GAS COOKTOP MODELS: CTG304D, CTG305D, CTG365D
IMPORTANT:
Before beginning use please read these instructions completely and
carefully.
Leave this owner's manual with the cooktop.
INSTALLER:
OWNER:
Please retain this manual for future reference.
USE AND CARE MANUAL
CNP INDUSTRIES, INC.
ANAHEIM, CA 92817
(714) 482-2320 ● (714) 482-2337 FAX
P.O. BOX 18645
1
Advertisement
Table of Contents
Related Manuals for Wind Crest CTG304D
Summary of Contents for Wind Crest CTG304D
- Page 1 USE AND CARE MANUAL GAS COOKTOP MODELS: CTG304D, CTG305D, CTG365D IMPORTANT: Before beginning use please read these instructions completely and carefully. Leave this owner’s manual with the cooktop. INSTALLER: OWNER: Please retain this manual for future reference. CNP INDUSTRIES, INC.
- Page 2 Dear Customer, Thank you for selecting a Wind Crest Gas Cooktop. By following the procedures and recommendations in this manual the cooktop should give you many years of service. The top is produced from high quality stainless steel, which is very durable but does require some care to maintain its beauty.
- Page 3 Natural gas cooktops can be converted for Liquid Propane (LP) use by qualified servicers only. A factory supplied “LP” conversion kit is available. To obtain kit contact your local dealer. MODEL CTG304D – LP KIT #10691.00 MODEL CTG305D – LP KIT #10692.00...
-
Page 4: Safety Practices To Avoid Personal Injury
B. Always turn hood ON when cooking at high heat. ************************************************************************************************* When properly used and cared for your new Wind Crest Cooktop has been designed to be a safe, reliable appliance. When using kitchen appliances, basic safety precautions must be followed,... - Page 5 Do not repair or replace any part of the appliance unless specifically recommended in this manual. All other servicing should be referred to a qualified technician. Children should not be left alone or unattended in an area where appliances are in use. They should never be allowed to sit or stand on any part of the appliance.
- Page 6 ♦ SAVE THESE INSTRUCTIONS ♦ BEFORE USING YOUR COOKTOP FOR THE FIRST TIME: Remove all packaging materials and labels before using your cooktop. Check that you have these items: CTG304D: - 2 Burner Grates - 4 Single Burner caps - Use and Care Manual...
- Page 7 Controls & Burners Model CTG304D (Grates not shown) 1 – Right Front Burner Control 9,000 BTU/HR 2 – Left Front Burner Control 15,000 BTU/HR Model CTG305D (Grates not shown) 1 – Right Front Burner Control 9,000 BTU/HR 2 – Left Front Burner Control...
- Page 8 1 – Left Rear Burner Control 12,000 BTU/HR 2 – Left Front Burner Control 15,000 BTU/HR Model CTG365D (Grates not shown) 3 – Center Burner Control 18,500 BTU/HR Control Knob & Graphic HIGH HEAT ULTRA - LOW HEAT CENTER BURNER ONLY 4 –...
-
Page 9: Control Operation
CONTROL OPERATION Each burner has an individual control knob allowing infinite heat selection between high and low. 9,000 Btu/hr burner adjusts to 1300 Btu/hr Low 12,000 Btu/hr burner adjusts to 1600 Btu/hr Low 15,000 Btu/hr burner adjusts to 2100 Btu/hr Low 18,500 Btu/hr burner adjusts to 4100 Btu/hr Low and 500 Btu/hr Ultra-Low The control knobs are plated metal and can be removed (by pulling straight upward) for improved cleaning. -
Page 10: Cleaning And General Care
Grates are to be properly installed onto cooktop. Model CTG304D – Has two symmetrical grates. Position side by side into recessed area of cooktop over burners. Model CTG305D – Has two non-symmetrical grates. Position side by side into recessed area of cooktop over burners. -
Page 11: Warranty
Grates The grates are porcelain enamel coated cast iron. Non-abrasive cleaners are preferred. Use a hot or warm water and detergent solution. Mild abrasive cleaners, such as Bon Ami®, are acceptable. After cleaning always rinse and dry immediately. If grates are extremely dirty, a Scotch Brite pad will aid cleaning. Acidic and sugar-laden spills attack the porcelain –... - Page 12 NOTES...
