Use and Care Manual
ELECTRIC COOKTOP MODELS: CTI304D, CTI365D
IMPORTANT: Save these instruction for Local Electrical Inspector's use.
INSTALLER: Please leave these Installation Instructions with this unit for the owner.
Before beginning, please read these instruction completely and carefully.
WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO
PERSONS, OBSERVE THE FOLLOWING:
1.
Use This Unit Only In The Manner Intended By The Manufacturer. If You Have Any Questions, Contact
The Manufacturer.
2.
Before Installing Or Servicing Unit, Switch Power Off At Service Panel And Lock Service Disconnecting
Means To Prevent Power From Being Switched On Accidentally. When The Service Disconnecting Means
Cannot Be Locked, Securely Fasten a Prominent Warning Device, Such As A Tag, To The Service Panel.
POWER SUPPLY – Power supply is dual rated: 240 VAC /208 VAC, 3-wire, 60 Hz, 50Amp circuit breaker
JUNCTION BOX – Plan the installation of the unit so that the location of the junction box is within three (3)
CABINET PREPARATION AND CLEARANCE – Be sure your appliance is properly installed and
To eliminate the risk of burns or fire by reaching over heated surface units, cabinet storage space located above
the surface units should be avoided. If cabinet storage is to be provided, the risk can be reduced by installing a
range hood that projects horizontally a minimum of 5 inches beyond the bottom of the cabinets.
Page 1 of 8
INSTALLATION INSTRUCTIONS
OWNER: Please retain these instruction for future reference.
READ AND SAVE THESE INSTRUCTIONS
required for CTI365D Models and 30 Amp circuit breaker for CTI304D Models.
feet of the center bottom of the cooktop. The junction box must be accessible from the
front of the unit. See FIG – 4.
grounded by a qualified technician.
11067.00 Rev B
Advertisement
Table of Contents
Related Manuals for Wind Crest CTI304D
Summary of Contents for Wind Crest CTI304D
- Page 1 POWER SUPPLY – Power supply is dual rated: 240 VAC /208 VAC, 3-wire, 60 Hz, 50Amp circuit breaker required for CTI365D Models and 30 Amp circuit breaker for CTI304D Models. JUNCTION BOX – Plan the installation of the unit so that the location of the junction box is within three (3) feet of the center bottom of the cooktop.
- Page 2 COOKTOP INSTALLATION WARNING – DISCONNECT POWER BEFORE INSTALLING COOKTOP. FOAM TAPE – A foam tape is provided to seal the cooktop edges to the countertop. Turn the cooktop upside down (USE A TOWEL OR TABLE CLOTH BETWEEN COOKTOP AND SUPPORT SURFACE) and apply the tape to bottom side edges of metal frame.
- Page 3 MAXIMUM DEPTH = 13" CABINET MINIMUM MINIMUM CLEARANCE SIDE WALL FROM BACK OF EXTRUSION CLEARANCE TO BACKSPLASH = 2" = 1" 18" MINIMUM FROM COUNTER TOP FOR COMBUSTIBLE SURFACES EXTENDING BEYOUND WIDTH OF COOKTOP CLEARANCE TO COMBUSTIBLE SURFACES – A=30 inches minimum clearance between the countertop and the bottom of an unprotected wood or metal cabinet.
- Page 4 2-5/8" 2-5/8" 2-3/8" MIN 2-3/8" MIN 19-3/4 19-3/4 35-3/8 29-3/8 CTI304 CTI365 Note: Provide a minimum of 2-1/2" clearance between bottom of cooktop and any other surface. Caution: Reducing this clearance can cause the cooktop to malfunction and/or damage the unit. FIG - 1 DATA PLATE FOAM TAPE...
- Page 5 CTG304D Wiring Page 5 of 8 11067.00 Rev B...
- Page 6 Page 6 of 8 11067.00 Rev B...
- Page 7 Notes MODEL NO. ____________________________ SERIAL NO. _______________________________ DATE OF PURCHASE ____________________ DATE INSTALLED ________________________ DEALER’S NAME ___________________________________________________________________ ADDRESS __________________________________________________________________________ Page 7 of 8 11067.00 Rev B...
- Page 8 CNP Industries, Inc. 351 Thor Place Brea, Ca 92821 Phone (877) 387-6721 Fax (714) 482-2337 Page 8 of 8 11067.00 Rev B...
