set temperature every 10 seconds in the cool and heat mode . -
Page 22: Program Mode
Program Mode • In this mode, the program function is on (PROG displays), and the thermostat will automatically be controlled by the set program schedule . Program mode can function with heat mode, cool mode, or heat & cool mode . The program schedule can be overridden by changing the set temperature (up or down button) . After 2 hours, the program schedule will automatically be resumed . To manually return to the program PROG schedule, press the PROG button twice . PROG PROG... -
Page 23: Testing The Thermostat
Testing the Thermostat Once the thermostat is configured, it should be thoroughly tested . CAUTION!: Do not energize the air conditioning system when the outdoor temperature is below 50 degrees . It can result in equipment damage or personal injury . Heat Test 1 . Press SYS (left) button until heat mode is displayed . 2 . Adjust the set temperature so it is 5 degrees above the room temperature . 3 . Heat should come on within a few seconds . Red LED may turn on . 4 . Adjust the set temperature 2 degrees below the room temperature and the heat should turn off . There may be a fan delay on your system . Note: For heat pumps, there is a four-minute delay to protect your compressor after it turns off . To bypass the compressor time delay, go to OFF mode for 5 seconds . Cool Test 1 . Press SYS (left) button until cool mode is displayed . 2 . Adjust set temperature so it is 5 degrees below room temperature . -
Page 24: Setting The Time And Day Of The Week
Setting the Time and Day of the Week The time and day of the week must be set for your program schedule to operate correctly . 1 . Press the SYS (left) button until you are in the OFF mode . 2 . Press and hold the PROG button (SYS (left) and FAN (right) buttons pressed simultaneously) in for 6 seconds . 3 . Time displays (hour flashing) . Press the up or down button to adjust the hour . 4 . Press the FAN (right) button once to select minutes (minutes flashing) . Press the up or down button to adjust the minutes . 5 . Press the FAN (right) button once to select day of the week (TODAY flashing) . Press the up or down button to select current day of the week . Note: At any time, press the SYS (left) button to return to the previous screen or press the FAN (right) button to advance to the next screen . Press the PROG button in for 2 seconds to lock values into memory and return TODAY to the OFF mode or press the FAN (right) button once to enter programming . -
Page 25: Programming
Programming Program Overview The SC5811 programmable thermostat has four periods (MORN, DAY, EVE, NITE) that are customizable for each day of the week . Each period will have a start time, heat temperature, cool temperature and programmable fan option . The SC5811 monitors the day and time, while maintaining the specific conditions you have chosen for each period in your program . Setting the program schedule: 1 . Press the SYS (left) button until you are in OFF mode . 2 . Press and hold the PROG button (SYS and FAN buttons pressed simultaneously) for 6 seconds . 3 . Press the FAN (right) button 3 times . 4 . SUN thru SAT are blinking . From this screen you have 2 options: 1 . Press the FAN (right) button to begin programming all 7 days at one time, or 2 . Press the up button to see the other programming options . Note: The days of the week shown on the display will be programmed simultaneously . The screens are listed below . Screen 1 Screen 2 Screen 3 Screen 4... - Page 26 From any of the screens on Page 23, you can press the FAN (right) button to begin entering your program schedule . The days shown on the display will all be programmed simultaneously . Once the FAN (right) button is pressed, MORN blinks . Use the up or down button to select a different period (MORN, DAY, EVE, NITE) . Press FAN (right) button to advance to the next screen . Transition time hour blinks . Use the up or down button to select a different hour . Press FAN (right) button to advance to the next screen . Transition time minutes blink . Use the up or down button to select different minutes . Press FAN (right) button to advance to the next screen . Heat set temperature displays . Use the up or down button to adjust the heat set temperature . Press FAN (right) button to advance to the next screen . Cool set temperature displays . Use the up or down button to adjust the cool set temperature . Press FAN (right) button to advance to the next screen . Programmable fan screen displays . Use the up or down button to select: Choose Off – Programmable fan disabled On – Indoor fan on continuously Note: Programmable fan operates in Program mode only . Repeat above steps to program the four periods per day .
-
Page 27: Lockout Feature
Lockout Feature The SC5811 has a button lockout feature so the mode cannot be changed and the temperature adjustment is limited . Select the appropriate lockout from Configuration Mode Settings (Step 8, Page 13) of this guide . To activate the LOCK feature: 1 . Simultaneously press the SYS, FAN and UP buttons for 10 seconds . 2 . will display and the lockout function will be enabled . To deactivate the LOCK feature, repeat steps 1 and 2 above . -
Page 28: Factory Preprogramming
Factory Preprogramming The SC5811 comes preprogrammed with the following schedule: MORN 6:00 AM 8:00 AM 6:00 PM NITE 10:00 PM MONDAY HEAT 70°F HEAT 62°F HEAT 70°F HEAT 62°F thru SUNDAY COOL 78°F COOL 85°F COOL 78°F COOL 82°F Personal Program Schedule Use the following personal program schedule to record your settings: MONDAY MORN NITE HEAT HEAT HEAT HEAT... - Page 29 Personal Program Schedule (continued) THURSDAY MORN NITE HEAT HEAT HEAT HEAT COOL COOL COOL COOL FRIDAY MORN NITE HEAT HEAT HEAT HEAT COOL COOL COOL COOL SATURDAY MORN NITE HEAT HEAT HEAT HEAT COOL COOL COOL COOL SUNDAY MORN NITE HEAT HEAT HEAT...
-
Page 30: Simpleset Tm Field Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
SimpleSet Field Programming Requires SimpleSet Transfer Cable (ACC-WIH21) This feature is used for transferring configuration and program schedule from the master to the target thermostat . All thermostats for a job can be mounted and powered up . Configure and program one thermostat . This will be the master . The master will be used to copy the program to the rest of the thermostats . Preparing the master to Send: 1 . The master must be powered with 24 VAC . 2 . Verify the master thermostat is in OFF mode . 3 . Press SYS (left) button until OFF mode displays . 4 . Remove cover of the master thermostat by gently pulling near one of the corners at the top of the thermostat . 5 . Press the up and down buttons and CONFIG switch simultaneously for 5 seconds . 6 . The OUT screen displays indicating the master thermostat is ready to transfer data . Note: Press the up and down buttons and CONFIG switch simultaneously for 5 seconds to exit from data transfer mode and to return the master to the OFF mode . -
Page 31: Troubleshooting
Troubleshooting Symptom Remedy No display Check for 24 VAC at thermostat; display is blank when 24 VAC is not present Time and day of week must be reset after extended power loss System fan does not come on properly Verify wiring is correct, check Gas/Electric Configuration (see Setting 6, Page 12) All thermostat buttons are inoperative Verify 24 VAC is present; unit locks out when 24 VAC is not present No response with first button press First button press activates backlight only Program schedule activates at the wrong Check time (AM/PM) set on thermostat (see Setting the Time, Page 22) time Thermostat turns on and off too Adjust temperature differential (see Configuration Mode Settings 2 & 3, Page 10) frequently Thermostat does not follow program Verify it is operating in program mode (PROG displays); check time (AM/PM); check if in 2 hour program override Fan runs continuously Press FAN (right) button to turn fan off Fan turns on occasionally Program Mode: Check programmable fan setting in program schedule (see Page 24) Status indicator light not on during call Turn status indicator function on (see Configuration Mode Setting 15, Page 15) Room temperature is not correct Calibrate thermostat (see Configuration Mode Setting 11, Page 14) If remote sensor is used, check S1 and S2 terminal connections displays when any button is pressed Thermostat has the button lockout function activated (see Lockout Feature, Page 25 and Configuration Mode Setting 8, Page 13) on display instead of room Check for a bad connection at S1 and S2 terminals, if used (see Configuration temperature Mode Setting 13, Page 14) Heat or Cool not coming on Verify wiring is correct, gently pull on each wire to verify there is a good connection at terminal block Problem not listed above Press Reset button once*... - Page 32 ONE-YEAR LIMITED WARRANTY The Seller warrants its products against defects in material or workmanship for a period of one (1) year from the date of manufacture . The liability of the Seller is limited, at its option, to repair, replace or issue a non-case credit for the purchase prices of the goods which are provided to be defective . The warranty and remedies set forth herein do not apply to any goods or parts thereof which have been subjected to misuse including any use or application in violation of the Seller’s instructions, neglect, tampering, improper storage, incorrect installation or servicing not performed by the Seller . In order to permit the Seller to properly administer the warranty, the Buyer shall: 1) Notify the Seller promptly of any claim, submitting date code information or any other pertinent data as requested by the Seller . 2) Permit the Seller to inspect and test the product claimed to be defective . Items claimed to be defective and are determined by Seller to be non-defective are subject to a $30 .00 per hour inspection fee . This warranty constitutes the Seller’s sole liability hereunder and is in lieu of any other warranty expressed, implied or statutory . Unless otherwise stated in writing, Seller makes no warranty that the goods depicted or described herein are fit for any particular purpose . Patent No. - Design: 424,953 Patent No. - Thermal Intrusion Barrier: 6,597,275 Patent Pending - SimpleSet Target Programming Technology William Barry Blvd., North Syracuse, NY (Toll Free) 800-365-5525...
